4820-01-232-8026
Check Valve
4820012328026 012328026 B-12C4-1/3 5381250 PART 16 5381250 98180 B-12C4-1 5381250
A valve permitting flow in one direction only. It does not have a stem, except when equipped with a lever and weight and has no pressure adjustment. It may be inline or cartridge (manifold) design. View more Check Valve
November 2023
10
Marketplace 4820-01-232-8026
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-232-8026 4+ Documents (More...)
4820-01-232-8026 4+ Documents ( More... ) https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-01-232-8026
Part NumberManufacturerStatusB-12C4-1 3T9T9 - Swagelok Co (Active) Primary Buy RNCC 3 RNVC 2 DAC E 5381250
PART 4 FG1016HHH1200 5381250 A length of nonmetallic hose with fittings on one or both ends.
A length of nonmetallic hose with PART 16 5381250 98180 B-12C4-1 5381250 A valve permitting flow in
PART 1 FG1016KKK0720AA 2010101C-12-12-12-72 FG1016KKK0720 5381250 A length of nonmetallic hose with
PART 16 5381250 98180 B-12C4-1 5381250 A valve permitting flow in one direction only. https//www.nsnlookup.com
Restrictions 4820-01-232-8026
4820-01-232-8026 is a Check Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4820-01-232-8026
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-01-232-8026
- NASA (G860)
- Effective Date:
- 1 Apr 1991
- US Navy (N9BC)
- Effective Date:
- 1 Jan 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Canada (ZC01)
- Effective Date:
- 1 Sep 1996
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4820-01-232-8026
- Part Number
- Manufacturer
- Status
- B-12C4-1
- Manufacturer
- 3T9T9 - Swagelok Co (Active)
- Primary Buy
- Primary Buy
- 5381250 PART 16
- 53711 - Naval Sea Systems Command (Active)
- Primary Buy
- Primary Buy
- 5381250 98180
- 53711 - Naval Sea Systems Command (Active)
- Secondary Buy
- Secondary Buy
- B-12C4-1
- 18034 - Nupro Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- B-12C4-1/3
- 98180 - Nupro Inc (Obsolete)
- Advisory Reference
- Advisory Reference
- 5381250
- 53711 - Naval Sea Systems Command (Active)
- Informational Drawing
- Informational Drawing
Datasheet 4820-01-232-8026
- Characteristic
- Specifications
- FIIG
- Specifications
- A530B0
- Connection Style [AHNC]
- Plain, Optional End (Pipe) All Ends
- Connection Type [AWLS]
- Threaded Internal Pipe All Ends
- Flow Control Device [ADQU]
- Poppet
- Material [MATT]
- Copper Alloy Body
- Material [MATT]
- Rubber Butadiene-Acrylonitrile Class Nbr Packing
- Maximum Operating Pressure [CQGM]
- 1500.0 Pounds Per Square Inch Single Response
- Maximum Operating Temp [AEHZ]
- 70.0 Deg Fahrenheit Single Response
- Media For Which Designed [MEDA]
- Hydraulic Fluid, Mineral Base Single Response
- Mounting Position [BBJX]
- Horizontal Or Vertical
- Nominal Thread Size [CQJX]
- 0.750 Inches All Ends
- Thread Series Designator [THSD]
- Npt All Ends
- Valve Operation Method [AQLR]
- Automatic
- Style Designator [STYL]
- Straight Thru
- Thread Direction [AAJF]
- Right-Hand All Ends
Weapon Systems (WSDC) 4820-01-232-8026
DLA Procurement Analysis 4820-01-232-8026
- Last Stock Position:
- 12 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4820-01-232-8026
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4820-01-232-8026
Freight Information 4820-01-232-8026
4820-01-232-8026 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-01-232-8026 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-01-232-8026 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-01-232-8026 is not classified as a special type of cargo when transported by water. 4820-01-232-8026 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-01-232-8026
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 4820-01-232-8026 1 Records
Contracting Technical Data File (CTDF) 4820-01-232-8026 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
