4820-01-229-7553
Safety Relief Valve
4820012297553 012297553 V-152 856A1209P17
A valve designed to automatically release excessive pressures. It is actuated by static pressure upstream of the valve and is used as a safety valve or relief valve, and may be set to close at a predetermined pressure. It is not designed for regulation of continuously fluctuating loads. It may be inline or cartridge (manifold) design. Excludes VALVE (1), RELIEF, PRESSURE AND TEMPERATURE. View more Safety Relief Valve
May 2023
8
Marketplace 4820-01-229-7553
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-229-7553 5+ Documents (More...)
4820-01-229-7553 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-01-229-7553
RQST NE Updated Every Day 4820-01-229-7553 RQST Updated Every Day 4820-01-229-7553 RQST NE Related Documents
Restrictions 4820-01-229-7553
4820-01-229-7553 is a Safety Relief Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4820-01-229-7553
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-01-229-7553
- Canada (ZC01)
- Effective Date:
- 1 Jul 1994
Approved Sources 4820-01-229-7553
- Part Number
- Manufacturer
- Status
- 856A1209P17
- Manufacturer
- 07482 - General Electric Company (Active)
- Primary Buy
- Primary Buy
- V-152
- 26952 - Enerpac Tool Group Corp (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
Similar Supply Items to 4820-01-229-7553
Freight Information 4820-01-229-7553
4820-01-229-7553 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 127220. A Sub NMFC of X. It has a NMFC Description of PRESSURE REG/RED/RELIEF VALVES NOI. 4820-01-229-7553 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 4820-01-229-7553 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 64490 which rates the freight between FCL and LCL. 4820-01-229-7553 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-01-229-7553 is not classified as a special type of cargo when transported by water. 4820-01-229-7553 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-01-229-7553
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- PPP-B-1672, Type II, Folding Convoluted Cushioning in Reusable Box
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
