4820-01-228-5529
Globe Valve
4820012285529 012285529 525-C361-XM N-807-9
A valve with one inlet and one outlet connection with outlet flow parallel to inlet flow. The flow is controlled by the action of a stem which lifts the disk perpendicularly off the center axis of its seat. The stem is at a 90 degree (1.5708 radians) angle to axis of flow. Excludes VALVE, STOP-CHECK; COCK, SHUTOFF, SCREW STEM; and VALVE, SOLENOID. View more Globe Valve
May 2023
4
Marketplace 4820-01-228-5529
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-228-5529 5+ Documents (More...)
Photo 1/2 NSN 4820-01-228-5529 (Identification) 2/2 - - 1.
United States (US) 4. 4820-01-228-5529 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 4820-01-228-5529
4820-01-228-5529 is a Globe Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4820-01-228-5529
- US Navy (N9BC)
- Effective Date:
- 1 Jan 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
Approved Sources 4820-01-228-5529
- Part Number
- Manufacturer
- Status
- 525-C361-XM
- Manufacturer
- 1GZ83 - Sfc Valve Corporation (Active)
- Primary Buy
- Primary Buy
- N-807-9
- 1GZ83 - Sfc Valve Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- N-807-9
- 32373 - Sfc Valve Corp (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4820-01-228-5529
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Style Designator [STYL]
- Straight Thru
- Maximum Operating Pressure [CQGM]
- 600.0 Pounds Per Square Inch Single Response
- Valve Operation Method [AQLR]
- Manual
- Connection Type [AWLS]
- Unthreaded Internal Pipe All Ends
- Connection Style [AHNC]
- Socket All Ends
- Nominal Pipe Size Accommodated [AAAR]
- 0.500 Inches All Ends
