4820-01-215-2135

Check Valve

4820012152135 012152135 MIL-DTL-7899 MS28882A-24 MIL-V-7899 588-24D1

A valve permitting flow in one direction only. It does not have a stem, except when equipped with a lever and weight and has no pressure adjustment. It may be inline or cartridge (manifold) design. View more Check Valve

Managed by United States

NSN Created on 22 Aug 1985

Data Last Changed
November 2023

NATO Update Count
17

NATO Data Quality

STYL Style A6 for 4820-01-215-2135 1/1 — NSN 4820-01-215-2135 (Identification) 1/1

Marketplace 4820-01-215-2135

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

588-24D1 VALVE,CHECK 9 EA NS

Subscribe to View Vendor Details...

MIL-V-7899 VALVE,CHECK 13 EA NS

Updated Every Day

4820-01-215-2135 RQST NE

Updated Every Day

4820-01-215-2135 RQST

Updated Every Day

4820-01-215-2135 RQST NE

Related Documents 4820-01-215-2135 5+ Documents (More...)

https//www.nsnlookup.com
/fsg-48/fsc-4820/us

4820-01-215-2135 Check Valve 4820012152135 012152135

MIL-DTL-7899 MS28882A-24 MIL-V-7899 588-24D1 A valve permitting flow in one direction only.
MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 https//www.nsnlookup.com
VALVE, MIL-DTL- 7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 ,

https//www.nsnlookup.com
/fsg-48/fsc-4820/us

4820-01-353-7382 Safety Relief Valve 4820013537382 013537382

VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 MS28883 MIL-V-7899 VALVE
, 012152135 , MIL-V-7899 / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request -7382 Safety Relief Valve
Check Valve 4820012152135 012152135 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE

https//www.nsnlookup.com
/fsg-48/fsc-4820/us

4820-01-241-4611 Check Valve 4820012414611 012414611

MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 , MIL-V-7899 /
fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 https
10CB240 MS28884B-10 MIL-V-7899 VALVE, 012152135 , MIL-V-7899 EA NS Request Quotation MIL-DTL https//

https//www.nsnlookup.com
/fsg-48/fsc-4820/us

4820-01-499-6578 Check Valve 4820014996578 014996578

VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 , MIL-V-7899 / fsg-48
/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 https 6633Fuel
MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE https//www.nsnlookup.com

https//www.nsnlookup.com
/fsg-48/fsc-4820/us

4820-01-017-2602 Check Valve 4820010172602 010172602,588-24D1

Upgrade for $1 a day Upgrade your Account Upgrade 4820-01-017-2602Check Valve4820010172602 010172602 588-24D1
VALVE,CHECK 2 EA NS Request Quotation Subscribe to View Vendor Details... 588-24D1 VALVE,CHECK 9 EA
Check Valve 4820012152135 012152135 Account Upgrade 4820-01-215-2135Check Valve4820012152135 012152135

Restrictions 4820-01-215-2135

4820-01-215-2135 is a Check Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 4820-01-215-2135

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 4820-01-215-2135

US Coast Guard (C911)
Effective Date:: 1 Jan 2005
Former MOE Rule:: C001
Supplementary Receivers:: XH; AMC 1 AMSC T

US Air Force (FXGC)
Effective Date:: 1 Jan 2005
Former MOE Rule:: FXAX; AMC 1 AMSC T IMC Z IMCACTY SX

US Navy (N9BC)
Effective Date:: 1 Jan 2005
Former MOE Rule:: N9CD
Supplementary Collaborators:: GTKE; AMC 1 AMSC T IMC Z IMCACTY KE

Brazil (YA01)
Effective Date:: 1 Oct 2001

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Australia (ZA01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Feb 1999

Denmark (ZS01)
Effective Date:: 1 May 2014

Greece (ZU01)
Effective Date:: 1 Jun 2005

Turkey (ZW01)
Effective Date:: 1 Dec 2005

Approved Sources 4820-01-215-2135

Part Number
Manufacturer
Status
MS28882A-24: 96906 - Military Standards (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
MIL-DTL-7899: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
MIL-V-7899: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
588-24D1: 09990 - Parker-Hannifin Corporation (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5

Datasheet 4820-01-215-2135

Characteristic
Specifications
FIIG: A530B0
Connection Style [AHNC]: Gasket Seal (Boss) All Ends
Connection Type [AWLS]: Threaded Internal Tube All Ends
Flow Control Device [ADQU]: Disk
Material [MATT]: Aluminum Alloy Overall
Maximum Operating Temp [AEHZ]: 160.0 Deg Fahrenheit Single Response
Media For Which Designed [MEDA]: Fuel/Oil, Hydrocarbon Single Response
Mounting Position [BBJX]: Horizontal
Nominal Outside Diameter Tube Accommodated [CWFD]: 1.500 Inches All Ends
Nominal Thread Size [CQJX]: 1.875 Inches All Ends
Valve Operation Method [AQLR]: Automatic
Specification/Standard Data [ZZZK]: 96906-Ms28882 Government Standard
Style Designator [STYL]: Straight Thru
Surface Treatment [SFTT]: Anodize
Thread Class [AAJD]: 3B All Ends
Thread Direction [AAJF]: Right-Hand All Ends
Thread Series Designator [THSD]: Unj All Ends
Thread Quantity Per Inch [CMLP]: 12 All Ends

Weapon Systems (WSDC) 4820-01-215-2135

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 4820-01-215-2135

Last Stock Position:: 16 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 4820-01-215-2135

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2021: Department of the Navy (DN); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Feb 2020: Department of the Air Force (DF); EA; Subscribe; 1

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SX: SICA RESIDUAL MMAC-OC-ALC

Price Validation Code:

E: The current standard price is an estimated price.
Estimated Price challenges are allowed but follow procedures in para 60.b. (3) of section L of this manual.
This code will be changed to a P code upon notification of a contract price or this code will be changed to an updated code upon determination of a valid price.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

NATO Stock Numbers Related to 4820-01-215-2135

4820-66-032-2602 4820-99-226-6712 4820-12-376-2998 4810-12-304-9438 4820-99-745-9058 4820-99-993-4992 4820-14-561-5821 4820-21-912-4474 4820-34-031-1491 4820-66-100-0013 4820-66-140-4603 4820-22-608-7887 4820-99-142-5128 4820-37-501-5120 4820-98-104-9586 4820-99-342-0921 4820-32-073-9443 4820-99-762-9214

Freight Information 4820-01-215-2135

4820-01-215-2135 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-01-215-2135 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-01-215-2135 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-01-215-2135 is not classified as a special type of cargo when transported by water. 4820-01-215-2135 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 4820-01-215-2135

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: ASTM - D5118, Fiberboard Box

Contracting Technical Data File (CTDF) 4820-01-215-2135 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
