4820-01-108-2581
Check Valve
4820011082581 011082581 MIL-DTL-7899 MS28882-12 593-12D1 MS28882A-12 7587870 MIL-V-7899 307100-12
A valve permitting flow in one direction only. It does not have a stem, except when equipped with a lever and weight and has no pressure adjustment. It may be inline or cartridge (manifold) design. View more Check Valve
Managed by United States
NSN Created on 24 Feb 1981
Data Last Changed
November 2023
November 2023
NATO Update Count
31
31
NATO Data Quality
Marketplace 4820-01-108-2581
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-108-2581 5+ Documents (More...)
MIL-DTL-7899 MS28882-12 593-12D1 MS28882A-12 307100-12 7587870 MIL-V-7899 A valve permitting flow in
, MIL-V-7899 / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request https//www.nsnlookup.com /fsg-48/
EA NS Request Quotation MS28883 MIL-V-7899 VALVE, https//www.nsnlookup.com MIL-DTL-7899 VALVE,CHECK
, MIL-V-7899 / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request https//www.nsnlookup.com /fsg-48/
EA NS Request Quotation MS28883 MIL-V-7899 VALVE, https//www.nsnlookup.com MIL-DTL-7899 VALVE,CHECK
VALVE,CHECK 120 EA NS Request Quotation MS28882A12 VALVE,CHECK 7 EA NS Request Quotation 593-12D1
VALVE,CHECK 69 EA NS Request Quotation Subscribe to View Vendor Details... 593-12D1 VALVE,CHECK 1 EA
NS Request Quotation MS28882-12 VALVE,CHECK 2 EA NS Request Quotation Updated Every Day 4820-00-555-
VALVE,CHECK 69 EA NS Request Quotation Subscribe to View Vendor Details... 593-12D1 VALVE,CHECK 1 EA
NS Request Quotation MS28882-12 VALVE,CHECK 2 EA NS Request Quotation Updated Every Day 4820-00-555-
,CHECK 5 EA NS Request Quotation MIL-DTL- 7899 https//www.nsnlookup.com / fsg-48/fsc MIL-V-7899 VALVE
,CHECK 5 EA NS Request Quotation MIL-DTL-7899 , 012152135 , MIL-V-7899 / fsg-48/fsc MIL-DTL-7899 VALVE
Check Valve 4820015218103015218103 , MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL- 7899 https
,CHECK 5 EA NS Request Quotation MIL-DTL-7899 , 012152135 , MIL-V-7899 / fsg-48/fsc MIL-DTL-7899 VALVE
Check Valve 4820015218103015218103 , MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL- 7899 https
MS28883 MIL-V-7899 VALVE, 012152135 , MIL-V-7899 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-01
VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 , MIL-V-7899 /fsg-48/
MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 https//www.nsnlookup.com
VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 , MIL-V-7899 /fsg-48/
MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135 https//www.nsnlookup.com
https EA NS Request Quotation MIL-DTL-7899 https/ /www.nsnlookup.com / fsg-48/fsc MIL-DTL-7899 VALVE
/www.nsnlookup.com MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135
, MIL-V-7899 / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request https//www.nsnlookup.com /fsg-48/
/www.nsnlookup.com MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883 MIL-V-7899 VALVE, 012152135
, MIL-V-7899 / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request https//www.nsnlookup.com /fsg-48/
Restrictions 4820-01-108-2581
4820-01-108-2581 is a Check Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4820-01-108-2581
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-01-108-2581
- US Air Force (FXGC)
- Effective Date:
- 1 Feb 2007
- NASA (G860)
- Effective Date:
- 1 Nov 1998
- US Navy (N9BC)
- Effective Date:
- 1 Jan 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GT
- Poland (WP01)
- Effective Date:
- 1 Aug 2011
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Columbia (YC01)
- Effective Date:
- 1 Jun 2015
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 May 2008
Approved Sources 4820-01-108-2581
- Part Number
- Manufacturer
- Status
- MS28882A-12
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-7899
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 7587870
- 18355 - The Boeing Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-V-7899
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 593-12D1
- 86768 - Teledyne Industries Inc Teledyne (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 7587870
- 88277 - The Boeing Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 307100-12
- 96124 - Transdigm Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS28882-12
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- 593-12D1
- 09990 - Parker-Hannifin Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4820-01-108-2581
- Characteristic
- Specifications
- FIIG
- Specifications
- A530B0
- Connection Style [AHNC]
- Gasket Seal (Boss) 1St End
- Connection Type [AWLS]
- Threaded Internal Boss 1St End
- Connection Type [AWLS]
- Threaded Internal Boss 2Nd End
- Disk Loading Method [ADSU]
- Spring
- Flow Control Device [ADQU]
- Disk
- Material [MATT]
- Steel Overall
- Maximum Operating Pressure [CQGM]
- 60.0 Pounds Per Square Inch Single Response
- Maximum Operating Temp [AEHZ]
- 135.0 Deg Fahrenheit Single Response
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Mounting Position [BBJX]
- Horizontal Or Vertical
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.750 Inches 1St End
- Nominal Thread Size [CQJX]
- 1.062 Inches 1St End
- Valve Operation Method [AQLR]
- Automatic
- Specification/Standard Data [ZZZK]
- 96906-Ms28882a12 Government Standard
- Style Designator [STYL]
- Straight Thru
- Thread Class [AAJD]
- 2A 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Series Designator [THSD]
- Unj 1St End
- Thread Quantity Per Inch [CMLP]
- 12 1St End
Weapon Systems (WSDC) 4820-01-108-2581
DLA Procurement Analysis 4820-01-108-2581
- Last Stock Position:
- 31 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4820-01-108-2581
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4820-01-108-2581
4820-66-032-2602 4820-99-226-6712 4820-12-376-2998 4810-12-304-9438 4820-99-745-9058 4820-99-993-4992 4820-14-561-5821 4820-21-912-4474 4820-34-031-1491 4820-66-100-0013 4820-66-140-4603 4820-22-608-7887 4820-99-142-5128 4820-37-501-5120 4820-98-104-9586 4820-99-342-0921 4820-32-073-9443 4820-99-762-9214
Freight Information 4820-01-108-2581
4820-01-108-2581 has freight characteristics managed by Australia.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-01-108-2581 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-01-108-2581 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4820-01-108-2581 is not classified as a special type of cargo when transported by water. 4820-01-108-2581 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-01-108-2581
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- --
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 4820-01-108-2581 1 Records
Contracting Technical Data File (CTDF) 4820-01-108-2581 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
