4820-01-052-8543
Check Valve
4820010528543 010528543 0690-0022 CV-30R
A valve permitting flow in one direction only. It does not have a stem, except when equipped with a lever and weight and has no pressure adjustment. It may be inline or cartridge (manifold) design. View more Check Valve
June 2023
3
Marketplace 4820-01-052-8543
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-052-8543 5+ Documents (More...)
CV-30R VALVE,CHECK 10 EA NS Request Quotation FedMall Updated Every 15 Minutes 4820-01-052-8543 BUY NE
/fsg-48/fsc-4820/us 4820-01-052-8543 Check Valve 4820010528543 010528543,0690-0022 0690-0022CV-30R A
Tapered Roller Bearing 3110123830138,639209 www.nsnlookup.com /fsg-31/fsc-3110/de 3110-12-383-0138 4820-01-052-8543
Check Valve 4820010528543 010528543,0690-0022 Subscribe to View Vendor Details... 639209 https/
Restrictions 4820-01-052-8543
4820-01-052-8543 is a Check Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4820-01-052-8543
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-01-052-8543
- US Army (A920)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- A181
- US Navy (N9BC)
- Effective Date:
- 1 Sep 2004
Approved Sources 4820-01-052-8543
- Part Number
- Manufacturer
- Status
- 0690-0022
- Manufacturer
- 63026 - Victor Equipment Co (Active)
- Primary Buy
- Primary Buy
- CV-30R
- 16166 - Western Enterprises Div Of Scott And (Active)
- Primary Buy
- Primary Buy
Datasheet 4820-01-052-8543
- Characteristic
- Specifications
- FIIG
- Specifications
- A530B0
- Connection Style [AHNC]
- Inverted Flare (Tube) 1St End
- Connection Style [AHNC]
- Inverted Flare (Tube) 2Nd End
- Connection Type [AWLS]
- Threaded External Tube 2Nd End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Disk Loading Method [ADSU]
- Spring
- Flow Control Device [ADQU]
- Poppet
- Material [MATT]
- Copper Alloy Overall
- Maximum Operating Pressure [CQGM]
- 125.0 Pounds Per Square Inch Single Response
- Media For Which Designed [MEDA]
- Oxygen, Gaseous Single Response
- Mounting Position [BBJX]
- Horizontal Or Vertical
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.375 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.562 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.562 Inches 2Nd End
- Seat Angle [CQRB]
- 30.0 Degrees All Ends
- Valve Operation Method [AQLR]
- Automatic
- Style Designator [STYL]
- Straight Thru
- Thread Class [AAJD]
- 2A 2Nd End
- Thread Class [AAJD]
- 2B 1St End
- Thread Direction [AAJF]
- Right-Hand 2Nd End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Series Designator [THSD]
- Unf 1St End
- Thread Series Designator [THSD]
- Unf 2Nd End
DLA Procurement Analysis 4820-01-052-8543
Management Data 4820-01-052-8543
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4820-01-052-8543
Freight Information 4820-01-052-8543
4820-01-052-8543 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-01-052-8543 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-01-052-8543 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-01-052-8543 is not classified as a special type of cargo when transported by water. 4820-01-052-8543 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-01-052-8543
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 4820-01-052-8543 2 Records
Contracting Technical Data File (CTDF) 4820-01-052-8543 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
