4820-01-032-5696
Globe Valve
4820010325696 010325696 MIL-V-17737 TY D1784-1 1-2INGL D1784-1 1/2INGL D3550 D1784 1 1/2IN CS4820-0102TYPEV 1894M D1784-1 1/2INGLBSTP D1784 CS4820-0102
A valve with one inlet and one outlet connection with outlet flow parallel to inlet flow. The flow is controlled by the action of a stem which lifts the disk perpendicularly off the center axis of its seat. The stem is at a 90 degree (1.5708 radians) angle to axis of flow. Excludes VALVE, STOP-CHECK; COCK, SHUTOFF, SCREW STEM; and VALVE, SOLENOID. View more Globe Valve
May 2023
17
Marketplace 4820-01-032-5696
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-032-5696 5+ Documents (More...)
1/2IN CS4820-0102TYPEV1894M D1784D1784-1 1/2INGLBSTP CS4820-0102 -1 1-2INGL D1784-1 1/2INGLD1784 1 -4820
www.nsnlookup.com /fsg-47/fsc-4730/uk 4730-99-807-4044 Pipe Bushing 4730998074044 998074044,D1784 -1
1/2IN CS4820-0102TYPEV 1894M D1784D1784-1 1/2INGLBSTP CS4820-0102 -1 1-2INGL D1784-1 1/2INGL D1784 1
Globe Valve 4820011425278011425278,D1784 -1 1-2INGL D1784-1 1/2INGL D1784 1 1/2IN CS4820-0102TYPEV https
Valve 4820011425278 011425278,D1784 Globe Valve 4820011425278011425278,D1784 -1 1-2INGL D1784-1 1/2INGL
D1784F44145007-04 A tubular product formed from plastic material. -1 1-2INGL D1784-1 1/2INGL D1784 1
D1784 1 1/2IN CS4820-0102TYPEV 1894M D1784D1784-1 1/2INGLBSTP CS4820 https//www.nsnlookup.com /fsg-47
/fsc-4730/uk 4730-99-807-4044 Pipe Bushing 4730998074044 998074044,D1784 -1 1/2INGL D1784 1 1/2IN CS4820
Restrictions 4820-01-032-5696
4820-01-032-5696 is a Globe Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4820-01-032-5696
- US Navy (N9BC)
- Effective Date:
- 1 Aug 2004
- Supplementary Collaborators:
- GTHD
- Brazil (YA)
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB)
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU)
- Greece (ZU01)
- Effective Date:
- 1 Jun 2005
- Turkey (ZW)
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
- United States of America (ZZ)
Approved Sources 4820-01-032-5696
- Part Number
- Manufacturer
- Status
- D1784 1 1/2IN
- Manufacturer
- 0YA44 - Specialty Marine & Industrial (Active)
- Primary Buy
- Primary Buy
- CS4820-0102TYPEV
- 16236 - Dla Land And Maritime (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1894M
- 06546 - Bee Line Company (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- D1784-1 1/2INGLBSTP
- 17062 - P J Valves Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- D1784
- 17062 - P J Valves Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-V-17737 TY
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- D1784-1 1-2INGL
- 17062 - P J Valves Inc (Obsolete)
- Advisory Reference
- Advisory Reference
- D1784-1 1/2INGL
- 17062 - P J Valves Inc (Obsolete)
- Advisory Reference
- Advisory Reference
- D3550
- 17062 - P J Valves Inc (Obsolete)
- Advisory Reference
- Advisory Reference
- CS4820-0102
- 16236 - Dla Land And Maritime (Active)
- Informational Drawing
- Informational Drawing
Datasheet 4820-01-032-5696
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Bolt Hole Nominal Diameter [CWCQ]
- 1.125 Inches All Ends
- Bolt Hole Quantity [AECS]
- 4 All Ends
- Bonnet Type [ADSR]
- Inside Screw
- Bonnet Attachment Method [ADST]
- Bolted
- Bolt Circle Nominal Diameter [CWCT]
- 4.875 Inches All Ends
- Connection Type [AWLS]
- Flange All Ends
- Face To Face Distance [CWCF]
- 12.000 Inches
- Flange Face Design [CWDF]
- Raised Straight All Ends
- Flange Shape [ARKN]
- Round With Holes All Ends
- Flow Control Device [ADQU]
- Disk
- Material Document And Classification [MDCL]
- Qq-N-286,Cl A Fed Spec Single Material Response Stem
- Material Document And Classification [MDCL]
- Qq-N-288,Comp E Fed Spec Single Material Response Body
- Material [MATT]
- Nickel Alloy Stem
- Maximum Operating Temp [AEHZ]
- 775.0 Deg Fahrenheit Single Response
- Maximum Operating Pressure [CQGM]
- 1500.0 Pounds Per Square Inch Single Response
- Media For Which Designed [MEDA]
- Water-Oil-Gas Single Response
- Nominal Outside Diameter [CWCD]
- 7.000 Inches All Ends
- Nominal Thickness [CWCK]
- 1.250 Inches All Ends
- Raised Face Nominal Diameter [CWDL]
- 2.875 Inches All Ends
- Raised Face Nominal Height [CWDH]
- 0.250 Inches All Ends
- Valve Operation Method [AQLR]
- Manual
- Valve Size [CCFG]
- 1.500 Inches
- Style Designator [STYL]
- Straight Thru Flanged Ends
Weapon Systems (WSDC) 4820-01-032-5696
DLA Procurement Analysis 4820-01-032-5696
Management Data 4820-01-032-5696
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4820-01-032-5696
Freight Information 4820-01-032-5696
4820-01-032-5696 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-01-032-5696 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-01-032-5696 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-01-032-5696 is not classified as a special type of cargo when transported by water. 4820-01-032-5696 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
