4820-00-923-4582
Globe Valve
4820009234582 009234582 B712-1B1 1-4IN 213754LI B712-1B1 1-4INL1 MILV22094 MILV22094L1 213754 803-5184193
A valve with one inlet and one outlet connection with outlet flow parallel to inlet flow. The flow is controlled by the action of a stem which lifts the disk perpendicularly off the center axis of its seat. The stem is at a 90 degree (1.5708 radians) angle to axis of flow. Excludes VALVE, STOP-CHECK; COCK, SHUTOFF, SCREW STEM; and VALVE, SOLENOID. View more Globe Valve
May 2023
10
Marketplace 4820-00-923-4582
Request a Quotation from participating marketplace vendors
Related Documents 4820-00-923-4582 5+ Documents (More...)
Photo 1/2 NSN 4820-00-923-4582 (Identification) 2/2 - - 1.
Quotation Updated Every Day 4820-00-923-4582 RQST NE Updated Every Day 4820-00-923-4582 RQST Updated
enable JavaScript in your web browser . 5999-14-462-2206Boitier Couvercle5999144622206 144622206 213754
enable JavaScript in your web browser . 5999-14-462-2206Boitier Couvercle5999144622206 144622206 213754
B712-1-D ITEM 20 11859 - Hunt Valve Company, Inc. https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-923-4582
Globe Valve 4820009234582 009234582 Upgrade for $1 a day Upgrade your Account Upgrade 4820-00-923
Globe Valve 4820009234582 009234582 Upgrade 4820-00-923-4582Globe Valve4820009234582 009234582
B712-1B1 1-4IN 213754LI B712-1B1 1-4INL1 MILV22094 213754 MILV22094L1 803-5184193 A valve with one inlet
enable JavaScript in your web browser . 5999-14-462-2206Boitier Couvercle5999144622206 144622206 213754
5305143823319 143823319,213754 Documents 5305-14-382-3319 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-923-4582
Restrictions 4820-00-923-4582
4820-00-923-4582 is a Globe Valve that is specifically designed to be or selected as being nuclear hard. In addition it has other critical features such as tolerance, fit restrictions or application.This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4820-00-923-4582
- US Navy (N1H5)
- Effective Date:
- 1 Apr 1991
Approved Sources 4820-00-923-4582
- Part Number
- Manufacturer
- Status
- B712-1B1 1-4IN
- Manufacturer
- 11859 - Hunt Valve Company, Inc. (Active)
- Incomplete Reference
- Incomplete Reference
- 213754LI
- 03950 - Naval Inventory Control Point (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- B712-1B1 1-4INL1
- 03950 - Naval Inventory Control Point (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MILV22094
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MILV22094L1
- 03950 - Naval Inventory Control Point (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 213754
- 16497 - Dresser, Inc. (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 803-5184193
- 53711 - Naval Sea Systems Command (Active)
- Informational Drawing
- Informational Drawing
Datasheet 4820-00-923-4582
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Bonnet Attachment Method [ADST]
- Bolted
- Bonnet Type [ADSR]
- Outside Screw-Yoke
- Connection Style [AHNC]
- Streamlined With Two Brazing Rings 1St End
- Connection Type [AWLS]
- Unthreaded Internal Pipe 1St End
- Criticality Code Justification [CRTL]
- Zzzx
- Departure From Cited Designator [ZZZX]
- Quality Control Iaw Navships 0948-045-7010 Material Identification And Control Instruction For Level 1 Items
- Features Provided [CBBL]
- Bonnet Packing
- Flow Control Device [ADQU]
- Disk
- Material [MATT]
- Asbestos Packing
- Material [MATT]
- Steel Comp Xm-10 Stem Or Steel Comp Xm-11 Stem Or Steel Comp Xm-21 Stem Or Steel Comp Xm-26 Stem Or Steel Comp Xm-27 Stem Or Steel Comp 302 Stem Or Steel Comp 302B Stem Or Steel Comp 304 Stem Or Steel Comp 304N Stem Or Steel Comp 304L Stem Or Steel Comp 305 Stem Or Steel Comp 308 Stem Or Steel Comp 309 Stem Or Steel Comp 309S Stem Or Steel Comp 310 Stem Or Steel Comp 310S Stem Or Steel Comp 314 Stem Or Steel Comp 316 Stem Or Steel Comp 316L Stem Or Steel Comp 316N Stem Or Steel Comp 317 Stem Or Steel Comp 321 Stem Or Steel Comp 347 Stem Or Steel Comp 348 Stem Or Steel Comp 403 Stem Or Steel Comp 405 Stem Or Steel Comp 410 Stem Or Steel Comp 414 Stem Or Steel Comp 420 Stem Or Steel Comp 429 Stem Or Steel Comp 430 Stem Or Steel Comp 431 Stem Or Steel Comp 440A Stem Or Steel Comp 440B Stem Or Steel Comp 440C Stem Or Steel Comp 446 Stem
- Maximum Operating Pressure [CQGM]
- 1500.0 Pounds Per Square Inch Single Response
- Maximum Operating Temp [AEHZ]
- 775.0 Deg Fahrenheit Single Response
- Media For Which Designed [MEDA]
- Steam Single Response
- Nominal Pipe Size Accommodated [AAAR]
- 1.250 Inches 1St End
- Nondefinitive Spec/Std Data [ZZZT]
- D Composition
- Renewable Seat Ring Type [ADZH]
- Welded
- Valve Operation Method [AQLR]
- Manual
- Style Designator [STYL]
- Straight Thru
Management Data 4820-00-923-4582
Navy
- Cognizance:
- 3H
- Special Material ID:
- L1
- An item that supports either a SUBSAFE or Level 1 system that has undergone the extreme material control and quality assurance techniques that provide objective evidence of its acceptance for its appropriate application. Each item has certification papers (or special markings that provide traceability to the certification) that pedigree its material and physical properties, provide traceability, to manufacturer, contract list and lot, and document the quality assurance system and test requirements applied to the item.
- Issue, Repair, Requisition Restriction Code:
- 00
- No Restriction
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 4820-00-923-4582
Freight Information 4820-00-923-4582
4820-00-923-4582 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-00-923-4582 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4820-00-923-4582 is rated as class 60 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4820-00-923-4582 is not classified as a special type of cargo when transported by water. 4820-00-923-4582 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-00-923-4582
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 16.0" H x 16.0" W x 19.0" L
- --
- --
- --
- --
- 16.0" H x 16.0" W x 19.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
