4820-00-684-4271
Check Valve
4820006844271 006844271 16CB240 2S3016L MS28885-16D 588-16D1 MS28884B-16 1111-587665 MS28885-16 37552 MIL-DTL-7899
A valve permitting flow in one direction only. It does not have a stem, except when equipped with a lever and weight and has no pressure adjustment. It may be inline or cartridge (manifold) design. View more Check Valve
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
35
35
NATO Data Quality
Marketplace 4820-00-684-4271
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4820-00-684-4271 5+ Documents (More...)
16CB240 2S3016L MS28885-16D 588-16D1 MS28884B-16 1111-587665 MS28885-16 37552 MIL-DTL-7899 A valve permitting
MS28885-16 VALVE,CHECK 1 EA NS Request Quotation 16CB240 VALVE,CHECK 1 EA NS Request Quotation Subscribe
Quotation 16CB240 VALVE,CHECK 1 EA NS Request Quotation Subscribe MS28885-16 VALVE,CHECK 1 EA NS Request
MS28885-16 VALVE,CHECK 1 EA NS Request Quotation 16CB240 VALVE,CHECK 1 EA NS Request Quotation Subscribe
Quotation 16CB240 VALVE,CHECK 1 EA NS Request Quotation Subscribe MS28885-16 VALVE,CHECK 1 EA NS Request
MS28885-16 VALVE,CHECK 8 EA NS Request Quotation Subscribe to View Vendor Details... 3755-2 VALVE,CHECK
VALVE,CHECK 1 EA NS Request Quotation Subscribe to View Vendor Details... 1111-587665 VALVE,CHECK 1
EA NS Request Quotation MS28885-16 VALVE,CHECK 1 EA NS Request Quotation Updated Every Day 4820-00-142
VALVE,CHECK 1 EA NS Request Quotation Subscribe to View Vendor Details... 1111-587665 VALVE,CHECK 1
EA NS Request Quotation MS28885-16 VALVE,CHECK 1 EA NS Request Quotation Updated Every Day 4820-00-142
MS28885-16 VALVE,CHECK 8 EA NS Request Quotation Subscribe to View Vendor Details... 3755-2 VALVE,CHECK
RQST NS Request Quotation Subscribe to View Vendor Details... 1111-587665 VALVE,CHECK 1 EA NS Request
MS28885-16 VALVE,CHECK 1 EA NS Request Quotation 1111-587665 VALVE,CHECK 1 EA NS Request Quotation Updated
RQST NS Request Quotation Subscribe to View Vendor Details... 1111-587665 VALVE,CHECK 1 EA NS Request
MS28885-16 VALVE,CHECK 1 EA NS Request Quotation 1111-587665 VALVE,CHECK 1 EA NS Request Quotation Updated
/us 4820-00-013-8904 Check Valve 4820000138904 000138904 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL-7899
218 -4607 Check Valve 4820012184607 012184607 MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL-7899
https//www.nsnlookup.com / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883
218 -4607 Check Valve 4820012184607 012184607 MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL-7899
https//www.nsnlookup.com / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883
to enable JavaScript in your web browser . 4820-00-013-8904Check Valve4820000138904 000138904 MIL-DTL-7899
-218-4607 Check Valve 4820012184607 012184607 MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL-7899
to enable JavaScript in your web browser . 4820-00-013-8904Check Valve4820000138904 000138904 MIL-DTL-7899
-218-4607 Check Valve 4820012184607 012184607 MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL-7899
to enable JavaScript in your web browser . 4820-00-013-8904Check Valve4820000138904 000138904 MIL-DTL-7899
Restrictions 4820-00-684-4271
4820-00-684-4271 is a Check Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4820-00-684-4271
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-00-684-4271
- US Army (A920)
- Effective Date:
- 1 Jan 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- CT
- US Air Force (FXGC)
- Effective Date:
- 1 Jan 2005
- Former MOE Rule:
- FXAX
- US Navy (N9BC)
- Effective Date:
- 1 Jan 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
- Poland (WP01)
- Effective Date:
- 1 Aug 2011
- Brazil (YA01)
- Effective Date:
- 1 Sep 2000
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Singapore (YJ01)
- Effective Date:
- 1 Apr 2000
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Aug 2004
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
Approved Sources 4820-00-684-4271
- Part Number
- Manufacturer
- Status
- MS28884B-16
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-7899
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 16CB240
- 82829 - Allen Aircraft Products Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 2S3016L
- 99240 - Crissair Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 1111-587665
- 3H889 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1111-587665
- 92003 - Parker Hannifin Corporation Div (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS28885-16
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1111-587665
- 45681 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 37552
- 92003 - Parker Hannifin Corporation Div (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-DTL-7899
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 588-16D1
- 86768 - Teledyne Industries Inc Teledyne (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- MS28885-16D
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- 588-16D1
- 09990 - Parker-Hannifin Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4820-00-684-4271
- Characteristic
- Specifications
- FIIG
- Specifications
- A530B0
- Connection Style [AHNC]
- Flared (Tube) All Ends
- Connection Type [AWLS]
- Threaded External Tube All Ends
- Disk Loading Method [ADSU]
- Spring
- Flow Control Device [ADQU]
- Disk
- Material Document And Classification [MDCL]
- Mil-S-5059 Mil Spec Single Material Response Flow Control Device
- Material Document And Classification [MDCL]
- Qq-A-225/5,Alloy 2017,T4 Fed Spec Single Material Response Body
- Material Document And Classification [MDCL]
- Qq-A-225/5,Alloy 2017,T4 Fed Spec Single Material Response Seat
- Material [MATT]
- Aluminum Flow Control Device
- Maximum Operating Pressure [CQGM]
- 300.0 Pounds Per Square Inch Single Response
- Maximum Operating Temp [AEHZ]
- -67.0 Deg Fahrenheit 1St Response
- Maximum Operating Temp [AEHZ]
- 160.0 Deg Fahrenheit 2Nd Response
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Mounting Position [BBJX]
- Horizontal Or Vertical
- Nominal Thread Size [CQJX]
- 1.312 Inches All Ends
- Nondefinitive Spec/Std Data [ZZZT]
- B Class And 1.000 Size
- Seat Angle [CQRB]
- 37.0 Degrees All Ends
- Valve Operation Method [AQLR]
- Automatic
- Specification/Standard Data [ZZZK]
- 96906-Ms28884b-16 Manufacturers Standard
- Style Designator [STYL]
- Straight Thru
- Surface Treatment Document And Classification [STDC]
- Mil-A-8625,Ty 2 Mil Spec Single Treatment Response
- Surface Treatment [SFTT]
- Passivate
- Thread Direction [AAJF]
- Right-Hand All Ends
- Thread Class [AAJD]
- 3A All Ends
- Thread Quantity Per Inch [CMLP]
- 12 All Ends
- Thread Series Designator [THSD]
- Un All Ends
Weapon Systems (WSDC) 4820-00-684-4271
DLA Procurement Analysis 4820-00-684-4271
- Last Stock Position:
- 7 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4820-00-684-4271
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4820-00-684-4271
4820-66-032-2602 4820-99-226-6712 4820-12-376-2998 4810-12-304-9438 4820-99-745-9058 4820-99-993-4992 4820-14-561-5821 4820-21-912-4474 4820-34-031-1491 4820-66-100-0013 4820-66-140-4603 4820-22-608-7887 4820-99-142-5128 4820-37-501-5120 4820-98-104-9586 4820-99-342-0921 4820-32-073-9443 4820-99-762-9214
Freight Information 4820-00-684-4271
4820-00-684-4271 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-00-684-4271 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-00-684-4271 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-00-684-4271 is not classified as a special type of cargo when transported by water. 4820-00-684-4271 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-00-684-4271
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 4820-00-684-4271 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
