4820-00-627-4777
Check Valve
4820006274777 006274777 MS28884A-16 16C240-1 695833-1 1111-578574 2-20544
A valve permitting flow in one direction only. It does not have a stem, except when equipped with a lever and weight and has no pressure adjustment. It may be inline or cartridge (manifold) design. View more Check Valve
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
October 2025
October 2025
NATO Update Count
51
51
NATO Data Quality
Marketplace 4820-00-627-4777
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
MS28884A16 VALVE,CHECK 21 EA NS
695833-1 VALVE,CHECK 21 EA NS
16C240-1 VALVE,CHECK 21 EA NS
1111-578574 VALVE,CHECK 21 EA NS
2-20544 VALVE,CHECK 21 EA NS
Updated Every Day 4820-00-627-4777 RQST NE
Updated Every Day 4820-00-627-4777 RQST
Updated Every Day 4820-00-627-4777 RQST NE
Related Documents 4820-00-627-4777 5+ Documents (More...)
MS28884A-16 16C240-1 695833-1 1111-578574 2-20544 A valve permitting flow in one direction only.
MS28884A16 VALVE,CHECK 21 EA NS Request Quotation 695833-1 VALVE,CHECK 21 EA NS Request Quotation 16C240
-1 VALVE,CHECK 21 EA NS Request Quotation 1111-578574 VALVE,CHECK 21 EA NS Request Quotation 2-20544
MS28884A16 VALVE,CHECK 21 EA NS Request Quotation 695833-1 VALVE,CHECK 21 EA NS Request Quotation 16C240
-1 VALVE,CHECK 21 EA NS Request Quotation 1111-578574 VALVE,CHECK 21 EA NS Request Quotation 2-20544
Upgrade 4820-00-627-4777Check Valve4820006274777 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-627-4777
Check Valve 4820006274777 006274777 Account Upgrade 4820-00-627-4777Check Valve4820006274777 006274777
MS28884A-16 1111-578574 16C240-1 695833 Details... 1111-578574 VALVE,CHECK 10 EA NS Request Quotation
Check Valve 4820006274777 006274777 Account Upgrade 4820-00-627-4777Check Valve4820006274777 006274777
MS28884A-16 1111-578574 16C240-1 695833 Details... 1111-578574 VALVE,CHECK 10 EA NS Request Quotation
JavaScript in your web browser . 4820-21-871-5402Check Valve4820218715402 218715402 MS28884-16 MS28884A-16
www.nsnlookup.com /fsg-48/fsc-4820/ca 4820-21-871-5402 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-627-4777
Check Valve 4820006274777 006274777 Upgrade for $1 a day Upgrade your Account Upgrade 4820-00-627
www.nsnlookup.com /fsg-48/fsc-4820/ca 4820-21-871-5402 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-627-4777
Check Valve 4820006274777 006274777 Upgrade for $1 a day Upgrade your Account Upgrade 4820-00-627
Machine Thread Plug 5365123139481123139481 5365-12 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-627-4777
Check Valve 4820006274777 006274777 Account Upgrade 4820-00-627-4777Check Valve4820006274777 006274777
MS28884A-16 1111-578574 16C240-1 695833 Details... 1111-578574 VALVE,CHECK 10 EA NS Request Quotation
Check Valve 4820006274777 006274777 Account Upgrade 4820-00-627-4777Check Valve4820006274777 006274777
MS28884A-16 1111-578574 16C240-1 695833 Details... 1111-578574 VALVE,CHECK 10 EA NS Request Quotation
202-5741 4820-01-164-7767 4820-01-052-8543 4820-01-333-0780 4820-01-392-0331 4820-01-521-8103 4820-00-627-4777
Restrictions 4820-00-627-4777
4820-00-627-4777 is a Check Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4820-00-627-4777
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-00-627-4777
- US Coast Guard (C911)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- C001
- Supplementary Receivers:
- XH
- US Air Force (FXGC)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- FXAX
- US Navy (N9BC)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTKE
- Poland (WP01)
- Effective Date:
- 1 Aug 2011
- Brazil (YA01)
- Effective Date:
- 1 Sep 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Philippines (ZM01)
- Effective Date:
- 1 Feb 2015
- Netherlands (ZN01)
- Effective Date:
- 1 Sep 1993
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4820-00-627-4777
- Part Number
- Manufacturer
- Status
- 16C240-1
- Manufacturer
- 82829 - Allen Aircraft Products Inc (Active)
- Primary Buy
- Primary Buy
- 1111-578574
- 92003 - Parker Hannifin Corporation Div (Active)
- Primary Buy
- Primary Buy
- 1111-578574
- 0TR84 - Federal Industries, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 1111-578574
- 45681 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2-20544
- 92003 - Parker Hannifin Corporation Div (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 695833-1
- 98897 - Lockheed Martin Corp (Active)
- Vendor Drawing
- Vendor Drawing
- MS28884A-16
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4820-00-627-4777
- Characteristic
- Specifications
- FIIG
- Specifications
- A530B0
- Connection Style [AHNC]
- Flared (Tube) 1St End
- Connection Type [AWLS]
- Threaded External Tube 1St End
- Disk Loading Method [ADSU]
- Spring
- Flow Control Device [ADQU]
- Disk
- Material [MATT]
- Aluminum Alloy 2017 Body
- Material [MATT]
- Rubber Seat
- Maximum Operating Pressure [CQGM]
- 60.0 Pounds Per Square Inch Single Response
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Mounting Position [BBJX]
- Horizontal Or Vertical
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 1.000 Inches 1St End
- Nominal Thread Size [CQJX]
- 1.312 Inches 1St End
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Valve Operation Method [AQLR]
- Automatic
- Style Designator [STYL]
- Straight Thru
- Surface Treatment [SFTT]
- Anodize
- Thread Class [AAJD]
- 3A 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Quantity Per Inch [CMLP]
- 12 1St End
- Thread Series Designator [THSD]
- Unf 1St End
Weapon Systems (WSDC) 4820-00-627-4777
DLA Procurement Analysis 4820-00-627-4777
- Last Stock Position:
- 5 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4820-00-627-4777
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Apr 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- R
- Refer To Aft095req
- AFT095REQ
- R
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4820-00-627-4777
Freight Information 4820-00-627-4777
4820-00-627-4777 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-00-627-4777 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-00-627-4777 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-00-627-4777 is not classified as a special type of cargo when transported by water. 4820-00-627-4777 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-00-627-4777
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 4820-00-627-4777 8 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7MC23V5153
- 02 May 2023
- Subscribe
- 41
- Subscribe
- Subscribe
- Subscribe
- SPE7MC18P1078
- 22 Nov 2017
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPE7M417P3258
- 23 May 2017
- Subscribe
- 30
- Subscribe
- Subscribe
- Subscribe
- SPE7MC16M8085
- 06 Sep 2016
- Subscribe
- 17
- Subscribe
- Subscribe
- Subscribe
- SPE7M116V9967
- 04 Apr 2016
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7MC16V3713
- 16 Feb 2016
- Subscribe
- 18
- Subscribe
- Subscribe
- Subscribe
- SPE7M116V2799
- 16 Nov 2015
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M116V2473
- 10 Nov 2015
- Subscribe
- 1
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 4820-00-627-4777 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
