4820-00-319-4336
Angle Valve
4820003194336 003194336 B222
A valve with one inlet and one outlet connection with outlet flow at an angle to inlet flow. The flow is controlled by the action of a stem which lifts disks perpendicularly off the center axis of its seat. It may be inline or cartridge (manifold) design. Excludes VALVE (1), Y; VALVE, STOP-CHECK; and COCK, SHUTOFF, SCREW STEM. View more Angle Valve
June 2023
5
Marketplace 4820-00-319-4336
Request a Quotation from participating marketplace vendors
Related Documents 4820-00-319-4336 5+ Documents (More...)
,B222 B222 VALVE,ANGLE 293 EA NS Request Quotation Subscribe to View Vendor Details... 4820-00-319-4336
VALVE ,B222 Photo 1/2 NSN 4820-00-319-4336 (Identification) 2/2 - - 1.
319-4336 Angle Valve 4820003194336 003194336,B222 https//www.nsnlookup.com /fsg-59/fsc-5998/de 5998-
https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-319-4336 Angle Valve 4820003194336 003194336,B222
B222 ,B222 Photo 1/2 NSN 4820-00-319-4336 (Identification) 2/2 - - 1. https//www.nsnlookup.com /fsg-
NE 319-4336 Angle Valve 4820003194336 003194336,B222 https//www.nsnlookup.com /fsg-59/fsc-5998/de 5998
https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-319-4349 Angle Valve 4820003194349 003194349,B222
319-4336 Angle Valve 4820003194336 003194336,B222 https//www.nsnlookup.com https//www.nsnlookup.com
Restrictions 4820-00-319-4336
4820-00-319-4336 is a Angle Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4820-00-319-4336
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-00-319-4336
- NASA (G900)
- Effective Date:
- 1 Apr 1991
Approved Sources 4820-00-319-4336
- Part Number
- Manufacturer
- Status
- B222
- Manufacturer
- 82666 - Stockham Valves And Fittings Inc (Active)
- Incomplete Reference
- Incomplete Reference
Datasheet 4820-00-319-4336
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Material [MATT]
- Copper Alloy Body
- Material [MATT]
- Plastic Vinyl Flow Control Device
- Material [MATT]
- Copper Alloy Seat
- Material [MATT]
- Copper Alloy Stem
- Material Document And Classification [MDCL]
- Qq-C-390,Alloy B5 Fed Spec Single Material Response Body
- Material Document And Classification [MDCL]
- Astm B63 Assn Std Single Material Response Seat
- Material Document And Classification [MDCL]
- Astm B371 Assn Std Single Material Response Stem
- Style Designator [STYL]
- Angle
- Flow Control Device [ADQU]
- Disk
- Media For Which Designed [MEDA]
- Steam Single Response
- Maximum Operating Pressure [CQGM]
- 150.0 Pounds Per Square Inch Single Response
- Maximum Operating Temp [AEHZ]
- 366.0 Deg Fahrenheit 1St Response
- Maximum Operating Temp [AEHZ]
- 150.0 Deg Fahrenheit 2Nd Response
- Valve Operation Method [AQLR]
- Manual
- Connection Type [AWLS]
- Threaded Internal Pipe 1St End
- Connection Style [AHNC]
- Plain,Optional End(Pipe) 1St End
- Nominal Pipe Size Accommodated [AAAR]
- 2.000 Inches 1St End
- Thread Series Designator [THSD]
- Anpt 1St End
- Nominal Thread Size [CQJX]
- 2.000 Inches 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Bonnet Type [ADSR]
- Inside Screw
- Bonnet Attachment Method [ADST]
- Union
- Features Provided [CBBL]
- Bonnet Packing
Similar Supply Items to 4820-00-319-4336
Freight Information 4820-00-319-4336
4820-00-319-4336 has freight characteristics.. 4820-00-319-4336 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
