4820-00-262-1098
Check Valve
4820002621098 002621098 MIL-DTL-7899 MS28882A-10 MS28882-10
A valve permitting flow in one direction only. It does not have a stem, except when equipped with a lever and weight and has no pressure adjustment. It may be inline or cartridge (manifold) design. View more Check Valve
May 2023
9
Marketplace 4820-00-262-1098
Request a Quotation from participating marketplace vendors
Related Documents 4820-00-262-1098 5+ Documents (More...)
RQST NE Updated Every Day 4820-00-262-1098 RQST Updated Every Day 4820-00-262-1098 RQST NE Related Documents
4820-00-262-1098 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-262-1098
Check Valve 4820002621098 002621098 Check Valve 4820000138904000138904 Upgrade for $1 a day Upgrade
-218-4607 Check Valve 4820012184607 012184607 MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL-7899
Upgrade for $1 a day Upgrade your Account Upgrade 4820-00-262-1098Check Valve4820002621098 002621098
MIL-DTL-7899 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-00-288-8916 Check Valve 4820002888916
Check Valve 4820002621098 002621098 Upgrade for $1 a day Upgrade your Account Upgrade 4820-00-262
-1098Check Valve4820002621098 002621098 MIL-DTL-7899 Upgrade for $1 a day Upgrade your Account https/
218 -4607 Check Valve 4820012184607 012184607 MIL-V-7899 VALVE,CHECK 5 EA NS Request Quotation MIL-DTL-7899
https//www.nsnlookup.com / fsg-48/fsc MIL-DTL-7899 VALVE,CHECK 1 EA NS Request Quotation MS28883
Restrictions 4820-00-262-1098
4820-00-262-1098 is a Check Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4820-00-262-1098
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-00-262-1098
- US Army (A920)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- A181
- US Navy (N9BC)
- Effective Date:
- 1 Sep 2004
- Brazil (YA01)
- Effective Date:
- 1 Nov 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4820-00-262-1098
- Part Number
- Manufacturer
- Status
- MS28882A-10
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-7899
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MS28882-10
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4820-00-262-1098
- Characteristic
- Specifications
- FIIG
- Specifications
- A530B0
- Connection Style [AHNC]
- Gasket Seal (Boss) All Ends
- Connection Type [AWLS]
- Threaded Internal Boss All Ends
- Disk Loading Method [ADSU]
- Spring
- Flow Control Device [ADQU]
- Disk
- Material [MATT]
- Aluminum Alloy Overall
- Maximum Operating Temp [AEHZ]
- 160.0 Deg Fahrenheit Single Response
- Maximum Operating Pressure [CQGM]
- 60.0 Pounds Per Square Inch Single Response
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Mounting Position [BBJX]
- Horizontal Or Vertical
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.625 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.875 Inches All Ends
- Valve Operation Method [AQLR]
- Automatic
- Style Designator [STYL]
- Straight Thru
- Surface Treatment [SFTT]
- Anodize
- Thread Class [AAJD]
- 3B All Ends
- Thread Direction [AAJF]
- Right-Hand All Ends
- Thread Series Designator [THSD]
- Unjf All Ends
DLA Procurement Analysis 4820-00-262-1098
Management Data 4820-00-262-1098
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4820-00-262-1098
Freight Information 4820-00-262-1098
4820-00-262-1098 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-00-262-1098 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-00-262-1098 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4820-00-262-1098 is not classified as a special type of cargo when transported by water. 4820-00-262-1098 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-00-262-1098
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 4820-00-262-1098 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
