4820-00-036-1401
Valve Seat
4820000361401 000361401 A4262
A replaceable item designed to provide a stationary seating surface for a mating, moveable item such as a valve disk or the like. The body may have a flange of various shapes. For diesel and gasoline reciprocating engines, see INSERT, ENGINE VALVE SEAT. View more Valve Seat
May 2023
18
Marketplace 4820-00-036-1401
Request a Quotation from participating marketplace vendors
Related Documents 4820-00-036-1401 5+ Documents (More...)
Day 4820-00-036-1401 RQST Updated Every Day 4820-00-036-1401 RQST NE Related Documents 4820-00-036-1401
,A4262 A4262 A replaceable item designed to provide a stationary seating surface for a mating, moveable
... ) https//www.nsnlookup.com /fsg-43/fsc-4330/us 4330-01-109-9624 Element 4330011099624011099624,A4262
... ) https//www.nsnlookup.com /fsg-43/fsc-4330/us 4330-01-109-9624 Element 4330011099624011099624,A4262
) https//www.nsnlookup.com /fsg-62/fsc-6210/ca 6210-21-851-7118 Light Lens 6210218517118218517118,A4262
Valve Seat 4820000361401 000361401,A4262 AssyUOMTechnical DocumentQuantative ExpressionDefense
Restrictions 4820-00-036-1401
4820-00-036-1401 is a Valve Seat that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4820-00-036-1401
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-00-036-1401
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Italy (ZR01)
- Effective Date:
- 1 Jun 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4820-00-036-1401
- Part Number
- Manufacturer
- Status
- A4262
- Manufacturer
- 33547 - Kieley And Mueller Inc Sub Of (Obsolete)
- Primary Buy
- Primary Buy
Datasheet 4820-00-036-1401
- Characteristic
- Specifications
- FIIG
- Specifications
- A15500
- Body Inside Diameter [ADAS]
- 0.688 Inches Nominal
- Body Outside Diameter [ADAR]
- 0.938 Inches Nominal
- Flange Diameter [ABKK]
- 1.250 Inches Nominal
- Flange Seat To Disk End Height [AJRF]
- 0.281 Nominal Inches
- Material [MATT]
- Copper Alloy Overall
- Nominal Thread Size [CQJX]
- 1.000 Inches Single Threaded Portion
- Seating Surface Shape [CQKM]
- Flat
- Under Flange Height [AJRM]
- 0.250 Inches Nominal
- Thread Class [AAJD]
- 3A Single Threaded Portion
- Thread Length [AASA]
- 0.250 Inches Nominal Single Threaded Portion
- Thread Quantity Per Inch [CMLP]
- 16 Single Threaded Portion
- Thread Series Designator [THSD]
- Un Single Threaded Portion
DLA Procurement Analysis 4820-00-036-1401
Management Data 4820-00-036-1401
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Aug 1980
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- F
- When Exhausted Use 4820-00-142-1382
- F
Similar Supply Items to 4820-00-036-1401
Freight Information 4820-00-036-1401
4820-00-036-1401 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-00-036-1401 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-00-036-1401 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4820-00-036-1401 is not classified as a special type of cargo when transported by water. 4820-00-036-1401 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 4820-00-036-1401 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
