4810-01-194-6795
Solenoid Valve
4810011946795 011946795 153D8047 AFL77C-73 153D8047 PART 1 AFL77C-73-1
A valve having two or more ports with valve stem or pilot needle in a normally open or closed position. It is specifically designed to stop or start or change the flow of fluid by means of the magnetic action of an electric coil on a moveable core or plunger. The valve may be equipped with a manual opening or closing device. For items with three or more ports that utilize a reciprocating slide with recess areas which mate with ports in an integral or replaceable ported sleeve, see VALVE (1), LINEAR, DIRECTIONAL CONTROL. It may be inline or cartridge (manifold) design. Excludes VALVE (1), BUTTERFLY. View more Solenoid Valve
May 2023
7
Marketplace 4810-01-194-6795
Request a Quotation from participating marketplace vendors
Related Documents 4810-01-194-6795 5+ Documents (More...)
/fsg-48/fsc-4810/us
AFL77C-73 VALVE,SOLENOID RQST NS Request Quotation AFL77C-73-1 VALVE,SOLENOID RQST NS Request Quotation
Subscribe to View Vendor Details... 153D8047 VALVE,SOLENOID 3 EA NS Request Quotation AFL77C-73 VALVE
/fsg-73/fsc-7320/uk
/fsg-73/fsc-7320/uk
/fsg-73/fsc-7310/no
/fsg-84/fsc-8445/ca
Restrictions 4810-01-194-6795
4810-01-194-6795 is a Solenoid Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4810-01-194-6795
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4810-01-194-6795
- US Navy (N9BC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- KE
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4810-01-194-6795
- Part Number
- Manufacturer
- Status
- AFL77C-73
- Manufacturer
- 70236 - Tactair Fluid Controls Inc (Active)
- Primary Buy
- Primary Buy
- 153D8047 PART 1
- 89954 - Bae Systems Controls Inc. (Active)
- Secondary Buy
- Secondary Buy
- AFL77C-73-1
- 99215 - Kaiser Fluid Technologies Inc. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- AFL77C-73
- 99215 - Kaiser Fluid Technologies Inc. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 153D8047
- 89954 - Bae Systems Controls Inc. (Active)
- Related Drawing
- Related Drawing
Datasheet 4810-01-194-6795
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Connection Style [AHNC]
- Flared (Tube) All Ends
- Connection Type [AWLS]
- Threaded External Tube All Ends
- Current Rating In Amps [AMPS]
- 1.000
- Flow Control Device Normal Operation Position [ADSK]
- Universal
- Flow Control Device [ADQU]
- Disk
- Material [MATT]
- Steel Corrosion Resisting Body
- Maximum Operating Temp [AEHZ]
- 167.0 Deg Fahrenheit Single Response
- Maximum Operating Pressure [CQGM]
- 40.0 Pounds Per Square Inch Single Response
- Media For Which Designed [MEDA]
- Oxygen, Gaseous 2Nd Response
- Media For Which Designed [MEDA]
- Air 1St Response
- Mounting Position [BBJX]
- Horizontal
- Nominal Thread Size [CQJX]
- 0.438 Inches All Ends
- Seat Angle [CQRB]
- 37.0 Degrees All Ends
- Special Features [FEAT]
- 150 Micron Screens Both Ports
- Valve Operation Method [AQLR]
- Solenoid
- Voltage In Volts And Current Type [CSBH]
- 24.0 Dc And 30.0 Dc
- Style Designator [STYL]
- Straight Thru
- Thread Class [AAJD]
- 3A All Ends
- Thread Direction [AAJF]
- Right-Hand All Ends
- Thread Series Designator [THSD]
- Unj All Ends
- Thread Quantity Per Inch [CMLP]
- 20 All Ends
Weapon Systems (WSDC) 4810-01-194-6795
DLA Procurement Analysis 4810-01-194-6795
Management Data 4810-01-194-6795
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4810-01-194-6795
Freight Information 4810-01-194-6795
4810-01-194-6795 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4810-01-194-6795 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4810-01-194-6795 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4810-01-194-6795 is not classified as a special type of cargo when transported by water. 4810-01-194-6795 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4810-01-194-6795
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
