4730-01-506-7089
Union Thread Piece
4730015067089 015067089 H849T-12-CUNI-L H849T-8-CUNI-LW
A fitting used with a union nut and a tailpiece to form a union. View more Union Thread Piece
May 2023
5
Marketplace 4730-01-506-7089
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-506-7089 4+ Documents (More...)
United States (US) 4. 4730-01-506-7089 Marketplace Restrictions Approved Sources Datasheet Management
BUY NE FedMall Updated Every Day 4730-01-506-7089 RQST NE Updated Every Day 4730-01-506-7089 RQST
Union Thread Piece 4730015067089 015067089 your Account Upgrade 4730-01-506-7089Union Thread Piece4730015067089
015067089 H849T-12-CUNI-L H849T-8-CUNI RQST NE Updated Every Day 4730-01-506-7089 RQST https//www.nsnlookup.com
Union Thread Piece 4730015067089 015067089 $1 a day Upgrade your Account Upgrade 4730-01-506-7089Union
Thread Piece4730015067089 015067089 H849T-12-CUNI www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-506-
Union Thread Piece 4730015067089 015067089 fsc-4730/us 4730-01-509-8478 Union Thread Piece 4730015098478
Restrictions 4730-01-506-7089
4730-01-506-7089 is a Union Thread Piece that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4730-01-506-7089
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HDJB
Approved Sources 4730-01-506-7089
- Part Number
- Manufacturer
- Status
- H849T-8-CUNI-LW
- Manufacturer
- 99565 - Admiral Valve Llc (Active)
- Primary Buy
- Primary Buy
- H849T-12-CUNI-L
- 99565 - Admiral Valve Llc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4730-01-506-7089
- Characteristic
- Specifications
- FIIG
- Specifications
- T385-Q
- End Connection Type [AWZY]
- Brazed
- Bulkhead Feature [CGNH]
- Not Provided
- Material [MATT]
- Copper Alloy 706
- Part Name Assigned By Controlling Agency [CXCY]
- Union-Tube To Tube Body Only
- Male End Feature [CGNC]
- Not Included
- Seat Type [BYJF]
- Recessed Face
- Overall Length [ABHP]
- 0.9375 Inches Nominal
- Special Features [FEAT]
- Equiped With Lockwire Hole; Connection Can Be Brazed Or Welded
- Tubing Outside Diameter [AQRX]
- 0.500 Inches Nominal
- Union End Screw Thread Series Designator [CGNF]
- Un
- Union End Thread Direction [CGNG]
- Right-Hand
- Union End Thread Size [CGND]
- 13/16-16
DLA Procurement Analysis 4730-01-506-7089
Management Data 4730-01-506-7089
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4730-01-506-7089
Freight Information 4730-01-506-7089
4730-01-506-7089 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4730-01-506-7089 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. 4730-01-506-7089 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-01-506-7089 is not classified as a special type of cargo when transported by water. 4730-01-506-7089 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-01-506-7089
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 4730-01-506-7089 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
