4730-01-305-8651
Pipe To Tube Straight Adapter
4730013058651 013058651 F-11 SCD-092
An adapter having standard pipe threads on one end or an unthreaded end designed to accommodate a pipe. The other end has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube or is unthreaded and designed to accommodate a tube. It is designed to join a pipe or pipe fitting to a tube or tube fitting in a straight line. View more Pipe To Tube Straight Adapter
May 2023
7
Marketplace 4730-01-305-8651
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-305-8651 5+ Documents (More...)
F-11 ADAPTER,STRAIGHT,PIPE TO TUBE 371 EA NS Request Quotation Updated Every Day 4730-01-305-8651 RQST
NE Updated Every Day 4730-01-305-8651 RQST Updated Every Day 4730-01-305-8651 RQST NE Related Documents
Restrictions 4730-01-305-8651
4730-01-305-8651 is a Pipe To Tube Straight Adapter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4730-01-305-8651
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-01-305-8651
- National Security Agency (DGX1)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- DAX1
- Supplementary Receivers:
- AX
- Poland (WP01)
- Effective Date:
- 1 Aug 2007
- Germany (ZG01)
- Effective Date:
- 1 Dec 1995
Approved Sources 4730-01-305-8651
- Part Number
- Manufacturer
- Status
- F-11
- Manufacturer
- 16166 - Western Enterprises Div Of Scott And (Active)
- Primary Buy
- Primary Buy
- SCD-092
- 98749 - Sacramento Air Logistics Center (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4730-01-305-8651
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- Material [MATT]
- Copper Alloy 360 Overall
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Connection Type [AWLS]
- Threaded Internal Pipe 2Nd End
- Connection Style [AHNC]
- Plain (Tube) 1St End
- Connection Style [AHNC]
- Plain (Pipe) 2Nd End
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.250 Inches 1St End
- Thread Series Designator [THSD]
- Unf 1St End
- Thread Series Designator [THSD]
- Npt 2Nd End
- Nominal Thread Size [CQJX]
- 0.437 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.125 Inches 2Nd End
- Thread Class [AAJD]
- 2B 1St End
- Nominal Overall Length [CWFR]
- 1.187 Inches
DLA Procurement Analysis 4730-01-305-8651
Management Data 4730-01-305-8651
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Aug 2020
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4730-01-305-8651
Freight Information 4730-01-305-8651
4730-01-305-8651 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4730-01-305-8651 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. 4730-01-305-8651 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-01-305-8651 is not classified as a special type of cargo when transported by water. 4730-01-305-8651 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-01-305-8651
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 9.5" H x 3.0" W x 3.0" L
- --
- --
- --
- Any Suitable Process
- 9.5" H x 3.0" W x 3.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 4730-01-305-8651 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
