4730-01-256-9023
Union Nut
4730012569023 012569023 8431343 SS-60-3 8431343-2
An internally threaded nut which has an internal seat or shoulder designed to engage the nut retaining flange of a union tailpiece. The threaded portion is used to engage the thread piece of a union, union elbor or the like. Excludes NUT (1), TUBE COUPLING. View more Union Nut
November 2023
6
Marketplace 4730-01-256-9023
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-256-9023 5+ Documents (More...)
SS-60-3 NUT,UNION 10 EA NS Request Quotation Updated Every Day 4730-01-256-9023 RQST NE Updated Every
1+ Documents ( More... ) https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-256-9023 Union Nut 4730012569023
Restrictions 4730-01-256-9023
4730-01-256-9023 is a Union Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4730-01-256-9023
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-01-256-9023
- US Army (A920)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- BD
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- FXAX
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Supplementary Collaborators:
- HD
Approved Sources 4730-01-256-9023
- Part Number
- Manufacturer
- Status
- SS-60-3
- Manufacturer
- 16166 - Western Enterprises Div Of Scott And (Active)
- Primary Buy
- Primary Buy
- 8431343-2
- 98752 - Warner Robins Air Logistics Center (Active)
- Secondary Buy
- Secondary Buy
- 8431343
- 98752 - Warner Robins Air Logistics Center (Active)
- Related Drawing
- Related Drawing
Datasheet 4730-01-256-9023
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Thread Series [BZRR]
- Ngo
- Nominal Thread Size [CQJX]
- 1.030 Inches
- Thread Quantity Per Inch [CMLP]
- 14
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Left-Hand
- Material [MATT]
- Steel Corrosion Resisting Overall
- Material Document And Classification [MDCL]
- Astm A582,Ty 303,Cond A Assn Std Single Material Response Overall
- Surface Treatment [SFTT]
- Passivate Overall
- Surface Treatment Document And Classification [STDC]
- Qq-P-35,Ty 4 Fed Spec Single Treatment Response Overall
- Nut Style [ACTA]
- Hexagon
- Nut Height [ADEA]
- 1.072 Inches Nominal
- Width Across Flats [ASDB]
- 1.250 Inches Nominal
- Smallest Inside Diameter [BSPX]
- 0.758 Inches Nominal
- Shoulder Step Width [CFQB]
- 0.187 Inches Nominal
- Shoulder Seat Diameter [CFQC]
- 0.960 Inches Nominal
Weapon Systems (WSDC) 4730-01-256-9023
DLA Procurement Analysis 4730-01-256-9023
- Last Stock Position:
- 38 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-01-256-9023
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- DM
- Surface-to-Air Missiles
Air-to-Air Stinger(ATAS)
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4730-01-256-9023
Freight Information 4730-01-256-9023
4730-01-256-9023 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 4730-01-256-9023 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 4730-01-256-9023 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 573 for ocean manifesting and military sealift. 4730-01-256-9023 is not classified as a special type of cargo when transported by water. 4730-01-256-9023 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-01-256-9023
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 4730-01-256-9023 1 Records
Contracting Technical Data File (CTDF) 4730-01-256-9023 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
