4730-01-255-1410
Sediment Strainer
4730012551410 012551410 851-2.5IN-Y-BRZ AN-2.5-851-Q AN-2.5-851-P
A strainer having inlet and outlet connections and designed to be connected in a pipe, tube or hose line. View more Sediment Strainer
May 2023
4
Marketplace 4730-01-255-1410
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-255-1410 5+ Documents (More...)
(Identification) 1/3 NSN 4730-01-255-1410 (Identification) 2/3 NSN 4730-01-255-1410 (Identification
BUY NE FedMall Updated Every Day 4730-01-255-1410 RQST NE Updated Every Day 4730-01-255-1410 RQST
Sediment Strainer 4730012551410 012551410 Upgrade 4730-01-255-1410Sediment Strainer4730012551410 012551410
851-2.5IN-Y-BRZ AN-2.5-851-Q AN-2.5-851-P RQST NE Updated Every Day 4730-01-255-1410 RQST https//www.nsnlookup.com
Upgrade 4730-01-255-1410Sediment Strainer4730012551410 012551410 851-2.5IN-Y-BRZ AN-2.5-851-Q AN
Sediment Strainer 4730012551410 012551410 Upgrade 4730-01-255-1410Sediment Strainer4730012551410
4730-01-356-6869 Sediment Strainer 4730013566869 https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-255-1410
Sediment Strainer 4730012551410 012551410 -Q AN-2.5-851-P A strainer having inlet and outlet connections
012551410 851-2.5IN-Y-BRZ AN-2.5-851-Q AN-2.5-851-P strainer having inlet and outlet connections and
designed to be connected in a pipe -P PIECE 3 AN-2.5-851-P Sediment Strainer 4730012484283012484283
Restrictions 4730-01-255-1410
4730-01-255-1410 is a Sediment Strainer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4730-01-255-1410
- US Navy (N9BC)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
Approved Sources 4730-01-255-1410
- Part Number
- Manufacturer
- Status
- AN-2.5-851-Q
- Manufacturer
- 76588 - Core Industries Inc. (Active)
- Primary Buy
- Primary Buy
- 851-2.5IN-Y-BRZ
- 76588 - Core Industries Inc. (Active)
- Advisory Reference
- Advisory Reference
- AN-2.5-851-P
- 76588 - Core Industries Inc. (Active)
- Informational Drawing
- Informational Drawing
Datasheet 4730-01-255-1410
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Distance From Bottom Of Body To Center Of Inlet [CSKY]
- 7.438 Inches Nominal
- Body Length [ADAQ]
- 10.625 Inches Nominal
- Filtering Media Design [CRXW]
- Perforated Single Filtering Media Response
- First Discharge Connection Relationship To Intake Connection [CSJR]
- Identical To First Intake Connection
- First Intake Connection Type [CRXZ]
- Recessed Flange Line
- First Intake Flange Face Style [CTBJ]
- Recessed
- First Intake Flange Outside Diameter [CSRH]
- 6.125 Inches Nominal
- First Intake Flange Recess Depth [CXNQ]
- 0.062 Inches Nominal
- First Intake Flange Recess Diameter [CXBM]
- 2.710 Inches Nominal
- First Intake Flange Thickness [CTHJ]
- 0.938 Inches Nominal
- First Intake Flange Shape Style [CSTD]
- Round W/Unthreaded Bolt Holes
- Material [MATT]
- Copper Alloy Body
- Material [MATT]
- Steel Comp 304 Filtering Medium
- Media For Which Designed [MEDA]
- Water
- Mounting Type [AAXX]
- Inlet Connection Line And Outlet Connection Line
- Style Designator [STYL]
- Y Strainer W/Bolted Cover
- Perforation Diameter [AKSV]
- 0.045 Inches Nominal
- Perforation Quantity [AKSW]
- 225.0 Per Square Inch
Weapon Systems (WSDC) 4730-01-255-1410
DLA Procurement Analysis 4730-01-255-1410
Management Data 4730-01-255-1410
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4730-01-255-1410
Freight Information 4730-01-255-1410
4730-01-255-1410 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052440. A Sub NMFC of X. It has a NMFC Description of STRAINERS PIPE LINE I/S BODY. 4730-01-255-1410 is rated as class 60 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 30350 which rates the freight between FCL and LCL. 4730-01-255-1410 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-01-255-1410 is not classified as a special type of cargo when transported by water. 4730-01-255-1410 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-01-255-1410
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 4730-01-255-1410 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
