4730-01-245-8546
Pipe Elbow
4730012458546 012458546 BSL-4HP 1426AS124-1
A fitting that forms an angle of less than 180 degrees (3.141 radians) from the straight flow. Both connecting ends have standard pipe threads or are unthreaded and designed to accommodate a pipe. It may have side or heel inlet(s). See also ELBOW, TUBE; and CONNECTOR, MULTIPLE, FLUID PRESSURE LINE. Excludes BEND, SOIL PIPE. View more Pipe Elbow
November 2023
7
Marketplace 4730-01-245-8546
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-245-8546 5+ Documents (More...)
United States (US) 4. 4730-01-245-8546 Marketplace Restrictions Approved Sources Datasheet Management
BSL-4HP ELBOW,PIPE 10 EA NS Request Quotation Updated Every Day 4730-01-245-8546 RQST NE Updated Every
Restrictions 4730-01-245-8546
4730-01-245-8546 is a Pipe Elbow that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4730-01-245-8546
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-01-245-8546
- US Army (A920)
- Effective Date:
- 1 Oct 2010
- Supplementary Receivers:
- BF
- US Marine Corps (MC40)
- Effective Date:
- 1 Oct 2009
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTKE
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 1998
Approved Sources 4730-01-245-8546
- Part Number
- Manufacturer
- Status
- BSL-4HP
- Manufacturer
- 16166 - Western Enterprises Div Of Scott And (Active)
- Primary Buy
- Primary Buy
- 1426AS124-1
- 30003 - Naval Air Systems Command Managed (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 4730-01-245-8546
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- Connection Style [AHNC]
- Gasket Seal (Pipe) 2Nd End
- Connection Style [AHNC]
- Swivel Nut, Gasket Seal (Pipe) 1St End
- Connection Type [AWLS]
- Threaded External Pipe 2Nd End
- Connection Type [AWLS]
- Threaded Internal Pipe 1St End
- Fsc Application Data [ZZZV]
- Oxygen Servicing Cart
- Material [MATT]
- Copper Alloy Overall
- Maximum Operating Temp [AEHZ]
- 160.0 Deg Fahrenheit Single Response
- Maximum Operating Pressure [CQGM]
- 3000.0 Pounds Per Square Inch Single Response
- Nominal Thread Size [CQJX]
- 0.250 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.250 Inches 2Nd End
- Thread Series Designator [THSD]
- Npt 2Nd End
- Thread Series Designator [THSD]
- Npt 1St End
Weapon Systems (WSDC) 4730-01-245-8546
DLA Procurement Analysis 4730-01-245-8546
- Last Stock Position:
- 6 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-01-245-8546
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material ID:
- SX
- Special Aircraft and Engine Tool and Support Equipment/Parts
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
- Physical Category:
- 1
- Bin
Similar Supply Items to 4730-01-245-8546
Freight Information 4730-01-245-8546
4730-01-245-8546 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051630. A Sub NMFC of Z. It has a NMFC Description of PIPE R DUCT ETC. 4730-01-245-8546 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4730-01-245-8546 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 29892 which rates the freight between FCL and LCL. 4730-01-245-8546 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-01-245-8546 is not classified as a special type of cargo when transported by water. 4730-01-245-8546 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-01-245-8546
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Procurement History 4730-01-245-8546 2 Records
Contracting Technical Data File (CTDF) 4730-01-245-8546 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
