4730-01-119-9044
Tube Tee
4730011199044 011199044 023-10674 H810-4S
A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The connections have machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or are unthreaded and designed to accommodate a tube. It may have side inlet(s). It is used as a junction at the intersection of a tube or tube fitting. View more Tube Tee
November 2023
13
Marketplace 4730-01-119-9044
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-119-9044 3+ Documents (More...)
Photo 1/2 4730-01-119-9044 Photo 2/2 - - 1.
4730-01-119-9044 RQST Updated Every Day 4730-01-119-9044 RQST NE Related Documents 4730-01-119-9044
Restrictions 4730-01-119-9044
4730-01-119-9044 is a Tube Tee that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4730-01-119-9044
- US Navy (N9BC)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTJBHD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Jan 2015
Approved Sources 4730-01-119-9044
- Part Number
- Manufacturer
- Status
- H810-4S
- Manufacturer
- 99565 - Admiral Valve Llc (Active)
- Primary Buy
- Primary Buy
- 023-10674
- 66935 - Johnson Controls Navy Systems, Llc (Active)
- Secondary Buy
- Secondary Buy
- H810-4S
- 99569 - Gould Engineering And Sales Co Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4730-01-119-9044
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- Connection Style [AHNC]
- Plain (Tube) All Ends
- Connection Type [AWLS]
- Threaded External Tube All Ends
- Furnished Items And Quantity [TMQY]
- 3 Tube Coupling Nut And 3 Preformed Packing And 3 Tailpiece
- Material [MATT]
- Rubber Synthetic Gasket
- Material [MATT]
- Steel Nut
- Material [MATT]
- Steel Tailpiece
- Material [MATT]
- Steel Tee
- Maximum Operating Pressure [CQGM]
- 3000.0 Pounds Per Square Inch Single Response
- Media For Which Designed [MEDA]
- Fluid Single Response
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.250 Inches All Ends
- Nominal Thread Size [CQJX]
- 0.437 Inches All Ends
- Leg Length [AHSJ]
- 1.187 Inches Nominal All Ends
- Union Joint Location [CRDL]
- First End And Second End And Third End
- Surface Treatment [SFTT]
- Zinc Tailpiece
- Surface Treatment [SFTT]
- Zinc Tee
- Surface Treatment [SFTT]
- Zinc Nut Or Cadmium Nut
- Thread Class [AAJD]
- 2A All Ends
- Thread Series Designator [THSD]
- Unf All Ends
Weapon Systems (WSDC) 4730-01-119-9044
DLA Procurement Analysis 4730-01-119-9044
- Last Stock Position:
- 1 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-01-119-9044
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4730-01-119-9044
Freight Information 4730-01-119-9044
4730-01-119-9044 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4730-01-119-9044 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. 4730-01-119-9044 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-01-119-9044 is not classified as a special type of cargo when transported by water. 4730-01-119-9044 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 4730-01-119-9044 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
