4730-01-109-7971
Pipe To Tube Tee
4730011097971 011097971 11669685
A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The pipe connection(s) has standard pipe threads, or is unthreaded and designed to accommodate a pipe. The tube connection(s) has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or is unthreaded and designed to accommodate a tube. It may have side inlet(s). It is used as a junction at the intersection of pipe or pipe fitting and a tube or tube fitting. View more Pipe To Tube Tee
July 2025
21
Marketplace 4730-01-109-7971
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-109-7971 1+ Documents (More...)
United States (US) 4. 4730-01-109-7971 Marketplace Restrictions Approved Sources Datasheet Management
TEE,PIPE TO TUBE RQST NS Request Quotation Subscribe to View Vendor Details... 11669685 TEE,PIPE TO
Restrictions 4730-01-109-7971
4730-01-109-7971 is a Pipe To Tube Tee that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4730-01-109-7971
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-01-109-7971
- US Army (A920)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXAX
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Morocco (YP01)
- Effective Date:
- 1 Dec 2011
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Oct 2000
Approved Sources 4730-01-109-7971
- Part Number
- Manufacturer
- Status
- 11669685
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 11669685
- 01276 - Danfoss Power Solutions Ii, Llc (Active)
- Secondary Buy
- Secondary Buy
- 11669685
- 79470 - Dana Corp Weatherhead Div (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 4730011097971
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 4730011097971
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 4730-01-109-7971
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- Material [MATT]
- Steel Comp 316 Overall
- Connection Type [AWLS]
- Threaded External Tube 1St End
- Connection Type [AWLS]
- Threaded External Tube 2Nd End
- Connection Type [AWLS]
- Threaded Internal Pipe 3Rd End
- Connection Style [AHNC]
- Flareless (Tube) 1St End
- Connection Style [AHNC]
- Flareless (Tube) 2Nd End
- Connection Style [AHNC]
- Plain (Pipe) 3Rd End
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.250 Inches 1St End
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.250 Inches 2Nd End
- Thread Series Designator [THSD]
- Unjf 1St End
- Thread Series Designator [THSD]
- Unjf 2Nd End
- Thread Series Designator [THSD]
- Nptf 3Rd End
- Nominal Thread Size [CQJX]
- 0.437 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.437 Inches 2Nd End
- Nominal Thread Size [CQJX]
- 0.250 Inches 3Rd End
- Thread Class [AAJD]
- 3A 1St End
- Thread Class [AAJD]
- 3A 2Nd End
- Leg Length [AHSJ]
- 0.453 Inches Nominal 1St End
- Leg Length [AHSJ]
- 0.453 Inches Nominal 2Nd End
- Leg Length [AHSJ]
- 0.880 Inches Nominal 3Rd End
Weapon Systems (WSDC) 4730-01-109-7971
