4730-01-006-0948
Fluid Flow Restrictor Unit
4730010060948 010060948 5620-2-125
An assembly consisting of an orifice in a fixed plate, disk, or tube with screens or filters on one or both sides, depending on the direction of filtered flow. See RESTRICTOR, FLUID FLOW. View more Fluid Flow Restrictor Unit
November 2023
11
Marketplace 4730-01-006-0948
Request a Quotation from participating marketplace vendors
Related Documents 4730-01-006-0948 2+ Documents (More...)
4730-01-006-0948 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-006-0948
Fluid Flow Restrictor Unit 4730010060948 Updated Every Day 4730-01-006-0948 RQST Updated Every Day 4730
/us 4730-00-397-3108 Fluid Flow Restrictor Unit https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-006-0948
Fluid Flow Restrictor Unit 4730010060948 Day 4730-01-006-0948 RQST NE Related Documents https//
Restrictions 4730-01-006-0948
4730-01-006-0948 is a Fluid Flow Restrictor Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4730-01-006-0948
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-01-006-0948
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- FXAX
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
Approved Sources 4730-01-006-0948
- Part Number
- Manufacturer
- Status
- 5620-2-125
- Manufacturer
- 76301 - The Boeing Company (Active)
- Primary Buy
- Primary Buy
- 5620-2-125
- 18355 - The Boeing Company (Active)
- Secondary Buy
- Secondary Buy
Datasheet 4730-01-006-0948
- Characteristic
- Specifications
- FIIG
- Specifications
- T359-C
- End Connection Component Type And Size For Which Designed [CFPS]
- 1/4 In. Od
- End Connection Similarity [AXAL]
- Identical
- End Connection Type [AWZY]
- Threaded Male
- Body Material [AAFZ]
- Cres 17-4Ph Pep Ams5643
- Compression Type [ANKB]
- Gasket Seal
- Design Type [APGF]
- Straight
- Diameter [ABMZ]
- 0.800 Inches Nominal
- Operating Temp Range [AFGA]
- +60.0 To 120.0 Deg Fahrenheit
- Orifice Diameter [AMSF]
- 0.172 Inches Maximum
- Pressure Rating [BGST]
- 3000.0 Pounds Per Square Inch Nominal
- Screening Material [AQJQ]
- Steel, Fed Std 66, Aisi 304/Sae 30304
- Overall Length [ABHP]
- 1.695 Inches Nominal
- Packing Material [ADQT]
- Rubber, Synthetic Or Plastic
- Valve Size [CCFG]
- 0.438 Inches
- Width Across Flats [ASDB]
- 0.812 Inches Nominal
- Strainer Type And Quantity [BZTM]
- 2 Screen
- Surface Treatment [SFTT]
- Passivated Per Qq-P-35
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Uns
- Thread Size Designator [ABVK]
- 7/16-24
Weapon Systems (WSDC) 4730-01-006-0948
DLA Procurement Analysis 4730-01-006-0948
- Last Stock Position:
- 2 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-01-006-0948
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4730-01-006-0948
Freight Information 4730-01-006-0948
4730-01-006-0948 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4730-01-006-0948 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. 4730-01-006-0948 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-01-006-0948 is not classified as a special type of cargo when transported by water. 4730-01-006-0948 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-01-006-0948
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
Procurement History 4730-01-006-0948 17 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7M121V8058
- 07 Jun 2021
- Subscribe
- 30
- Subscribe
- Subscribe
- Subscribe
- SPE7M018V9937
- 23 Jul 2018
- Subscribe
- 3
- Subscribe
- Subscribe
- Subscribe
- SPE7M318V4350
- 14 Jun 2018
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M318P4438
- 04 Jun 2018
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE7M018V6504
- 10 Apr 2018
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M018V5518
- 15 Mar 2018
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M317P2137
- 26 Mar 2017
- Subscribe
- 5
- Subscribe
- Subscribe
- Subscribe
- SPE7M315V5483
- 25 Aug 2015
- Subscribe
- 17
- Subscribe
- Subscribe
- Subscribe
- SPE7M015VA640
- 19 Jun 2015
- Subscribe
- 3
- Subscribe
- Subscribe
- Subscribe
- SPE7M015VA127
- 03 Jun 2015
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M315M2325
- 05 May 2015
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M315V1711
- 07 Jan 2015
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M315M0786
- 11 Dec 2014
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M314V6487
- 30 Jul 2014
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M314V6484
- 30 Jul 2014
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE7M314V4155
- 07 Apr 2014
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE7M314V3717
- 14 Mar 2014
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 4730-01-006-0948 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
