4730-00-951-3293

Quick Disconnect Reducer

4730009513293 009513293 A-A-59326/12 40CX30A AA59326/12-1-A-2 MS49000-1 DA4X3 AA59326A/12-1-A-2 AA59326XI11 633BA4X3

A straight fluid line fitting having a different size quick disconnect feature on each end, designed to couple mating quick disconnect features. Both ends may have external quick disconnect features. View more Quick Disconnect Reducer

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
November 2023

NATO Update Count
32

NATO Data Quality

4730-00-951-3293 REDUCER,QUICK DISCONNECT 4730009513293 009513293 1/1 — 4730-00-951-3293 Photo 1/1

Marketplace 4730-00-951-3293

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

MS49000-1 REDUCER,QUICK DISCONNECT 1 EA NS

Subscribe to View Vendor Details...

AA59326XI11 REDUCER,QUICK DISCONNECT 15 EA NS

Subscribe to View Vendor Details...

A-A-59326/12 REDUCER,QUICK DISCONNECT 32 EA NS

Subscribe to View Vendor Details...

AA5932612-1-A-2 REDUCER,QUICK DISCONNECT 12 EA NS

Updated Every 15 Minutes

4730-00-951-3293 BUY NE

Updated Every Day

4730-00-951-3293 RQST NE

Updated Every Day

4730-00-951-3293 RQST

Updated Every Day

4730-00-951-3293 RQST NE

Restrictions 4730-00-951-3293

4730-00-951-3293 is a Quick Disconnect Reducer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 4730-00-951-3293

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 4730-00-951-3293

US Army (A920)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZCTCE; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FXGC)
Effective Date:: 1 Apr 2006
Former MOE Rule:: FXAX; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC40)
Effective Date:: 1 Apr 2006
Former MOE Rule:: MC01; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Apr 2006
Former MOE Rule:: N9CD
Supplementary Collaborators:: GT; AMC 1 AMSC G IMC Z IMCACTY GH

Canada (ZC01)
Effective Date:: 1 Jul 1996

Germany (ZG01)
Effective Date:: 1 Jan 2015

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 2005

Approved Sources 4730-00-951-3293

Part Number
Manufacturer
Status
AA59326/12-1-A-2: 58536 - Federal Commercial Item Description (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
A-A-59326/12: 58536 - Federal Commercial Item Description (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC 6
40CX30A: 33813 - Parrish Enterprises, Ltd. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC E
MS49000-1: 81718 - Opw Fueling Components Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
MS49000-1: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
DA4X3: 24869 - Dvcc, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
AA59326A/12-1-A-2: 58536 - Federal Commercial Item Description (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
AA59326XI11: 58536 - Federal Commercial Item Description (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
MS49000-1: 24869 - Dvcc, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
633BA4X3: 81718 - Opw Fueling Components Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
MS49000-1: 9H113 - Dover Resources Inc Dba Opw (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3

Datasheet 4730-00-951-3293

Characteristic
Specifications
FIIG: A535X0
Connection Type [AWLS]: External Quick Disconnect
Furnished Items And Quantity [TMQY]: 1 Gasket
Material Document And Classification [MDCL]: Qq-A-601, T5 Fed Spec 1St Material Response Body And Qq-A-601, T5 Fed Spec 2Nd Material Response Body
Material [MATT]: Aluminum Alloy Body
Maximum Operating Pressure [CQGM]: 150.0 Pounds Per Square Inch
Quick Disconnect Method [ADLN]: Cam-Locking All Ends
Quick Disconnect Nominal Size [ADLP]: 3.000 Inches First Quick Disconnect End
Quick Disconnect Nominal Size [ADLP]: 3.000 Inches Second End
Quick Disconnect Nominal Size [ADLP]: 4.000 Inches First End
Quick Disconnect Nominal Size [ADLP]: 4.000 Inches Second Quick Disconnect End
Special Features [FEAT]: W/Cam Arms And Pins; Second End Connection Type: Internal
Specification/Standard Data [ZZZK]: 96906-Ms49000 Government Standard
Surface Treatment Document And Classification [STDC]: Mil-A-8625, Type 2, Class 1 Mil Spec Single Treatment Response Body
Surface Treatment [SFTT]: Anodize Body

Weapon Systems (WSDC) 4730-00-951-3293

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 4730-00-951-3293

Last Stock Position:: 754 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 4730-00-951-3293

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); EA; Subscribe; 1
Feb 2020: Department of the Air Force (DF); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SX: SICA RESIDUAL MMAC-OC-ALC

Price Validation Code:

V: The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

2: Non-Critical Repair Part

Echelon Management:

B2

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 4730-00-951-3293

4730-14-538-9855 4730-98-200-1245 4730-15-002-8088 4730-98-204-1568 4730-12-313-6775 4730-98-206-4221 4730-12-311-7455 4730-14-538-8949 4730-98-204-1588 4730-01-374-9496 4730-01-184-5463 4730-01-184-5462 4730-01-589-3560 4730-01-540-1892 4730-01-499-8752 4730-01-499-8687 4730-00-887-3822 4730-12-339-0880

Freight Information 4730-00-951-3293

4730-00-951-3293 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093750. A Sub NMFC of Z. It has a NMFC Description of BUNGS/PLUGS NOI IN PKGS. 4730-00-951-3293 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49080 which rates the freight between FCL and LCL. 4730-00-951-3293 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4730-00-951-3293 is not classified as a special type of cargo when transported by water. 4730-00-951-3293 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 4730-00-951-3293

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; No Requirement; Not Applicable; PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --

Procurement History 4730-00-951-3293 6 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7M317P4788: 06 Sep 2017; Subscribe; 335; Subscribe; Subscribe
SPE7M317V0567: 18 Jan 2017; Subscribe; 418; Subscribe; Subscribe
SPE7M317V0436: 16 Dec 2016; Subscribe; 310; Subscribe; Subscribe
SPE7MC16V6454: 22 Apr 2016; Subscribe; 305; Subscribe; Subscribe
SPE7M116V3060: 20 Nov 2015; Subscribe; 181; Subscribe; Subscribe
SPE7M315V4754: 22 Jun 2015; Subscribe; 210; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 4730-00-951-3293 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
