4730-00-909-0769
Tube Coupling Inverted Nut
4730009090769 009090769 A865D
An externally threaded fastening device which has an internal or external seat, designed to mate with the seat of an internally threaded tube fitting for the purpose of securing the tube to the fitting to form a leakproof connection. View more Tube Coupling Inverted Nut
January 2023
9
Marketplace 4730-00-909-0769
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-909-0769 1+ Documents (More...)
Updated Every Day 4730-00-909-0769 RQST Updated Every Day 4730-00-909-0769 RQST NE Related Documents
Tube Coupling Inverted Nut 4730009090769 A865D INVERTED NUT,TUBE COUPLING 1 EA NS Request Quotation
Restrictions 4730-00-909-0769
4730-00-909-0769 is a Tube Coupling Inverted Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4730-00-909-0769
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jun 1997
Approved Sources 4730-00-909-0769
- Part Number
- Manufacturer
- Status
- A865D
- Manufacturer
- 97484 - Eaton Aerospace Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 4730-00-909-0769
- Characteristic
- Specifications
- FIIG
- Specifications
- T385-B
- Casehardening Indicator [AASG]
- Not Casehardened
- Fabrication Method [AARN]
- Any Acceptable
- Material [MATT]
- Aluminum Alloy
- Screw Thread Series Designator [AJYP]
- Unf
- Smallest Inside Diameter [BSPX]
- 0.750 Inches Nominal
- Overall Length [ABHP]
- 1.906 Inches Nominal
- Tube Outside Diameter For Which Designed [ACSV]
- 0.312 Inches Nominal
- Width Across Flats [ASDB]
- 1.000 Inches Nominal
- Style Designator [STYL]
- Inverted Nut, Tube, Double Compression
- Surface Treatment [SFTT]
- Anodize
- Thread Class [AAJD]
- 2A
- Thread Direction [AAJF]
- Right-Hand
- Thread Size [ABUJ]
- 3/4In-16
Similar Supply Items to 4730-00-909-0769
Freight Information 4730-00-909-0769
4730-00-909-0769 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052175. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FIT. 4730-00-909-0769 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29920 which rates the freight between FCL and LCL. 4730-00-909-0769 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-909-0769 is not classified as a special type of cargo when transported by water. 4730-00-909-0769 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-909-0769
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Special Requirements
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Special requirement – See specific instructions or drawings provided
