4730-00-904-0876
Union Nut
4730009040876 009040876 EPA21000-274 A414241-3
An internally threaded nut which has an internal seat or shoulder designed to engage the nut retaining flange of a union tailpiece. The threaded portion is used to engage the thread piece of a union, union elbor or the like. Excludes NUT (1), TUBE COUPLING. View more Union Nut
November 2023
6
Marketplace 4730-00-904-0876
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-904-0876 5+ Documents (More...)
Photo 1/4 4730-00-904-0876 Photo 2/4 4730-00-904-0876 Photo 3/4 NSN 4730-00-904-0876 (Identification
A414241-3 NUT,UNION 6 EA NS Request Quotation EPA21000-274 NUT,UNION 45 EA NS Request Quotation Updated
EPA21000-274 NUT 45 EA NS Request Quotation Subscribe to View Vendor Details...
Union Nut 4730009040876 009040876 Upgrade for $1 a day Upgrade your Account Upgrade 4730-00-904
Restrictions 4730-00-904-0876
4730-00-904-0876 is a Union Nut that is specifically designed to be or selected as being nuclear hard. In addition it has other critical features such as tolerance, fit restrictions or application.This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4730-00-904-0876
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-904-0876
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTKEHD
- France (ZF01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4730-00-904-0876
- Part Number
- Manufacturer
- Status
- A414241-3
- Manufacturer
- 80020 - Naval Air Warfare Center Aircraft (Active)
- Primary Buy
- Primary Buy
- A414241-3
- 1V517 - Duhadaway Tool & Die Shop Inc (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 2M490 - Nassau Tool Works, Inc (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 30828 - Krobach Mfg. Corp. (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 3BZG7 - Nuflo, Inc. (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 6W889 - Ammcon Corp. (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 5S946 - Pre-Mach Inc (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 9U245 - Master Research & Manufacturing, (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 80206 - Naval Air Development Center (Active)
- Secondary Buy
- Secondary Buy
- A414241-3
- 07310 - Calabrese & Sons, Inc. (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- A414241-3
- 0A396 - Computa-Base-Machining, Inc. (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- EPA21000-274
- F3014 - Naval Group Site De Brest (Active)
- Related NATO Reproduction
- Related NATO Reproduction
Datasheet 4730-00-904-0876
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Material [MATT]
- Steel Corrosion Resisting Overall
- Nominal Thread Size [CQJX]
- 1.188 Inches
- Nut Height [ADEA]
- 0.938 Inches Nominal
- Nut Style [ACTA]
- Hexagon
- Material Document And Classification [MDCL]
- Il-S-6758,Cond D4 Mil Spec 10Th Material Response Overall
- Shoulder Step Width [CFQB]
- 0.250 Inches Nominal
- Shoulder Width [ABNK]
- 0.155 Inches Nominal
- Special Features [FEAT]
- Nominal Pipe Size 0.500
- Width Across Flats [ASDB]
- 1.375 Inches Nominal
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Series [BZRR]
- Un
- Thread Quantity Per Inch [CMLP]
- 12
Weapon Systems (WSDC) 4730-00-904-0876
DLA Procurement Analysis 4730-00-904-0876
- Last Stock Position:
- 481 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-00-904-0876
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material ID:
- EY
- 4R/5R Cog Items Managed by BRASO
Similar Supply Items to 4730-00-904-0876
Freight Information 4730-00-904-0876
4730-00-904-0876 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093486. A Sub NMFC of Z. It has a NMFC Description of BOLTS,NUTS OR SCREWS, NOI (SUB 3). 4730-00-904-0876 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48950 which rates the freight between FCL and LCL. 4730-00-904-0876 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-904-0876 is not classified as a special type of cargo when transported by water. 4730-00-904-0876 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-904-0876
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 4730-00-904-0876 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
