4730-00-713-5913
Tube To Boss Elbow
4730007135913 007135913 4C50XSS 0787268 8991489 4C50X-SS 1621213 2267548-3
A fitting that forms an angle of less that 180 degrees (3.141 radians) from a straight flow. One connecting end has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube or is unthreaded and designed to accommodate a tube. The other end has external or internal machine threads (straight threads other than pipe or hose series) and is designed to facilitate a gasket, preformed packing, washer, or the like, to form a seal at the boss. It may have side or heel inlet(s). It is designed to connect a tube or tube fitting to a boss or boss fitting on items such as tanks, housings, valve fittings, or the like. View more Tube To Boss Elbow
May 2023
38
Marketplace 4730-00-713-5913
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-713-5913 4+ Documents (More...)
United States (US) 4. 4730-00-713-5913 Marketplace Restrictions Approved Sources Datasheet Management
Request Quotation Updated Every Day 4C50XSS RQST NE Updated Every Day 4730-00-713-5913 RQST NE Updated
Restrictions 4730-00-713-5913
4730-00-713-5913 is a Tube To Boss Elbow that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4730-00-713-5913
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-713-5913
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Belgium (ZB01)
- Effective Date:
- 1 Nov 2006
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Nov 2009
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4730-00-713-5913
- Part Number
- Manufacturer
- Status
- 4C50XSS
- Manufacturer
- 30780 - Parker-Hannifin Corporation (Active)
- Primary Buy
- Primary Buy
- 0787268
- D0138 - Norgren Gmbh -Niederlassung (Active)
- Secondary Buy
- Secondary Buy
- 8991489
- 18876 - Us Army Aviation And Missile Command (Active)
- Secondary Buy
- Secondary Buy
- 4C50X-SS
- C2274 - Parker Hannifin Manufacturing (Active)
- Secondary Buy
- Secondary Buy
- 1621213
- 10001 - Navair And Navsea Managed Original (Active)
- Secondary Buy
- Secondary Buy
- 4C50XSS
- 98441 - Parker Hannifin Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2267548-3
- 10001 - Navair And Navsea Managed Original (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4C50XSS
- 45681 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4730-00-713-5913
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- Connection Style [AHNC]
- External Seat For Gasket Seal (Boss) 2Nd End
- Connection Style [AHNC]
- Flared (Tube) 1St End
- Connection Type [AWLS]
- Threaded External Boss 2Nd End
- Connection Type [AWLS]
- Threaded External Tube 1St End
- Furnished Items And Quantity [TMQY]
- 1 Locknut And 1 Preformed Packing And 1 Short Coupling Nut
- Flow Angle [CRFY]
- 90.0 Degrees
- Material [MATT]
- Steel Comp 316 Overall
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.250 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.438 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.438 Inches 2Nd End
- Leg Length [AHSJ]
- 0.890 Inches Nominal 1St End
- Leg Length [AHSJ]
- 1.030 Inches Nominal 2Nd End
- Material Document And Classification [MDCL]
- Aisi 316 Assn Std Single Material Response Overall
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Surface Treatment [SFTT]
- Passivate Inside
- Surface Treatment [SFTT]
- Passivate Outside
- Thread Class [AAJD]
- 2A 2Nd End
- Thread Class [AAJD]
- 3A 1St End
- Thread Series Designator [THSD]
- Unf 1St End
- Thread Series Designator [THSD]
- Unf 2Nd End
Similar Supply Items to 4730-00-713-5913
Freight Information 4730-00-713-5913
4730-00-713-5913 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4730-00-713-5913 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4730-00-713-5913 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-713-5913 is not classified as a special type of cargo when transported by water. 4730-00-713-5913 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
