4730-00-618-8126
Pipe To Tube Elbow
4730006188126 006188126 MIL-DTL-18866 8-12-CBTCX-S-C AND C J514 TC15-1096 06209400 2024-12-8S 8-12CTX-S 9018112 MS51504B8-12 2103-12-8 MS51504A8-12Z MS51504A8-12 MIL-F-18866 8-12 070202CA 8-12CBTX-S RH106801 8904944 8-12 070202C 849-FS-08X12
A fitting that forms an angle of less than 180 degrees (3.142 radians) from the straight flow. One connecting end has standard pipe threads, or is unthreaded and designed to accommodate a pipe. The other end has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or is unthreaded and designed to accommodate a tube. It may have side or heel inlet(s). See also ELBOW, PIPE; ELBOW, TUBE; and CONNECTOR, MULTIPLE, FLUID PRESSURE LINE. View more Pipe To Tube Elbow
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
September 2024
September 2024
NATO Update Count
82
82
NATO Data Quality
Marketplace 4730-00-618-8126
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
MS51504B8-12 ELBOW,PIPE TO TUBE 346 EA NS
MS51504A8-12 ELBOW,PIPE TO TUBE 315 EA NS
J514 ELBOW,PIPE TO TUBE 640 EA NS
MS51504-B8-12 ELBOW,PIPE TO TUBE 325 EA NS
MS51504-A8-12 ELBOW,PIPE TO TUBE 325 EA NS
MS51504-A8-12Z ELBOW,PIPE TO TUBE 1000 EA NS
MILF18866 ELBOW,PIPE TO TUBE RQST NS
MIL-F-18866 ELBOW,PIPE TO TUBE 143 EA NS
MIL-F-18866 ELBOW,PIPE TO TUBE 12 EA NS
MS51504A8-12 ELBOW,PIPE TO TUBE 1 EA NS
J514 ELBOW,PIPE TO TUBE 1 EA NS
MILF18866 ELBOW,PIPE TO TUBE 7 EA NS
MS51504B8-12 ELBOW,PIPE TO TUBE 1 EA NS
MS51504A8-12Z ELBOW,PIPE TO TUBE 1 EA NS
8-12CTX-S RQST NE
2103-12-8 RQST NE
8-12CBTX-S RQST NE
Updated Every Day 4730-00-618-8126 RQST NE
Updated Every Day 4730-00-618-8126 RQST
Updated Every Day 4730-00-618-8126 RQST NE
Related Documents 4730-00-618-8126 5+ Documents (More...)
MIL-DTL-18866 8-12-CBTCX-S-C AND C J514 TC15-1096 06209400 2024-12-8S 8-12CTX-S 9018112 MS51504B8-12
2103-12-8 MS51504A8-12Z MS51504A8-12 MIL-F-18866 8-12 070202CA 8-12CBTX-S RH106801 8904944 8-12 070202C
MS51504B8-12 ELBOW,PIPE TO TUBE 346 EA NS Request Quotation MS51504A8-12 ELBOW,PIPE TO TUBE 315 EA NS
2103-12-8 MS51504A8-12Z MS51504A8-12 MIL-F-18866 8-12 070202CA 8-12CBTX-S RH106801 8904944 8-12 070202C
MS51504B8-12 ELBOW,PIPE TO TUBE 346 EA NS Request Quotation MS51504A8-12 ELBOW,PIPE TO TUBE 315 EA NS
J5-14 ELBOW,PIPE TO TUBE 6 EA NS Request Quotation J514.
TUBE RQST NS Request Quotation MIL-F-18866 ELBOW,PIPE TO TUBE 143 EA NS Request Quotation MS51504-A8
Quotation MS51504A8-12 ELBOW,PIPE TO TUBE 1 EA NS Request Quotation J514 ELBOW,PIPE TO TUBE 416 EA NS
TUBE RQST NS Request Quotation MIL-F-18866 ELBOW,PIPE TO TUBE 143 EA NS Request Quotation MS51504-A8
Quotation MS51504A8-12 ELBOW,PIPE TO TUBE 1 EA NS Request Quotation J514 ELBOW,PIPE TO TUBE 416 EA NS
J514.
MS51504A8-12 ELBOW,PIPE TO TUBE 315 EA NS Request Quotation J514 ELBOW,PIPE TO TUBE 640 EA NS Request
J514 ELBOW,PIPE TO TUBE 416 EA NS Request Quotation MS51504B8-12 ELBOW,PIPE TO TUBE 1 EA NS Request Quotation
MS51504A8-12 ELBOW,PIPE TO TUBE 315 EA NS Request Quotation J514 ELBOW,PIPE TO TUBE 640 EA NS Request
J514 ELBOW,PIPE TO TUBE 416 EA NS Request Quotation MS51504B8-12 ELBOW,PIPE TO TUBE 1 EA NS Request Quotation
J514.
MS51504A8-12 ELBOW,PIPE TO TUBE 315 EA NS Request Quotation MS51504-A8-12 ELBOW,PIPE TO TUBE 325 EA NS
MS51504A8-12Z ELBOW,PIPE TO TUBE 1 EA NS Request Quotation MIL-F-18866 ELBOW,PIPE TO TUBE 12 EA NS Request
MS51504A8-12 ELBOW,PIPE TO TUBE 315 EA NS Request Quotation MS51504-A8-12 ELBOW,PIPE TO TUBE 325 EA NS
MS51504A8-12Z ELBOW,PIPE TO TUBE 1 EA NS Request Quotation MIL-F-18866 ELBOW,PIPE TO TUBE 12 EA NS Request
8-12 070202BA A fitting that forms an angle of less than 180 degrees (3.142 radians J514 ELBOW,PIPE
SAE J514 24-24 070220 https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-618-8126 Pipe To Tube Elbow
4730006188126 006188126 Elbow4730006188126 006188126 MIL-DTL-18866 8-12-CBTCX-S-C AND C J514 TC15-1096
SAE J514 24-24 070220 https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-618-8126 Pipe To Tube Elbow
4730006188126 006188126 Elbow4730006188126 006188126 MIL-DTL-18866 8-12-CBTCX-S-C AND C J514 TC15-1096
Restrictions 4730-00-618-8126
4730-00-618-8126 is a Pipe To Tube Elbow that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4730-00-618-8126
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-618-8126
- US Army (A920)
- Effective Date:
- 1 Apr 2006
- Supplementary Receivers:
- AJCTCLBFAZ
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2006
- US Marine Corps (MC40)
- Effective Date:
- 1 Apr 2006
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2006
- Supplementary Collaborators:
- GTKEHD
- Austria (WB)
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Poland (WP)
- Poland (WP01)
- Effective Date:
- 1 Oct 2006
- Brazil (YA)
- Brazil (YA01)
- Effective Date:
- 1 Sep 2000
- Spain (YB)
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Saudi Arabia (YS01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA)
- Australia (ZA01)
- Effective Date:
- 1 Jun 1997
- Belgium (ZB)
- Belgium (ZB01)
- Effective Date:
- 1 Apr 2003
- Canada (ZC)
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH)
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 1995
- Greece (ZU)
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW)
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
- United States of America (ZZ)
Approved Sources 4730-00-618-8126
- Part Number
- Manufacturer
- Status
- MS51504A8-12Z
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-18866
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 8-12-CBTCX-S-C AND C
- 59206 - Fd Johnson Co (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 8-12 070202CA
- 0U583 - Sae International (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- J514
- 0U583 - Sae International (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS51504A8-12
- 30780 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-F-18866
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS51504A8-12
- 93188 - L And L Mfg Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- MS51504A8-12
- 00624 - Eaton Aeroquip Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8-12 070202CA
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 8-12CBTX-S
- 98441 - Parker Hannifin Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS51504A8-12
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8-12CBTX-S
- 30780 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- RH106801
- 45152 - Oshkosh Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8904944
- 18876 - Us Army Aviation And Missile Command (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8-12 070202C
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MS51504A8-12
- 30327 - Imperial (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- MS51504A8-12
- 98660 - Lube Devices Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 849-FS-08X12
- 30327 - Imperial (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- J514
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- TC15-1096
- 03677 - Anthony York Co (Obsolete)
- Advisory Reference
- Advisory Reference
- 06209400
- 54217 - Terex Aerials Inc (Obsolete)
- Advisory Reference
- Advisory Reference
- 2024-12-8S
- 01276 - Danfoss Power Solutions Ii, Llc (Active)
- Advisory Reference
- Advisory Reference
- 8-12CTX-S
- 98441 - Parker Hannifin Corp (Active)
- Advisory Reference
- Advisory Reference
- 9018112
- 18876 - Us Army Aviation And Missile Command (Active)
- Advisory Reference
- Advisory Reference
- MS51504B8-12
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
- RH106801
- 75Q65 - Oshkosh Defense Llc (Active)
- Advisory Reference
- Advisory Reference
- 8-12CTX-S
- 45681 - Parker-Hannifin Corporation (Active)
- Advisory Reference
- Advisory Reference
- 2103-12-8
- 98441 - Parker Hannifin Corp (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4730-00-618-8126
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- End Item Identification [AGAV]
- 6Jm Howitzer, Medium, Sp, 155Mm, W/Radio Vrc-47 (M109)
- Connection Style [AHNC]
- Flared (Tube) 1St End
- Connection Style [AHNC]
- Plain (Pipe) 2Nd End
- Connection Type [AWLS]
- Threaded External Pipe 2Nd End
- Connection Type [AWLS]
- Threaded External Tube 1St End
- Furnished Items And Quantity [TMQY]
- 1 Tube Coupling Nut And 1 Flared Sleeve
- Flow Angle [CRFY]
- 90.0 Degrees
- Material [MATT]
- Steel Comp 12L14 Overall
- Maximum Operating Temp [AEHZ]
- -65.0 Deg Fahrenheit 1St Response
- Maximum Operating Temp [AEHZ]
- 250.0 Deg Fahrenheit 2Nd Response
- Maximum Operating Pressure [CQGM]
- 3000.0 Pounds Per Square Inch Single Response
- Media For Which Designed [MEDA]
- Hydraulic Fluid Single Response
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.500 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.750 Inches All Ends
- Nondefinitive Spec/Std Data [ZZZT]
- 4A Figure
- Leg Length [AHSJ]
- 1.420 Inches Nominal 1St End
- Leg Length [AHSJ]
- 1.590 Inches Nominal 2Nd End
- Material Document And Classification [MDCL]
- 66 Fed Std Single Material Response Overall
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Specification/Standard Data [ZZZK]
- 81349-Mil-F-18866 Government Specification And 81343-J514 Professional/Industrial Association Standard And 96906-Ms51504 Government Standard
- Surface Treatment Document And Classification [STDC]
- J514 Assn Std Single Treatment Response Overall And Qq-P-416, Ty 2, Cl 3 Fed Spec Single Treatment Response Overall
- Thread Class [AAJD]
- 2A 1St End
- Thread Series Designator [THSD]
- Nptf 2Nd End
- Thread Series Designator [THSD]
- Unf 1St End
