4730-00-555-8204
Tube Coupling Nut
4730005558204 005558204 SAE-AS18280 MS21921-10D MS21921D10 156/9 C61A2024D10 MS21917D10
An internally threaded nut which has either an internal seat or shoulder and/or is designed to be used with a ferrule, to mate with the seat of an externally threaded tube fitting to form a leakproof connection. Excludes NUT (1), TUBE COUPLING, REDUCING; and NUT (1), UNION. View more Tube Coupling Nut
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
November 2023
November 2023
NATO Update Count
41
41
NATO Data Quality
Marketplace 4730-00-555-8204
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
MS21921-10D NUT,TUBE COUPLING 249 PG NS
MS21917D10 NUT,TUBE COUPLING 24 PG NS
MS21921D10 NUT,TUBE COUPLING 20 PG NS
Updated Every Day 4730-00-555-8204 RQST NE
Updated Every Day 4730-00-555-8204 RQST
Updated Every Day 4730-00-555-8204 RQST NE
Related Documents 4730-00-555-8204 5+ Documents (More...)
SAE-AS18280 MS21921-10D MS21921D10 156/9 C61A2024D10 MS21917D10 An internally threaded nut which has
MS21921-10D NUT,TUBE COUPLING 249 PG NS Request Quotation MS21917D10 NUT,TUBE COUPLING 24 PG NS Request
MS21921D10 NUT,TUBE COUPLING 3 PG NS Request Quotation Subscribe to View Vendor Details... 4730-00-555
MS21921-10D NUT,TUBE COUPLING 249 PG NS Request Quotation MS21917D10 NUT,TUBE COUPLING 24 PG NS Request
MS21921D10 NUT,TUBE COUPLING 3 PG NS Request Quotation Subscribe to View Vendor Details... 4730-00-555
MS21921-10D NUT,TUBE COUPLING 29 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 11 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 39 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 11 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 39 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921D10 NUT,TUBE COUPLING 20 EA NS Request Quotation Subscribe to View Vendor Details... 1569 NUT,
MS21921D10 NUT,TUBE COUPLING 30 EA NS Request Quotation Subscribe to View Vendor Details... 1569 NUT,
Related Documents 4730-00-640-0399 2+ Documents https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-555-8204
MS21921D10 NUT,TUBE COUPLING 30 EA NS Request Quotation Subscribe to View Vendor Details... 1569 NUT,
Related Documents 4730-00-640-0399 2+ Documents https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-555-8204
MS21921-10D NUT,TUBE COUPLING 29 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 138 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 35 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 138 EA NS Request Quotation Subscribe to View Vendor Details...
MS21921-10D NUT,TUBE COUPLING 35 EA NS Request Quotation Subscribe to View Vendor Details...
AS18280 AS21921 MS21921D10 MS21921-10 9409525 An internally threaded nut which has either an internal
Tube Coupling Nut 4730005558204 005558204 $1 a day Upgrade your Account Upgrade 4730-00-555-8204Tube
Coupling Nut4730005558204 005558204 SAE-AS18280 Tube Coupling Nut 4730008211824008211824AS18280AS21921MS21921D10MS21921
Tube Coupling Nut 4730005558204 005558204 $1 a day Upgrade your Account Upgrade 4730-00-555-8204Tube
Coupling Nut4730005558204 005558204 SAE-AS18280 Tube Coupling Nut 4730008211824008211824AS18280AS21921MS21921D10MS21921
Restrictions 4730-00-555-8204
4730-00-555-8204 is a Tube Coupling Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4730-00-555-8204
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-555-8204
- US Army (A920)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- CT
- US Coast Guard (C911)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C001
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXAX
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTKEJBHD
- Poland (WP01)
- Effective Date:
- 1 Aug 2011
- Brazil (YA01)
- Effective Date:
- 1 Mar 2010
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Sep 2004
Approved Sources 4730-00-555-8204
- Part Number
- Manufacturer
- Status
- MS21921D10
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- SAE-AS18280
- 0U583 - Sae International (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 156/9
- K7018 - Wellman Group (Active)
- Secondary Buy
- Secondary Buy
- C61A2024D10
- 50948 - Parker Hannifin Corp Stratoflex Div (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS21917D10
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- C61A2024D10
- 92003 - Parker Hannifin Corporation Div (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- C61A2024D10
- 45681 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS21921-10D
- 96906 - Military Standards (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4730-00-555-8204
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- End Item Identification [AGAV]
- Ch-47 Helicopter
- Fabrication Method [AARN]
- Any Acceptable
- Material [MATT]
- Aluminum Alloy Overall
- Nominal Tube Outside Diameter [CQRJ]
- 0.625 Inches
- Nominal Thread Size [CQJX]
- 0.875 Inches
- Nut Height [ADEA]
- 0.970 Inches Minimum And 0.990 Inches Maximum
- Nut Style [ACTA]
- Tube Coupling
- Length To Shoulder [BRQL]
- 0.677 Inches Minimum And 0.697 Inches Maximum
- Seat Angle [CRRB]
- 45.00 Degrees Nominal
- Smallest Inside Diameter [BSPX]
- 0.690 Inches Minimum And 0.695 Inches Maximum
- Width Across Flats [ASDB]
- 1.000 Inches Nominal
- Surface Treatment Document And Classification [STDC]
- Mil-A-8625,Ty 2 Mil Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Anodize Overall
- Thread Class [AAJD]
- 3B
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity Per Inch [CMLP]
- 14
- Thread Series [BZRR]
- Unf
DLA Procurement Analysis 4730-00-555-8204
- Last Stock Position:
- 6575 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-00-555-8204
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Coast Guard (GP)
- PG
- Subscribe
- 1
- PG
- Dec 2021
- Department of the Air Force (DF)
- PG
- Subscribe
- 1
- PG
- Oct 2021
- Defense Logistics Agency (DS)
- PG
- Subscribe
- 1
- PG
- Oct 2020
- Defense Logistics Agency (DS)
- PG
- Subscribe
- 1
- PG
- Feb 2020
- Department of the Air Force (DF)
- PG
- Subscribe
- 1
- PG
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- K
- U/I Contains 25 Ea
- 00000000025EA
- K
- Department of the Air Force (DF)
- F
- K
- U/I Contains 25 Ea
- 00000000025EA
- K
- Department of the Navy (DN)
- N
- K
- U/I Contains 25 Ea
- 00000000025EA
- K
- Defense Logistics Agency (DS)
- I
- K
- U/I Contains 25 Ea
- 00000000025EA
- K
- Defense Logistics Agency (DS)
- I
- F
- When Exhausted Use 4730-01-004-8245
- F
- US Coast Guard (GP)
- C
- F
- When Exhausted Use 4730-01-004-8245
- F
- US Coast Guard (GP)
- C
- K
- U/I Contains 25 Ea
- 00000000025EA
- K
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- BJ
- Rotary Wing Aircraft
AH-64 Airframe
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4730-00-555-8204
4730-19-004-9209 4730-21-864-7316 4730-12-125-4942 4730-66-049-8520 4730-17-109-4426 4730-12-301-3211 4730-22-616-7084 4730-14-566-8474 4730-66-102-1697 4730-12-308-5275 4730-12-176-4035 4730-12-165-3167 4730-12-148-3404 4730-12-333-3220 4730-99-549-9467 4730-12-193-8303 4730-12-364-7859 4730-12-156-9763
Freight Information 4730-00-555-8204
4730-00-555-8204 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 013540. A Sub NMFC of X. It has a NMFC Description of ALUM NUTS. 4730-00-555-8204 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05680 which rates the freight between FCL and LCL. 4730-00-555-8204 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-555-8204 is not classified as a special type of cargo when transported by water. 4730-00-555-8204 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-555-8204
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
Contracting Technical Data File (CTDF) 4730-00-555-8204 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
