4730-00-502-9191
Tube Fitting Flared Sleeve
4730005029191 005029191 KC143C6 KC143K6 AS4327K06
A flanged cylindrical metallic item designed to be used on tubing to back up the flared end and to provide a bearing surface for the coupling nut, thereby reducing wear on the tubing flare. The inside diameter of the flanged end is countersunk to form a seat for the flare when assembled to a mating fitting. View more Tube Fitting Flared Sleeve
May 2023
12
Marketplace 4730-00-502-9191
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-502-9191 3+ Documents (More...)
Photo 1/3 4730-00-502-9191 Photo 2/3 NSN 4730-00-502-9191 (Identification) 3/3 - - - 1.
AS4327K06 SLEEVE,FLARED,TUBE FITTING 65 EA NS Request Quotation KC143K6 SLEEVE,FLARED,TUBE FITTING 1
Restrictions 4730-00-502-9191
4730-00-502-9191 is a Tube Fitting Flared Sleeve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4730-00-502-9191
- NASA (G860)
- Effective Date:
- 1 Apr 1991
Approved Sources 4730-00-502-9191
- Part Number
- Manufacturer
- Status
- AS4327K06
- Manufacturer
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- AS4327K06
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Original Design
- Original Design
- KC143C6
- 22264 - John F Kennedy Space Center (Active)
- Advisory Reference
- Advisory Reference
- KC143K6
- 22264 - John F Kennedy Space Center (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4730-00-502-9191
- Characteristic
- Specifications
- FIIG
- Specifications
- T385-J
- Casehardening Indicator [AASG]
- Not Casehardened
- Flange Outside Diameter [AHTC]
- 0.502 Inches Nominal
- Flange Width [AGFF]
- 0.172 Inches Nominal
- Hose/Tube Outside Diameter For Which Designed [CPMS]
- 0.375 Inches Nominal
- Material [MATT]
- Steel Corrosion Resisting
- Seat Angle In Deg [AJFY]
- 33.0
- Sleeve Outside Diameter [ARYW]
- 0.432 Inches Nominal
- Overall Length [ABHP]
- 0.500 Inches Nominal
- Style Designator [STYL]
- Sleeve
- Surface Treatment [SFTT]
- Passivate
Similar Supply Items to 4730-00-502-9191
Freight Information 4730-00-502-9191
4730-00-502-9191 has freight characteristics.. 4730-00-502-9191 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
