4730-00-435-6886
Quick Disconnect Coupling Half
4730004356886 004356886 3L23D7
A fluid line fitting having a pipe, tube or hose connection or a through hole to accommodate a BOLT, FLUID PASSAGE on one end. The other end must have an internal or external quick disconnect feature for connecting a mating part to form a quick disconnect coupling assembly. The fitting may incorporate a self-sealing feature for the purpose of automatically shutting off the flow of fluid when disconnected from its mating half. For self-sealing fittings with an external or internal threaded disconnect end, see COUPLING HALF, SELF-SEALING. See also, CONNECTOR, MULTIPLE, FLUID PRESSURE LINE. View more Quick Disconnect Coupling Half
May 2023
5
Marketplace 4730-00-435-6886
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-435-6886 5+ Documents (More...)
4730-00-435-6886 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-435-6886
Quick Disconnect Coupling Half 4730004356886 RQST NE Updated Every Day 4730-00-435-6886 RQST Updated
Restrictions 4730-00-435-6886
4730-00-435-6886 is a Quick Disconnect Coupling Half that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4730-00-435-6886
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-435-6886
- NASA (G860)
- Effective Date:
- 1 Apr 1991
Approved Sources 4730-00-435-6886
- Part Number
- Manufacturer
- Status
- 3L23D7
- Manufacturer
- 73992 - Tuthill Corp Hansen Coupling Div (Active)
- Primary Buy
- Primary Buy
Datasheet 4730-00-435-6886
- Characteristic
- Specifications
- FIIG
- Specifications
- A531T0
- Connection Style [AHNC]
- Hose Gripping Nipple All Ends
- Connection Type [AWLS]
- External Quick Disconnect All Ends
- Connection Type [AWLS]
- Threaded External Pipe First Fluid End Connection
- Furnished Items [ABFF]
- Hose Clamp Ferrule
- Material [MATT]
- Steel Body
- Mating End Identification [ADLT]
- Hansen Mfg Co. Coupling Half,Quick Disconnect,Part No. 3R23d7
- Quick Disconnect Method [ADLN]
- Push-Pull All Ends
- Overall Length [ABHP]
- 3.140 Inches Nominal
- Thread Series Designator [THSD]
- Unf All Ends
- Style Designator [STYL]
- Male Coupling Half
Similar Supply Items to 4730-00-435-6886
Freight Information 4730-00-435-6886
4730-00-435-6886 has freight characteristics.. 4730-00-435-6886 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
