4730-00-421-4464
Tube To Boss Tee
4730004214464 004214464 372220
A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The tube connection(s) has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or is unthreaded and designed to accommodate a tube. The boss connection(s) has external or internal machine threads (straight threads other than pipe or hose series), and is designed to facilitate a gasket, preformed packing, washer, or the like, to form a seal at the boss. It may have side inlet(s). It is used as a junction at the intersection of a tube or fitting and a boss or boss fitting on items such as a tank, housing, valve fitting, or the like. See also TEE, TUBE; and TEE, PIPE TO TUBE. Excludes CONNECTOR, MULTIPLE, FLUID PRESSURE LINE. View more Tube To Boss Tee
November 2023
6
Marketplace 4730-00-421-4464
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-421-4464 4+ Documents (More...)
Updated Every Day 4730-00-421-4464 RQST NE Related Documents 4730-00-421-4464 3+ Documents ( More...
Every Day 4730-00-421-4464 RQST NE Related Documents 4730-00-421-4464 3+ Documents ( More...
JavaScript in your web browser . 5998-00-088-7000Circuit Card Assembly5998000887000 000887000 0372220 372220
RQST NE Related Documents https//www.nsnlookup.com https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-421-4464
enable JavaScript in your web browser . 4810-14-328-7114Bloc Distributeur4810143287114 143287114 372220
Tube To Boss Tee 4730004214464 004214464 for $1 a day Upgrade your Account Upgrade 4730-00-421-
Restrictions 4730-00-421-4464
4730-00-421-4464 is a Tube To Boss Tee that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4730-00-421-4464
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-421-4464
- US Navy (N9BC)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTKE
Approved Sources 4730-00-421-4464
- Part Number
- Manufacturer
- Status
- 372220
- Manufacturer
- 3Y434 - Willmore, Inc. (Active)
- Primary Buy
- Primary Buy
- 372220
- 3B150 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- 372220
- 54X10 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- 372220
- 49956 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4730-00-421-4464
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- Material [MATT]
- Aluminum Alloy Overall
- Surface Treatment [SFTT]
- Oxide Film Overall
- Surface Treatment Document And Classification [STDC]
- Mil-C-5541 Mil Spec Single Treatment Response Overall
- Connection Type [AWLS]
- Threaded External Boss 1St End
- Connection Type [AWLS]
- Threaded External Boss 2Nd End
- Connection Type [AWLS]
- Threaded External Tube 3Rd End
- Connection Style [AHNC]
- External Seat For Gasket Seal (Boss) 1St End
- Connection Style [AHNC]
- External Seat For Gasket Seal (Boss) 2Nd End
- Connection Style [AHNC]
- Flared (Tube) 3Rd End
- Seat Angle [CQRB]
- 45.0 Degrees 3Rd End
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.188 Inches 3Rd End
- Thread Series Designator [THSD]
- Unf All Ends
- Nominal Thread Size [CQJX]
- 0.750 Inches 1St End
- Nominal Thread Size [CQJX]
- 0.750 Inches 2Nd End
- Nominal Thread Size [CQJX]
- 0.375 Inches 3Rd End
- Thread Class [AAJD]
- 3A All Ends
- Leg Length [AHSJ]
- 1.550 Inches Nominal 1St End
- Leg Length [AHSJ]
- 1.550 Inches Nominal 2Nd End
- Leg Length [AHSJ]
- 0.637 Inches Nominal 3Rd End
- Special Features [FEAT]
- First End Bulkhead,Unf,0.750 Thd Size,3A Thd Class
Weapon Systems (WSDC) 4730-00-421-4464
DLA Procurement Analysis 4730-00-421-4464
- Last Stock Position:
- 4 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-00-421-4464
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4730-00-421-4464
Freight Information 4730-00-421-4464
4730-00-421-4464 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051400. A Sub NMFC of X. It has a NMFC Description of PIPE FITTINGS ALUMINUM. 4730-00-421-4464 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29700 which rates the freight between FCL and LCL. 4730-00-421-4464 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-421-4464 is not classified as a special type of cargo when transported by water. 4730-00-421-4464 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-421-4464
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- MIL-DTL-117, Type II, Class C, Style 1, Heavy Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
Procurement History 4730-00-421-4464 1 Records
Contracting Technical Data File (CTDF) 4730-00-421-4464 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
