4730-00-339-0942
Sediment Strainer Element
4730003390942 003390942 SR57SF24B 61731 SR57S24B
A replaceable device designed to remove solid particles from flowing liquids. The removal of particles is accomplished by porous material (metallic or non-metallic), wire mesh, perforated metal, or the like, constructed so the liquid can flow through the device while the solid particles are retained. It is designed to fit into a STRAINER, SEDIMENT (or similar cavity). It may have a reinforcement to prevent collapsing, distorting or rupturing. The degree of particles removed must be nominally rated at 50 microns, or more, or absolutely rated at 75 microns, or more. See also FILTER ELEMENT, FLUID. View more Sediment Strainer Element
May 2023
5
Marketplace 4730-00-339-0942
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-339-0942 5+ Documents (More...)
SR57SF24B STRAINER ELEMENT,SEDIMENT 6 EA NS Request Quotation FedMall Updated Every 15 Minutes 4730-00
... ) https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-339-0942 Sediment Strainer Element 4730003390942
Sediment Strainer Element 4730003390942 0942 RQST NE Updated Every Day 4730-00-339-0942 https//
Sediment Strainer Element 4730003390942 3448 Part https//www.nsnlookup.com /fsg-59/fsc-5961/us 5961-
Restrictions 4730-00-339-0942
4730-00-339-0942 is a Sediment Strainer Element that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4730-00-339-0942
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Supplementary Collaborators:
- HD
- United States of America (ZZ)
Approved Sources 4730-00-339-0942
- Part Number
- Manufacturer
- Status
- SR57SF24B
- Manufacturer
- 07988 - Automotive Inc (Obsolete)
- Original Design
- Original Design
- SR57SF24B
- 05160 - Michigan Dynamics Inc (Active)
- Advisory Reference
- Advisory Reference
- 61731
- 94764 - Pettibone Mercury Corp (Obsolete)
- Advisory Reference
- Advisory Reference
- SR57S24B
- 05160 - Michigan Dynamics Inc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4730-00-339-0942
- Characteristic
- Specifications
- FIIG
- Specifications
- A523H0
- Element Outside Diameter [CSKZ]
- 4.040 Inches Minimum And 4.170 Inches Maximum
- End Connection Type [AWZY]
- Plain 2Nd End
- End Connection Type [AWZY]
- Threaded 1St End
- Filtering Media Design [CRXW]
- Mesh
- Material [MATT]
- Nickel Alloy And Aluminum Alloy And Steel
- Mesh Size [AKSX]
- 60.0
- Nominal Thread Size [CQJX]
- 1.500 Inches 1St End
- Length [ABRY]
- 6.100 Inches Minimum And 6.870 Inches Maximum
- Wire Diameter [AGCW]
- 0.00900 Inches Nominal
- Style Designator [STYL]
- Cylindrical
- Thread Series Designator [THSD]
- Npt 1St End
DLA Procurement Analysis 4730-00-339-0942
Management Data 4730-00-339-0942
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4730-00-339-0942
Freight Information 4730-00-339-0942
4730-00-339-0942 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051450. A Sub NMFC of X. It has a NMFC Description of PIPE FITTINGS CUPRO NICKEL/COPPER. 4730-00-339-0942 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29740 which rates the freight between FCL and LCL. 4730-00-339-0942 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-339-0942 is not classified as a special type of cargo when transported by water. 4730-00-339-0942 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 4730-00-339-0942 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
