4730-00-278-2621
Sediment Strainer
4730002782621 002782621 MIL-S-2953CLASSA
A strainer having inlet and outlet connections and designed to be connected in a pipe, tube or hose line. View more Sediment Strainer
May 2023
13
Marketplace 4730-00-278-2621
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-278-2621 5+ Documents (More...)
RQST NE Updated Every Day 4730-00-278-2621 RQST Updated Every Day 4730-00-278-2621 RQST NE Related Documents
4730-00-278-2621 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-47/fsc-4730/us 4730-00-278-2621
Sediment Strainer 4730002782621 002782621 a day Upgrade your Account Upgrade 4730-00-278-2621Sediment
Strainer4730002782621 002782621 MIL-S-2953CLASSA Upgrade your Account Upgrade 4730-00-278-2638Sediment
a day Upgrade your Account Upgrade 4730-00-278-2636Sediment Strainer4730002782636 002782636 MIL-S-2953CLASSA
Sediment Strainer 4730002782621 002782621 a day Upgrade your Account Upgrade 4730-00-278-2621Sediment
Restrictions 4730-00-278-2621
4730-00-278-2621 is a Sediment Strainer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4730-00-278-2621
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4730-00-278-2621
- Part Number
- Manufacturer
- Status
- MIL-S-2953CLASSA
- Manufacturer
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 4730-00-278-2621
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Filtering Media Design [CRXW]
- Perforated Single Filtering Media Response
- First Discharge Connection Relationship To Intake Connection [CSJR]
- Identical To First Intake Connection
- First Intake Connection Type [CRXZ]
- Plain Face Flange Line
- First Intake Flange Face Style [CTBJ]
- Plain
- First Intake Flange Shape Style [CSTD]
- Round W/Unthreaded Bolt Holes
- Material [MATT]
- Copper Alloy Body
- Material [MATT]
- Nickel Alloy Screening
- Maximum Operating Pressure [CQGM]
- 200.0 Pounds Per Square Inch
- Media For Which Designed [MEDA]
- Water
- Mounting Type [AAXX]
- Inlet Connection Line And Outlet Connection Line
- Nondefinitive Spec/Std Data [ZZZT]
- A Class
- Style Designator [STYL]
- Y Strainer W/Threaded Cover
- Perforation Diameter [AKSV]
- 0.063 Inches Nominal
- Perforation Quantity [AKSW]
- 144.0 Per Square Inch
- Temp Rating [AZKQ]
- 425.0 Deg Fahrenheit Nominal
DLA Procurement Analysis 4730-00-278-2621
Management Data 4730-00-278-2621
Navy
- Cognizance:
- 3B
Similar Supply Items to 4730-00-278-2621
Freight Information 4730-00-278-2621
4730-00-278-2621 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052185. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FIT. 4730-00-278-2621 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29950 which rates the freight between FCL and LCL. 4730-00-278-2621 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-278-2621 is not classified as a special type of cargo when transported by water. 4730-00-278-2621 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-278-2621
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
