4730-00-277-1167
Tube Tee
4730002771167 002771167 AFP2606T121208 AE16171-12-12-8 R45111T121208 GT515AY12-12-08 AP360T121208 ST7M220T121208
A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The connections have machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or are unthreaded and designed to accommodate a tube. It may have side inlet(s). It is used as a junction at the intersection of a tube or tube fitting. View more Tube Tee
November 2023
14
Marketplace 4730-00-277-1167
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-277-1167 3+ Documents (More...)
AE16171-12-12-8 TEE,TUBE RQST NS Request Quotation ST7M220T121208 TEE,TUBE 130 EA NS Request Quotation
GT515AY12-12-08 TEE,TUBE RQST NS Request Quotation AP360T121208 TEE,TUBE RQST NS Request Quotation R45111T121208
Restrictions 4730-00-277-1167
4730-00-277-1167 is a Tube Tee that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4730-00-277-1167
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-277-1167
- US Air Force (FXGC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- FXAX
- Singapore (YJ01)
- Effective Date:
- 1 Dec 2009
- Republic of Korea (ZH01)
- Effective Date:
- 1 Oct 2009
Approved Sources 4730-00-277-1167
- Part Number
- Manufacturer
- Status
- AE16171-12-12-8
- Manufacturer
- 00624 - Eaton Aeroquip Llc (Active)
- Primary Buy
- Primary Buy
- R45111T121208
- 50599 - Parker-Hannifin Corporation (Active)
- Primary Buy
- Primary Buy
- AFP2606T121208
- 30974 - Aerofit, Llc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- GT515AY12-12-08
- 26512 - Northrop Grumman Systems Corporation (Active)
- Secondary Buy
- Secondary Buy
- AP360T121208
- 01673 - Sps Technologies, Llc (Active)
- Secondary Buy
- Secondary Buy
- ST7M220T121208
- 76301 - The Boeing Company (Active)
- Secondary Buy
- Secondary Buy
Datasheet 4730-00-277-1167
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- Material [MATT]
- Titanium Alloy Overall
- Material Document And Classification [MDCL]
- Ams 4965,6Al-4V Assn Std Single Material Response Overall
- Connection Type [AWLS]
- Threaded External Tube 1St End
- Connection Type [AWLS]
- Threaded External Tube 2Nd End
- Connection Type [AWLS]
- Threaded External Tube 3Rd End
- Connection Style [AHNC]
- Inverted Flare (Tube) 1St End
- Connection Style [AHNC]
- Inverted Flare (Tube) 2Nd End
- Seat Angle [CQRB]
- 8.5 Degrees 1St End
- Seat Angle [CQRB]
- 8.5 Degrees 2Nd End
- Seat Angle [CQRB]
- 8.5 Degrees 3Rd End
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.750 Inches 1St End
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.750 Inches 2Nd End
- Nominal Outside Diameter Tube Accommodated [CWFD]
- 0.500 Inches 3Rd End
- Thread Series Designator [THSD]
- Unj 1St End
- Thread Series Designator [THSD]
- Unj 2Nd End
- Thread Series Designator [THSD]
- Unjs 3Rd End
- Nominal Thread Size [CQJX]
- 1.000 Inches 1St End
- Nominal Thread Size [CQJX]
- 1.000 Inches 2Nd End
- Nominal Thread Size [CQJX]
- 0.718 Inches 3Rd End
- Thread Quantity Per Inch [CMLP]
- 16 1St End
- Thread Quantity Per Inch [CMLP]
- 16 2Nd End
- Thread Quantity Per Inch [CMLP]
- 20 3Rd End
- Thread Class [AAJD]
- 3A 1St End
- Thread Class [AAJD]
- 3A 2Nd End
- Thread Class [AAJD]
- 3A 3Rd End
- Leg Length [AHSJ]
- 1.062 Inches Nominal 1St End
- Leg Length [AHSJ]
- 1.062 Inches Nominal 2Nd End
- Leg Length [AHSJ]
- 0.958 Inches Nominal 3Rd End
Weapon Systems (WSDC) 4730-00-277-1167
DLA Procurement Analysis 4730-00-277-1167
- Last Stock Position:
- 1 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4730-00-277-1167
Similar Supply Items to 4730-00-277-1167
Freight Information 4730-00-277-1167
4730-00-277-1167 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 136500. A Sub NMFC of Z. It has a NMFC Description of METAL NOI/METAL ALLOYS NOI. 4730-00-277-1167 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 68455 which rates the freight between FCL and LCL. 4730-00-277-1167 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-277-1167 is not classified as a special type of cargo when transported by water. 4730-00-277-1167 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-277-1167
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
Procurement History 4730-00-277-1167 1 Records
Contracting Technical Data File (CTDF) 4730-00-277-1167 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- R
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
