4730-00-201-3081
Tube Coupling Nut
4730002013081 002013081 7 646A078H05 N20 12722082-1
An internally threaded nut which has either an internal seat or shoulder and/or is designed to be used with a ferrule, to mate with the seat of an externally threaded tube fitting to form a leakproof connection. Excludes NUT (1), TUBE COUPLING, REDUCING; and NUT (1), UNION. View more Tube Coupling Nut
August 2023
3
Marketplace 4730-00-201-3081
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-201-3081 5+ Documents (More...)
/fsc-4730/us 4730-00-201-3081 Tube Coupling Nut 4730002013081 002013081,7 7646A078H05N2012722082-1 An
Tube Coupling Nut 4730002013081 002013081,7 7646A078H05N2012722082-1 An 2/4 4730-00-201-3081 Photo 3/
INC: 02101 Paint Remover Managed by France NSN Created on 7 Dec 2001 Data Last Changed July 2023 NATO
Tube Coupling Nut 4730002013081 002013081,7 Identification N20 NUT,TUBE COUPLING 1423 EA NS https
View more Automatic Data Processing Server Managed by Canada NSN Created on 7 Mar 2011 Data Last Changed
7035/ca 7035-20-006-1515 Automatic Data Processing Server 200061515 200061515POWEREDGE R910 X7550/D N20
Tube Coupling Nut 4730002013081 002013081,7 | EDC: | ADPEC : 5950-00-139-9036 is a 7 https https
)NAConsolidated With 4730-00-201-3081Federal Aviation Administration (GE)IAConsolidated With 4730-00-201-3081
Restrictions 4730-00-201-3081
4730-00-201-3081 is a Tube Coupling Nut that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4730-00-201-3081
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4730-00-201-3081
- US Army (A920)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- A181
- MOE Rule:
- BGX1
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- BAX1
- US Air Force (FXGC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- FXAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Jul 2005
- Supplementary Collaborators:
- HDJN
Approved Sources 4730-00-201-3081
- Part Number
- Manufacturer
- Status
- 7
- Manufacturer
- 16166 - Western Enterprises Div Of Scott And (Active)
- Primary Buy
- Primary Buy
- 646A078H05
- 97942 - Northrop Grumman Systems Corporation (Active)
- Primary Buy
- Primary Buy
- N20
- 52929 - Superior Products, Llc. (Active)
- Primary Buy
- Primary Buy
- 12722082-1
- 19200 - Combat Capabilities Development (Active)
- Secondary Buy
- Secondary Buy
Datasheet 4730-00-201-3081
- Characteristic
- Specifications
- FIIG
- Specifications
- A021A0
- Thread Series [BZRR]
- Unf
- Nominal Thread Size [CQJX]
- 0.562 Inches
- Thread Quantity Per Inch [CMLP]
- 18
- Thread Class [AAJD]
- 2B
- Thread Direction [AAJF]
- Right-Hand
- Material [MATT]
- Copper Alloy Overall
- Nut Style [ACTA]
- Tube Coupling
- Nut Height [ADEA]
- 0.625 Inches Nominal
- Width Across Flats [ASDB]
- 0.688 Inches Nominal
- Smallest Inside Diameter [BSPX]
- 0.440 Inches Nominal
- Fabrication Method [AARN]
- Machined
- Nominal Tube Outside Diameter [CQRJ]
- 0.437 Inches
DLA Procurement Analysis 4730-00-201-3081
Management Data 4730-00-201-3081
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 4730-00-201-3081
Freight Information 4730-00-201-3081
4730-00-201-3081 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 093460. A Sub NMFC of X. It has a NMFC Description of BOLTS/NUTS NOI BBC/ZINC. 4730-00-201-3081 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48930 which rates the freight between FCL and LCL. 4730-00-201-3081 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 4730-00-201-3081 is not classified as a special type of cargo when transported by water. 4730-00-201-3081 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-201-3081
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- MIL-DTL-117, Type II, Class C, Style 1, Heavy Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
