4730-00-200-0232
Fluid Pressure Line Multiple Connector
4730002000232 002000232 CPR100553 16A2971 7014967 5228628 373078 BB29133 111307007
A device of varying shapes with two or more connections to accommodate hydraulic or air passage(s) line end connections and/or a BOLT, FLUID PASSAGE(S). View more Fluid Pressure Line Multiple Connector
May 2023
28
Marketplace 4730-00-200-0232
Request a Quotation from participating marketplace vendors
Related Documents 4730-00-200-0232 5+ Documents (More...)
/fsg-47/fsc-4730/us
BB29133 CONNECTOR,MULTIPLE,FLUID PRESSURE LINE 9 EA NS Request Quotation Updated Every Day 4730-00-200
-0232 RQST NE Updated Every Day 4730-00-200-0232 RQST Updated Every Day 4730-00-200-0232 RQST NE Related
https//www.nsnlookup.com /fsg-49/fsc-4935/fr 4935-14-400-0540 Guide 4935144000540 144000540,373078 373078
https//www.nsnlookup.com /fsg-49/fsc-4935/fr 4935-14-400-0540 Guide 4935144000540 144000540,373078 373078
for $1 a day Upgrade your Account Upgrade 5960-01-290-2604Electron Tube5960012902604 012902604 Y634 373078
for $1 a day Upgrade your Account Upgrade 5960-01-290 -2604Electron Tube5960012902604 012902604Y634 373078
Fluid Pressure Line Multiple Connector Y634 373078 https//www.nsnlookup.com /fsg-59/fsc-5960/us
for $1 a day Upgrade your Account Upgrade 5960-01-290-2604Electron Tube5960012902604 012902604 Y634 373078
Restrictions 4730-00-200-0232
4730-00-200-0232 is a Fluid Pressure Line Multiple Connector that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4730-00-200-0232
- US Army (A920)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4730-00-200-0232
- Part Number
- Manufacturer
- Status
- CPR100553
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 16A2971
- 95201 - Napco International Llc (Active)
- Primary Buy
- Primary Buy
- 7014967
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 5228628
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
- 373078
- 62265 - Volvo Trucks North America, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 373078
- 65282 - White Motor Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- BB29133
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 111307007
- 63734 - Kaitlin Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 4730002000232
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 4730-00-200-0232
- Characteristic
- Specifications
- FIIG
- Specifications
- T385-G
- Bolt Hole Flats Serrations [CGLQ]
- Not Provided
- Bolt Hole Fluid Passage [CGLR]
- Not Provided
- Connection Style [AHNC]
- Plain
- Fluid Connection Quantity [CGLN]
- 2
- Fluid Conveyance Type And Size For Which Designed [CGLP]
- 1/4 In. Od Pipe
- Material [MATT]
- Iron Cast
- Mounting Hole Diameter [ABTB]
- 0.281 Inches Nominal
- Seat [BJHZ]
- Not Included
- Screw Thread Series Designator [AJYP]
- Npt
- Overall Length [ABHP]
- 2.500 Inches Nominal
- Overall Width [ABMK]
- 1.188 Inches Nominal
- Style Designator [STYL]
- 2 Fluid Connections W/Mounting Plate
- Thickness [ABNM]
- 0.875 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Provision [AFEW]
- Threaded
- Thread Size [ABUJ]
- 1/4 In. -18
DLA Procurement Analysis 4730-00-200-0232
Management Data 4730-00-200-0232
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
NATO Stock Numbers Related to 4730-00-200-0232
Freight Information 4730-00-200-0232
4730-00-200-0232 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4730-00-200-0232 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. 4730-00-200-0232 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4730-00-200-0232 is not classified as a special type of cargo when transported by water. 4730-00-200-0232 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4730-00-200-0232
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 4730-00-200-0232 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
