4720-01-432-1384
Air Duct Hose
4720014321384 014321384 SCATS 10-192-8
A flexible, tubular item of light wall construction. It must have single or multiple layers of nonmetallic material, but may contain metal wire reinforcement, foil type liner, and/or woven or braided cover. It is designed to convey under low pressure gaseous material, such as air and fumes, and light weight solid materials, such as dust, powders, and fibers. For items with couplings, see HOSE ASSEMBLY, AIR DUCT. For items of sleeve section design rated for high pressure use, see SLEEVE, SEAL, COUPLING. Excludes hose, nonmetallic. View more Air Duct Hose
August 2025
1
Marketplace 4720-01-432-1384
Request a Quotation from participating marketplace vendors
Related Documents 4720-01-432-1384 5+ Documents (More...)
4720-01-432-1384 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-01-432-1384
RQST NE Updated Every Day 4720-01-432-1384 RQST Updated Every Day 4720-01-432-1384 RQST NE Related Documents
Air Duct Hose 4720014321384 014321384 329-4130 4720-00-577-7271 4720-01-497-9934 4720-98-850-0765
329-4130 4720-00-577-7271 4720-01-497-9934 4720-98-850-0765 4720-01-097-6710 4720-98-104-9915 4720-01-432-1384
Air Duct Hose 4720014321384 014321384 432-1384 4720-00-329-4130 4720-00-577-7271 4720-01-497-9934
329-4130 4720-00-577-7271 4720-01-497-9934 4720-98-850-0765 4720-01-097-6710 4720-01-200-8697 4720-01-432-1384
Air Duct Hose 4720014321384 014321384 https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720 https//
577-7271 4720-01-497-9934 4720-98-850-0765 4720-01-097-6710 4720-98-104-9915 4720-01-200-8697 4720-01-432-1384
Air Duct Hose 4720014321384 014321384 432-1384 4720-00-329-4130 www.nsnlookup.com /fsg-47/fsc-4720
497-9934 4720-01-097-6710 4720-98-850-0765 4720-98-104-9915 4720-01-200-8697 4720-00-289-8904 4720-01-432-1384
Restrictions 4720-01-432-1384
4720-01-432-1384 is a Air Duct Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4720-01-432-1384
- US Coast Guard (C056)
- Effective Date:
- 1 Jul 2010
- Former MOE Rule:
- C163
- Supplementary Receivers:
- XH
Approved Sources 4720-01-432-1384
- Part Number
- Manufacturer
- Status
- SCATS 10-192-8
- Manufacturer
- 98891 - Hbd Industries, Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 4720-01-432-1384
- Characteristic
- Specifications
- FIIG
- Specifications
- A229A0
- End Inside Diameter [CPYG]
- 1.245 Inches Nominal Both Ends
- End Item Identification [AGAV]
- Hh65 Coast Guard Helicopter
- Connection Style [AHNC]
- Round Both Ends
- Connection Type [AWLS]
- Preformed Both Ends
- Cross-Sectional Shape Style [AAGR]
- Round
- End Overall Length [AGQM]
- 2.520 Inches Nominal Both Ends
- Material [MATT]
- Fiberglass 1St Ply And Rubber Silicone Class Q 1St Ply
- Material [MATT]
- Fiberglass 2Nd Ply And Plastic Vinyl 2Nd Ply
- Material [MATT]
- Steel Reinforcing Wire
- Measuring Method And Length [CRXX]
- 48.250 Inches Nominal Overall
- Inside Diameter [AARX]
- 2.490 Inches Nominal First End
- Wall Thickness [AAGT]
- 0.035 Inches Nominal
- Style Designator [STYL]
- Helically Wound Continous Wire Supported
Management Data 4720-01-432-1384
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2010
- US Coast Guard (GP)
- EA
- Subscribe
- 1
- EA
Coast Guard
- Inventory Activity:
- A
- Appropriations Purchase Account item managed for the Coast Guard by the respective Inventory Control Point. An unfunded requisition is required
- Serial Number Control:
- 0
- Item not controlled by serial number
- Material Control:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 4720-01-432-1384
Freight Information 4720-01-432-1384
4720-01-432-1384 has freight characteristics.. 4720-01-432-1384 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
