4720-01-187-3387
Preformed Hose
4720011873387 011873387 5584015 LD-1501 12339136 5578665 4720PL0355691
A length of nonmetallic hose, molded to a predetermined shape and size. View more Preformed Hose
Managed by United States
NSN Created on 21 Aug 1984
Data Last Changed
September 2025
September 2025
NATO Update Count
22
22
NATO Data Quality
Marketplace 4720-01-187-3387
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Updated 47 Days Ago
12339135 HOSE 26 EA NS
12339136 HOSE 8 EA NS
12339136 HOSE 10 EA NS
12339136 HOSE 2 EA NS
12339136 HOSE 3 EA NS
1239136 HOSE 3 EA NS
5578665 HOSE 1 EA NS
5584015 HOSE 2 EA NS
5584015 HOSE 2 EA NS
5584015 HOSE 3 EA NS
F-12339136 HOSE 815 EA NS
F-12339136 HOSE 28 EA NS
Updated Every Day 4720-01-187-3387 RQST NE
Updated Every Day 4720-01-187-3387 RQST
Updated Every Day 4720-01-187-3387 RQST NE
Related Documents 4720-01-187-3387 5+ Documents (More...)
5584015 LD-1501 12339136 5578665 4720PL0355691 A length of nonmetallic hose, molded to a predetermined
Request Quotation 1239136 HOSE 3 EA NS Request Quotation 5578665 HOSE 1 EA NS Request Quotation 5584015
HOSE 815 EA NS Request Quotation 12339136 HOSE 3 EA NS Request Quotation 5584015 HOSE 2 EA HOSE 26 EA
Request Quotation 1239136 HOSE 3 EA NS Request Quotation 5578665 HOSE 1 EA NS Request Quotation 5584015
HOSE 815 EA NS Request Quotation 12339136 HOSE 3 EA NS Request Quotation 5584015 HOSE 2 EA HOSE 26 EA
for $1 a day Upgrade your Account Upgrade 4720-01-470-2217Nonmetallic Hose4720014702217 014702217 12339136
2 EA NS Request Quotation Subscribe to View Vendor Details... 12339136 HOSE,NONMETALLIC 2 EA NS Request
Preformed Hose 4720011873387 011873387, HOSE,PREFORMED 107 EA NS Request Quotation Subscribe to
2 EA NS Request Quotation Subscribe to View Vendor Details... 12339136 HOSE,NONMETALLIC 2 EA NS Request
Preformed Hose 4720011873387 011873387, HOSE,PREFORMED 107 EA NS Request Quotation Subscribe to
188-1370 4720-00-494-9388 4720-98-201-4653 4720-14-534-4295 4720-00-300-0866 4720-01-065-7198 4720-01-187-3387
494-9388 4720-98-201-4653 4720-14-534-4295 4720-01-187-3386 4720-00-300-0866 4720-01-065-7198 4720-01-187-3387
369-3758 Metallic Hose Assembly 576-5901-1504675REVAASSYERNCC: 5 | RNVC: 2 | DAC: 5 1 Jan 1961 4720-01-187-3387
Restrictions 4720-01-187-3387
4720-01-187-3387 is a Preformed Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4720-01-187-3387
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4720-01-187-3387
- US Army (A920)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZBS
- US Air Force (FXGC)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- FXAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GGGT
- Lithuania (WI01)
- Effective Date:
- 1 Mar 2004
- Poland (WP01)
- Effective Date:
- 1 Jun 2011
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Canada (ZC01)
- Effective Date:
- 1 Jul 2011
- Portugal (ZP01)
- Effective Date:
- 1 Feb 2013
- Greece (ZU01)
- Effective Date:
- 1 Apr 2006
Approved Sources 4720-01-187-3387
- Part Number
- Manufacturer
- Status
- 5584015
- Manufacturer
- 34623 - Am General Llc (Active)
- Primary Buy
- Primary Buy
- LD-1501
- 16563 - Contitech Usa, Inc. (Active)
- Primary Buy
- Primary Buy
- 12339136
- 34623 - Am General Llc (Active)
- Secondary Buy
- Secondary Buy
- 5578665
- 34623 - Am General Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4720011873387
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 4720PL0355691
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 4720011873387
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 4720-01-187-3387
- Characteristic
- Specifications
- FIIG
- Specifications
- A542B0
- Material [MATT]
- Rubber Synthetic Overall
- Style Designator [STYL]
- Two Bend
- Features Provided [CBBL]
- Enlarged Ends
- Wall Thickness [AAGT]
- 0.070 Inches Nominal
- Inside Diameter [AARX]
- 0.800 Inches Nominal
- Working Length [WKLG]
- 4.760 Inches Nominal
- First Arm Length [CBZX]
- 0.680 Inches Nominal
- Second Arm Length [CBZY]
- 0.600 Inches Nominal
Weapon Systems (WSDC) 4720-01-187-3387
DLA Procurement Analysis 4720-01-187-3387
- Last Stock Position:
- 13 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-01-187-3387
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 4720-01-187-3387
Freight Information 4720-01-187-3387
4720-01-187-3387 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-01-187-3387 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-01-187-3387 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-01-187-3387 is not classified as a special type of cargo when transported by water. 4720-01-187-3387 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-01-187-3387
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Procurement History 4720-01-187-3387 1 Records
Contracting Technical Data File (CTDF) 4720-01-187-3387 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- J
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
