4720-01-121-6687
Nonmetallic Hose Assembly
4720011216687 011216687 S86A90099-04-0147 R26093-4-0147 730928-4-0147 95272-0147 R206093-4-0147 2-43803-31 129051-4SS-0147
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
Managed by United States
NSN Created on 7 Nov 1981
Data Last Changed
November 2023
November 2023
NATO Update Count
23
23
NATO Data Quality
Marketplace 4720-01-121-6687
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
129051-4SS-0147 RQST NE
Updated Every Day 4720-01-121-6687 RQST NE
Updated Every Day 4720-01-121-6687 RQST
Updated Every Day 4720-01-121-6687 RQST NE
Related Documents 4720-01-121-6687 1+ Documents (More...)
S86A90099-04-0147 R26093-4-0147 730928-4-0147 95272-0147 R206093-4-0147 2-43803-31 129051-4SS-0147 A
Photo 1/3 4720-01-121-6687 Photo 2/3 NSN 4720-01-121-6687 (Identification) 3/3 - - - 1.
R206093-4-0147 HOSE ASSEMBLY,NONMETALLIC 1 EA NS Request Quotation R26093-4-0147 HOSE ASSEMBLY,NONMETALLIC
Photo 1/3 4720-01-121-6687 Photo 2/3 NSN 4720-01-121-6687 (Identification) 3/3 - - - 1.
R206093-4-0147 HOSE ASSEMBLY,NONMETALLIC 1 EA NS Request Quotation R26093-4-0147 HOSE ASSEMBLY,NONMETALLIC
Restrictions 4720-01-121-6687
4720-01-121-6687 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4720-01-121-6687
- US Air Force (FUGC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- FUAX
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Brazil (YA01)
- Effective Date:
- 1 Mar 2010
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4720-01-121-6687
- Part Number
- Manufacturer
- Status
- S86A90099-04-0147
- Manufacturer
- 32142 - Hydrasearch Company, Llc (Active)
- Primary Buy
- Primary Buy
- 129051-4SS-0147
- 98441 - Parker Hannifin Corp (Active)
- Primary Buy
- Primary Buy
- R26093-4-0147
- 50599 - Parker-Hannifin Corporation (Active)
- Primary Buy
- Primary Buy
- 2-43803-31
- 79U29 - Northrop Grumman Systems Corporation (Active)
- Secondary Buy
- Secondary Buy
- 730928-4-0147
- 00624 - Eaton Aeroquip Llc (Active)
- Secondary Buy
- Secondary Buy
- 95272-0147
- 78570 - Smiths Tubular Systems-Laconia, Inc. (Active)
- Secondary Buy
- Secondary Buy
- R206093-4-0147
- 50599 - Parker-Hannifin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2-43803-31
- 0JRC1 - Northrop Grumman Technical Services, (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- S86A90099-04-0147
- 14798 - Designed Metal Connections Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 129051-4SS-0147
- 03925 - Parker Hannifin Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2-43803-31
- 76823 - Northrop Grumman Systems Corporation (Active)
- Obsolete Drawing
- Obsolete Drawing
Datasheet 4720-01-121-6687
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Straight 1St End
- Burst Test Pressure [CQBD]
- 16000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Swivel Nut, Flareless 1St End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Exterior Color [ADJS]
- Black Or White Or Clear
- Hydrostatic Test Pressure [CRDW]
- 6000.0 Pounds Per Square Inch
- Maximum Operating Pressure [CQGM]
- 3000.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 14.875 Inches Nominal Overall
- Minimum Inside Bending Radius [ACKH]
- 1.500 Inches
- Nominal Thread Size [CQJX]
- 0.438 Inches 1St End
- Outside Diameter [ABKV]
- 0.390 Inches Nominal
- Inside Diameter [AARX]
- 0.212 Inches Nominal
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- 1St Layer Braided Corrosion Resistant Steel Wire And Outer Layer Braided Corrosion Resistant Steel Wire
- Seat Angle [CQRB]
- 12.0 Degrees 1St End
- Special Features [FEAT]
- Polytetrafluoroethylene Sleeve,0.020 In.Wall Thk
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit And 450.0 Deg Fahrenheit Single Response
- Thread Class [AAJD]
- 3B 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Series Designator [THSD]
- Unjf 1St End
Weapon Systems (WSDC) 4720-01-121-6687
DLA Procurement Analysis 4720-01-121-6687
- Last Stock Position:
- 7 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-01-121-6687
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- XJ
- F-5 FREEDOM FIGHTER
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4720-01-121-6687
4930-98-855-1116 4720-99-845-9126 4720-14-311-2847 4720-14-269-0904 4720-21-913-4339 4720-14-277-3699 4720-15-118-9773 4720-14-308-8664 4720-17-114-6295 4720-99-477-5829 4720-12-341-5895 4720-12-330-2083 4720-99-477-5984 4720-17-124-9106 4720-27-053-5411 4720-99-374-7025 4720-12-353-8651 4720-99-580-4201
Freight Information 4720-01-121-6687
4720-01-121-6687 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-01-121-6687 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4720-01-121-6687 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-01-121-6687 is not classified as a special type of cargo when transported by water. 4720-01-121-6687 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-01-121-6687
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 15.0" H x 4.0" W x 1.0" L
- --
- --
- --
- Any Suitable Process
- 15.0" H x 4.0" W x 1.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
