4720-01-094-9027
Air Duct Hose
4720010949027 010949027 8711053-1
A flexible, tubular item of light wall construction. It must have single or multiple layers of nonmetallic material, but may contain metal wire reinforcement, foil type liner, and/or woven or braided cover. It is designed to convey under low pressure gaseous material, such as air and fumes, and light weight solid materials, such as dust, powders, and fibers. For items with couplings, see HOSE ASSEMBLY, AIR DUCT. For items of sleeve section design rated for high pressure use, see SLEEVE, SEAL, COUPLING. Excludes hose, nonmetallic. View more Air Duct Hose
September 2025
14
Marketplace 4720-01-094-9027
Request a Quotation from participating marketplace vendors
Related Documents 4720-01-094-9027 5+ Documents (More...)
Photo 1/3 NSN 4720-01-094-9027 (Identification) 2/3 NSN 4720-01-094-9027 (Identification) 3/3 -
Day 4720-01-094-9027 RQST Updated Every Day 4720-01-094-9027 RQST NE Related Documents 4720-01-094-9027
Air Duct Hose 4720010949027 010949027 Upgrade for $1 a day Upgrade your Account Upgrade 4720-01
-094-9027Air Duct Hose4720010949027 010949027 8711053 https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720
Air Duct Hose 4720010949027 010949027 https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720 https//
104-9915 4720-00-495-6214 4720-01-200-8697 4720-00-289-8904 4720-00-535-1994 4720-00-808-7904 4720-01-094-9027
Restrictions 4720-01-094-9027
4720-01-094-9027 is a Air Duct Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4720-01-094-9027
- US Army (A920)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZBF
- Austria (WB01)
- Effective Date:
- 1 Aug 2006
- Spain (YB01)
- Effective Date:
- 1 Apr 1998
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
Approved Sources 4720-01-094-9027
- Part Number
- Manufacturer
- Status
- 8711053-1
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 4720-01-094-9027
- Characteristic
- Specifications
- FIIG
- Specifications
- A229A0
- Connection Type [AWLS]
- Plain Both Ends
- Cross-Sectional Shape Style [AAGR]
- Round
- Material [MATT]
- Fiberglass 1St Ply And Rubber Chloroprene Class Cr 1St Ply
- Material [MATT]
- Fiberglass 2Nd Ply And Rubber Chloroprene Class Cr 2Nd Ply
- Material [MATT]
- Fiberglass Cover And Rubber Chloroprene Class Cr Cover
- Material [MATT]
- Steel Reinforcing Wire
- Maximum Operating Pressure [CQGM]
- 50.0 Pounds Per Square Inch
- Inside Diameter [AARX]
- 1.250 Inches Nominal First End
- Style Designator [STYL]
- Helically Wound Continous Wire Supported
Weapon Systems (WSDC) 4720-01-094-9027
DLA Procurement Analysis 4720-01-094-9027
Management Data 4720-01-094-9027
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 4720-01-094-9027
Freight Information 4720-01-094-9027
4720-01-094-9027 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051035. A Sub NMFC of Z. It has a NMFC Description of DUCTS:AIR SYSTEM. 4720-01-094-9027 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33815 which rates the freight between FCL and LCL. 4720-01-094-9027 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-01-094-9027 is not classified as a special type of cargo when transported by water. 4720-01-094-9027 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-01-094-9027
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 4720-01-094-9027 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- K
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
