4720-01-088-1087

Nonmetallic Hose

4720010881087 010881087 A-A-52426 A52426-1R BULK A52426-1R-BULK M62217/1-40-BULK M62217/1-40 A52426-1R M62217/1-40BULK A 52426-1R BULK M62217-1-40

A flexible, tubular item having a nonmetallic tube inner conveying surface and one or more reinforcement layers of a metallic or nonmetallic material. It is designed to convey gasses, liquids, or solids. For items with fittings on one or both ends, see HOSE ASSEMBLY, NONMETALLIC. Excludes HOSE, AIR DUCT; and HOSE AIR DUCT, AIR BREATHING. View more Nonmetallic Hose

Managed by United States

NSN Created on 6 Jan 1980

Data Last Changed
November 2023

NATO Update Count
39

NATO Data Quality

4720-01-088-1087 HOSE,NONMETALLIC 4720010881087 010881087 1/2 — 4720-01-088-1087 Photo 1/2

AAGR Style B1 for 4720-01-088-1087 2/2 — NSN 4720-01-088-1087 (Identification) 2/2

Marketplace 4720-01-088-1087

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

M62217/1-40BULK HOSE,NONMETALLIC 3 FT NS

Subscribe to View Vendor Details...

M62217-1-40 HOSE,NONMETALLIC 1 FT NS

A852426-1RBULK HOSE,NONMETALLIC 1 FT NS

A52426-1RBULK HOSE,NONMETALLIC 1 FT NS

M622171-40BULK HOSE,NONMETALLIC 1 FT NS

Subscribe to View Vendor Details...

M62217 HOSE,NONMETALLIC 1 FT NS

Subscribe to View Vendor Details...

4720-01-088-1087 HOSE,NONMETALLIC 10 FT NS

Updated Every 15 Minutes

4720-01-088-1087 BUY NE

Updated Every Day

4720-01-088-1087 RQST NE

Updated Every Day

4720-01-088-1087 RQST

Updated Every Day

4720-01-088-1087 RQST NE

Restrictions 4720-01-088-1087

4720-01-088-1087 is a Nonmetallic Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

End Users 4720-01-088-1087

US Army (A920)
Effective Date:: 1 Apr 2005
Former MOE Rule:: A181
Supplementary Receivers:: AZBF; AMC 1 AMSC G IMC Z IMCACTY AZ

US Air Force (FXGC)
Effective Date:: 1 Apr 2005
Former MOE Rule:: FXAX; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC40)
Effective Date:: 1 Apr 2005
Former MOE Rule:: MC01; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Dec 2013
Supplementary Collaborators:: GG; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Aug 2006

Spain (YB01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Jan 2015

Germany (ZG01)
Effective Date:: 1 Jan 2015

Republic of Korea (ZH01)
Effective Date:: 1 Aug 1995

Italy (ZR01)
Effective Date:: 1 Oct 2009

Denmark (ZS01)
Effective Date:: 1 Mar 1994

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Jul 1995

Approved Sources 4720-01-088-1087

Part Number
Manufacturer
Status
A52426-1R BULK: 58536 - Federal Commercial Item Description (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
A52426-1R-BULK: 58536 - Federal Commercial Item Description (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
A-A-52426: 58536 - Federal Commercial Item Description (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
M62217/1-40-BULK: A9271 - Goriziane Group Spa (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
M62217/1-40: A9271 - Goriziane Group Spa (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
M62217/1-40BULK: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
A 52426-1R BULK: 80244 - General Services Administration (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
M62217-1-40: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
A52426-1R: 58536 - Federal Commercial Item Description (Active); Transferred; RNCC E RNVC 8 DAC E

Datasheet 4720-01-088-1087

Characteristic
Specifications
FIIG: A541Z0
Burst Test Pressure [CQBD]: 250.0 Pounds Per Square Inch Single Response
Cross-Sectional Shape Style [AAGR]: Round
Material [MATT]: Rubber Silicone Class Q Tube
Nondefinitive Spec/Std Data [ZZZT]: 1 Type And 2 Class
Outer Covering Environmental Protection [CRJM]: Abrasion Resistant And Heat Resistant And Oil Resistant And Ozone Resistant And Vibration Resistant
Outside Diameter [ABKV]: 2.890 Inches Nominal
Inside Diameter [AARX]: 2.500 Inches Nominal
Inside Surface Condition [CRWL]: Smooth
Layer Composition And Location [CQCS]: 1St Layer Braided Wire Err-100
Layer Composition And Location [CQCS]: Outer Layer Rubber Impregnated Braided Fabric Err-100
Specification/Standard Data [ZZZK]: 81349-Mil-H-62217 Government Specification
Temp Rating [ABJH]: -65.0 Deg Fahrenheit Single Response

Weapon Systems (WSDC) 4720-01-088-1087

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 4720-01-088-1087

Last Stock Position:: 438 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 4720-01-088-1087

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Jan 2023: Defense Logistics Agency (DS); FT; Subscribe
Oct 2022: Department of the Army (DA); FT; Subscribe
Jan 2022: Department of the Air Force (DF); FT; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); FT; Subscribe
Oct 2020: Defense Logistics Agency (DS); FT; Subscribe
Feb 2020: Department of the Air Force (DF); FT; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SX: SICA RESIDUAL MMAC-OC-ALC

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

2: Non-Critical Repair Part

Echelon Management:

B2

Operational Test:

: No Special Procedures

Physical Category:

1: Bin

NATO Stock Numbers Related to 4720-01-088-1087

4720-12-392-0446 4720-37-510-9232 4720-12-194-5799 4720-22-610-5762 4720-99-811-9139 4720-17-052-8865 4720-17-123-9470 4720-66-031-6915 4720-12-185-8792 4720-14-566-1412 4720-22-606-2390 4720-12-323-7535 4720-99-746-2534 4720-99-782-4401 4720-99-758-5011 4720-66-063-0461 4720-66-103-9501 4720-37-509-1704

Freight Information 4720-01-088-1087

4720-01-088-1087 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-01-088-1087 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-01-088-1087 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-01-088-1087 is not classified as a special type of cargo when transported by water. 4720-01-088-1087 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 4720-01-088-1087

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; --; --

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement

Procurement History 4720-01-088-1087 10 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7M122P4304: 14 Mar 2022; Subscribe; 354; Subscribe; Subscribe
SPE7M421V2643: 21 May 2021; Subscribe; 194; Subscribe; Subscribe
SPE7M418V2483: 06 Jan 2018; Subscribe; 488; Subscribe; Subscribe
SPE7M417V0468: 16 Dec 2016; Subscribe; 1017; Subscribe; Subscribe
SPE7M417V0065: 14 Oct 2016; Subscribe; 447; Subscribe; Subscribe
SPE7MC16VA090: 27 Jul 2016; Subscribe; 187; Subscribe; Subscribe
SPE7M116V8070: 29 Feb 2016; Subscribe; 192; Subscribe; Subscribe
SPE7M116V3214: 25 Nov 2015; Subscribe; 281; Subscribe; Subscribe
SPE7L014V0846: 17 Dec 2013; Subscribe; 20; Subscribe; Subscribe
SPE7M413V0639: 16 Aug 2013; Subscribe; 766; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 4720-01-088-1087 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
