4720-01-069-7708
Nonmetallic Hose Assembly
4720010697708 010697708 F2132867060606-16.000 5137958 2132867-6-6-6-16.00 FA2408GGG0160 FA2408GGG0160AB 213R6-IS6-I45S6-16 5130687
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
Managed by United States
NSN Created on 23 Dec 1978
Data Last Changed
March 2025
March 2025
NATO Update Count
21
21
NATO Data Quality
Marketplace 4720-01-069-7708
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4720-01-069-7708 5+ Documents (More...)
F2132867060606-16.000 5137958 2132867-6-6-6-16.00 FA2408GGG0160 FA2408GGG0160AB 213R6-IS6-I45S6-16 5130687
9 EA NS Request Quotation Updated Every Day 2132867-6-6-6-16.00 RQST NE Updated Every Day 213R6-IS6-
//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-01-069-7708 Nonmetallic Hose Assembly 4720010697708 F2132867060606
9 EA NS Request Quotation Updated Every Day 2132867-6-6-6-16.00 RQST NE Updated Every Day 213R6-IS6-
//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-01-069-7708 Nonmetallic Hose Assembly 4720010697708 F2132867060606
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869 -6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-01-069-7708 Nonmetallic Hose Assembly 4720010697708
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-01-069-7708 Nonmetallic Hose Assembly 4720010697708
Account Upgrade 4720-01-099-3709Nonmetallic Hose Assembly4720010993709 010993709 5131803 FA2406EGG0524 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869 -6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869 -6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
your Account Upgrade 4720-00-081-3481Nonmetallic Hose Assembly4720000813481 000813481 FG1190EGG0226 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869 -6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Assembly4720012385995 012385995 FA2409GGG0084 5138050 2132869-6-6-6-8.50 213-27587-27751-6-8 1/2 5130687
Restrictions 4720-01-069-7708
4720-01-069-7708 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4720-01-069-7708
- US Army (A920)
- Effective Date:
- 1 Apr 2006
- Supplementary Receivers:
- AZ
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2006
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Lithuania (WI)
- Lithuania (WI01)
- Effective Date:
- 1 Feb 2001
- Brazil (YA)
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Malaysia (YW)
- Malaysia (YW01)
- Effective Date:
- 1 Sep 2005
- Australia (ZA)
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW)
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
- United States of America (ZZ)
Approved Sources 4720-01-069-7708
- Part Number
- Manufacturer
- Status
- F2132867060606-16.000
- Manufacturer
- 87373 - Parker-Hannifin Corporation (Active)
- Primary Buy
- Primary Buy
- 5137958
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Secondary Buy
- Secondary Buy
- 2132867-6-6-6-16.00
- 98441 - Parker Hannifin Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- FA2408GGG0160
- 01276 - Danfoss Power Solutions Ii, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4720010697708
- A00AM - E.C.A Etablissement Central Des (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- FA2408GGG0160AB
- 01276 - Danfoss Power Solutions Ii, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 213R6-IS6-I45S6-16
- 98441 - Parker Hannifin Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5130687
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Informational Drawing
- Informational Drawing
Datasheet 4720-01-069-7708
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Elbow 2Nd End
- End Connection Design [AKUU]
- Straight 1St End
- Burst Test Pressure [CQBD]
- 4000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Swivel Nut, Inverted Flare 1St End
- Connection Style [AHNC]
- Swivel Nut, Inverted Flare 2Nd End
- Connection Type [AWLS]
- Threaded External Tube 2Nd End
- Connection Type [AWLS]
- Threaded External Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Exterior Color [ADJS]
- Black
- Features Provided [CBBL]
- Reusable End Fittings
- Flow Angle [CRFY]
- 45.0 Degrees 2Nd End
- Hydrostatic Test Pressure [CRDW]
- 2000.0 Pounds Per Square Inch
- Maximum Operating Pressure [CQGM]
- 1000.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 16.000 Inches Nominal Working
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Minimum Inside Bending Radius [ACKH]
- 2.000 Inches
- Nominal Thread Size [CQJX]
- 0.625 Inches 2Nd End
- Nominal Thread Size [CQJX]
- 0.625 Inches 1St End
- Outer Covering Environmental Protection [CRJM]
- Oil Resistant
- Outside Diameter [ABKV]
- 0.610 Inches Nominal
- Inside Diameter [AARX]
- 0.312 Inches Nominal
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- 1St Layer Braided Corrosion Resistant Steel Wire, Partial Coverage And Outer Layer Rubber Impregnated Braided Fabric
- Seat Angle [CQRB]
- 45.0 Degrees 1St End
- Seat Angle [CQRB]
- 45.0 Degrees 2Nd End
- Vacuum In Torr [CRSM]
- 50.8
- Temp Rating [ABJH]
- -40.0 Deg Fahrenheit And 300.0 Deg Fahrenheit Single Response
- Thread Class [AAJD]
- 3A 2Nd End
- Thread Class [AAJD]
- 3A 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Direction [AAJF]
- Right-Hand 2Nd End
- Thread Series Designator [THSD]
- Unf 1St End
- Thread Series Designator [THSD]
- Unf 2Nd End
Weapon Systems (WSDC) 4720-01-069-7708
DLA Procurement Analysis 4720-01-069-7708
- Last Stock Position:
- 556 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-01-069-7708
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2023
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Mar 2023
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4720-01-069-7708
Freight Information 4720-01-069-7708
4720-01-069-7708 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-01-069-7708 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-01-069-7708 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-01-069-7708 is not classified as a special type of cargo when transported by water. 4720-01-069-7708 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Procurement History 4720-01-069-7708 10 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7M123V4834
- 16 Mar 2023
- Subscribe
- 792
- Subscribe
- Subscribe
- Subscribe
- SPE7M422V0127
- 25 Feb 2022
- Subscribe
- 249
- Subscribe
- Subscribe
- Subscribe
- SPE7M422V1614
- 02 Feb 2022
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPE7M418V2846P00001
- 24 Jan 2018
- Subscribe
- 230
- Subscribe
- Subscribe
- Subscribe
- SPE7MC16V3059
- 21 Jan 2016
- Subscribe
- 171
- Subscribe
- Subscribe
- Subscribe
- SPE7M416V0474
- 28 Dec 2015
- Subscribe
- 144
- Subscribe
- Subscribe
- Subscribe
- SPE7M416V0235
- 10 Nov 2015
- Subscribe
- 217
- Subscribe
- Subscribe
- Subscribe
- SPE7M115VJ225
- 24 Sep 2015
- Subscribe
- 83
- Subscribe
- Subscribe
- Subscribe
- SPE7M414V2404
- 07 Aug 2014
- Subscribe
- 423
- Subscribe
- Subscribe
- Subscribe
- SPE7M413M1067
- 23 Sep 2013
- Subscribe
- 344
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 4720-01-069-7708 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
