4720-00-999-9840
Preformed Hose
4720009999840 009999840 10954290 CPR-10954290
A length of nonmetallic hose, molded to a predetermined shape and size. View more Preformed Hose
November 2023
25
Marketplace 4720-00-999-9840
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-999-9840 5+ Documents (More...)
/fsg-47/fsc-4720/us
Photo 1/2 NSN 4720-00-999-9840 (Identification) 2/2 - - 1.
Day 4720-00-999-9840 RQST Updated Every Day 4720-00-999-9840 RQST NE Related Documents 4720-00-999-9840
/fsg-99/fsc-9999/uk
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/it
/fsg-99/fsc-9999/dk
Restrictions 4720-00-999-9840
4720-00-999-9840 is a Preformed Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4720-00-999-9840
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4720-00-999-9840
- US Army (A920)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZBF
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Feb 2013
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
Approved Sources 4720-00-999-9840
- Part Number
- Manufacturer
- Status
- CPR-10954290
- Manufacturer
- 83397 - Crown Products Co (Obsolete)
- Original Design
- Original Design
- 10954290
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
Datasheet 4720-00-999-9840
- Characteristic
- Specifications
- FIIG
- Specifications
- A542B0
- Bend Radius [AGSJ]
- 3.062 Inches Nominal
- First Arm Length [CBZX]
- 3.374 Inches Nominal
- Material Document And Classification [MDCL]
- Zz-H-428,Type 4,Grade A,Class 2 Fed Spec Single Material Response Cover
- Material Document And Classification [MDCL]
- Zz-H-428,Type 4,Grade A,Class 2 Fed Std Single Material Response Overall
- Material [MATT]
- Rubber Overall
- Material [MATT]
- Rubber Synthetic Cover
- Offset Distance [ACSX]
- 4.844 Inches Nominal
- Outer Radius [AHPP]
- 3.062 Inches Nominal
- Inside Diameter [AARX]
- 1.500 Inches Nominal
- Second Arm Length [CBZY]
- 8.031 Inches Nominal
- Wall Thickness [AAGT]
- 0.188 Inches Nominal
- Width [ABGL]
- 4.312 Inches Nominal
- Working Length [WKLG]
- 20.375 Inches Nominal
- Style Designator [STYL]
- Two Bend
Weapon Systems (WSDC) 4720-00-999-9840
DLA Procurement Analysis 4720-00-999-9840
- Last Stock Position:
- 265 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-00-999-9840
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- KF
- Combat Vehicles
Howitzer, Full Tracked, Self- propelled 155mm M109
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4720-00-999-9840
Freight Information 4720-00-999-9840
4720-00-999-9840 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-999-9840 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4720-00-999-9840 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-999-9840 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-999-9840 is not classified as a special type of cargo when transported by water. 4720-00-999-9840 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-999-9840
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 22.0" H x 4.0" W x 4.0" L
- --
- --
- --
- --
- 22.0" H x 4.0" W x 4.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 4720-00-999-9840 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- J
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
