4720-00-999-8589
Air Duct Hose Assembly
4720009998589 009998589 11593606
A length of HOSE, AIR DUCT with couplings on one or both ends. Excludes items which include a branch hose or fork hose, HOSE ASSEMBLY, NONMETALLIC. View more Air Duct Hose Assembly
August 2025
32
Marketplace 4720-00-999-8589
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-999-8589 3+ Documents (More...)
NE Updated Every Day 4720-00-999-8589 RQST Updated Every Day 4720-00-999-8589 RQST NE Related Documents
4720-00-999-8589 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-999-8589
-3 GASKET 42 EA NS Request Quotation Subscribe to View Vendor Details... 11593606-3 GASKET RQST NS Request
www.nsnlookup.com /fsg-53/fsc-5330/us 5330-00-999-8583 Gasket 5330009998583 009998583,11593606-3 11593606
Restrictions 4720-00-999-8589
4720-00-999-8589 is a Air Duct Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4720-00-999-8589
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4720-00-999-8589
- US Army (A920)
- Effective Date:
- 1 Aug 2010
- Former MOE Rule:
- A203
- Supplementary Receivers:
- AZBF
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Jan 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 10 Nov 2010
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4720-00-999-8589
- Part Number
- Manufacturer
- Status
- 11593606
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 4720009998589
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4720-00-999-8589
- Characteristic
- Specifications
- FIIG
- Specifications
- A229A0
- End Inside Diameter [CPYG]
- 6.000 Inches Nominal First End
- Connection Style [AHNC]
- Round Both Ends
- Cross-Sectional Shape Style [AAGR]
- Round
- End Overall Length [AGQM]
- 1.500 Inches Nominal First End
- Features Provided [CBBL]
- Ozone Resistant And Scuff Strip
- Measuring Method And Length [CRXX]
- 22.313 Inches Nominal Overall
- Minimum Inside Bending Radius [ACKH]
- 9.000 Inches
- Material [MATT]
- Aluminum Alloy 2Nd End Coupling
- Material [MATT]
- Plastic Polyamide And Rubber Synthetic 2Nd Ply
- Material [MATT]
- Rubber Chloroprene Class Cr 1St Ply
- Material [MATT]
- Steel Reinforcing Wire
- Inside Diameter [AARX]
- 6.000 Inches Nominal First End
- Material Document And Classification [MDCL]
- Alloy 2024 National Spec Single Material Response 2Nd End Coupling
- Wall Thickness [AAGT]
- 0.060 Inches Nominal
- Style Designator [STYL]
- Helically Wound Continous Wire Supported
- Surface Treatment [SFTT]
- Anodize 2Nd End Coupling
Weapon Systems (WSDC) 4720-00-999-8589
DLA Procurement Analysis 4720-00-999-8589
- Last Stock Position:
- 21 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-00-999-8589
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- KF
- Combat Vehicles
Howitzer, Full Tracked, Self- propelled 155mm M109
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4720-00-999-8589
Freight Information 4720-00-999-8589
4720-00-999-8589 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-999-8589 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-999-8589 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4720-00-999-8589 is not classified as a special type of cargo when transported by water. 4720-00-999-8589 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-999-8589
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 4720-00-999-8589 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
