4720-00-902-0192

Nonmetallic Hose Assembly

4720009020192 009020192 10951869 245033-1

A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly

Managed by United States

NSN Created on 1 Jan 1960

Data Last Changed
April 2025

NATO Update Count
27

NATO Data Quality

4720-00-902-0192 HOSE ASSEMBLY,NONMETALLIC 4720009020192 009020192 1/2 — 4720-00-902-0192 Photo 1/2

AAGR Style A1 for 4720-00-902-0192 2/2 — NSN 4720-00-902-0192 (Identification) 2/2

Marketplace 4720-00-902-0192

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

4720-00-902-0192 HOSE ASSEMBLY,NONMETALLIC 89 EA NS

Subscribe to View Vendor Details...

10951869 HOSE ASSEMBLY,NONMETALLIC RQST NS

Subscribe to View Vendor Details...

4720-00-902-0192 HOSE ASSEMBLY,NONMETALLIC 10 EA NS

Updated Every Day

245033-1 RQST NE

Updated Every Day

4720-00-902-0192 RQST NE

Updated Every Day

4720-00-902-0192 RQST

Updated Every Day

4720-00-902-0192 RQST NE

Restrictions 4720-00-902-0192

4720-00-902-0192 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 4720-00-902-0192

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 4720-00-902-0192

US Army (A920)
Effective Date:: 1 Aug 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZ; AMC 1 AMSC G IMC Z IMCACTY AZ

US Marine Corps (MC40)
Effective Date:: 1 Aug 2006
Former MOE Rule:: MC01; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Dec 2013
Supplementary Collaborators:: GG; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Brazil (YA01)
Effective Date:: 1 Mar 2001

Spain (YB01)
Effective Date:: 1 Oct 1998

Israel (YD01)
Effective Date:: 1 Aug 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Jul 1995

Turkey (ZW01)
Effective Date:: 1 Nov 2003

Approved Sources 4720-00-902-0192

Part Number
Manufacturer
Status
10951869: 19207 - U S Army Tank Automotive Command (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
245033-1: 98441 - Parker Hannifin Corp (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
4720009020192: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 4720-00-902-0192

Characteristic
Specifications
FIIG: A542A0
End Connection Design [AKUU]: Straight 1St End
End Connection Design [AKUU]: Straight 2Nd End
Burst Test Pressure [CQBD]: 8000.0 Pounds Per Square Inch
Connection Style [AHNC]: Flareless 1St End
Connection Style [AHNC]: Plain 2Nd End
Connection Type [AWLS]: Threaded External Pipe 2Nd End
Connection Type [AWLS]: Threaded External Tube 1St End
Cross-Sectional Shape Style [AAGR]: Round
Hydrostatic Test Pressure [CRDW]: 4000.0 Pounds Per Square Inch
Maximum Operating Pressure [CQGM]: 2000.0 Pounds Per Square Inch
Measuring Method And Length [CRXX]: 13.006 Inches Nominal Overall
Media For Which Designed [MEDA]: Fuel/Oil, Hydrocarbon Single Response
Nominal Thread Size [CQJX]: 0.500 Inches 2Nd End
Nominal Thread Size [CQJX]: 0.938 Inches 1St End
Outer Covering Environmental Protection [CRJM]: Mildew Resistant And Oil Resistant And Oil Resistant
Outside Diameter [ABKV]: 0.906 Inches Nominal
Inside Diameter [AARX]: 0.500 Inches Nominal
Inside Surface Condition [CRWL]: Smooth
Layer Composition And Location [CQCS]: 1St Layer Braided Steel Wire And Outer Layer Molded Rubber
Seat Angle [CQRB]: 37.0 Degrees 1St End
Temp Rating [ABJH]: -65.0 Deg Fahrenheit And 250.0 Deg Fahrenheit Single Response
Thread Class [AAJD]: 2A 1St End
Thread Direction [AAJF]: Right-Hand 1St End
Thread Direction [AAJF]: Right-Hand 2Nd End
Thread Series Designator [THSD]: Nptf 2Nd End
Thread Series Designator [THSD]: Unf 1St End
Thread Quantity Per Inch [CMLP]: 14 2Nd End
Thread Quantity Per Inch [CMLP]: 16 1St End

Weapon Systems (WSDC) 4720-00-902-0192

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 4720-00-902-0192

Last Stock Position:: 416 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 4720-00-902-0192

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2021: US Marine Corps (DM); EA; Subscribe; 1
Apr 2021: Defense Logistics Agency (DS); EA; Subscribe; 1
Feb 2021: US Marine Corps (DM); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

Similar Supply Items to 4720-00-902-0192

Freight Information 4720-00-902-0192

4720-00-902-0192 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-902-0192 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4720-00-902-0192 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-902-0192 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-902-0192 is not classified as a special type of cargo when transported by water. 4720-00-902-0192 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 4720-00-902-0192

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Non-Metallic Item; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 10.0" H x 4.0" W x 1.0" L; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag; Type I, shelf life

Intermediate Pack Level

Quantity of Unit Packs
Container: Any Suitable Fiber Box
