4720-00-535-7615
Air Duct Hose
4720005357615 005357615 MIL-PRF-62028 8724787 M62028236466132 MIL-H-62028 10113392
A flexible, tubular item of light wall construction. It must have single or multiple layers of nonmetallic material, but may contain metal wire reinforcement, foil type liner, and/or woven or braided cover. It is designed to convey under low pressure gaseous material, such as air and fumes, and light weight solid materials, such as dust, powders, and fibers. For items with couplings, see HOSE ASSEMBLY, AIR DUCT. For items of sleeve section design rated for high pressure use, see SLEEVE, SEAL, COUPLING. Excludes hose, nonmetallic. View more Air Duct Hose
March 2025
43
Marketplace 4720-00-535-7615
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-535-7615 5+ Documents (More...)
MIL-PRF-62028 HOSE,AIR DUCT 108 EA HOSE,AIR MIL-H-62028 https//www.nsnlookup.com /fsg-47/fsc-4720/us
HOSE,AIR DUCT 3 EA NS Request Quotation MIL-PRF-62028 HOSE,AIR DUCT HOSE,AIR HOSE,AIR MIL-H-62028
MIL-H-62028 HOSE,AIR DUCT 3 EA NS Request Quotation MIL-PRF-62028 HOSE,AIR DUCT 108 EA NS Request Quotation
Air Duct Hose 4720005357615 005357615 108 EA HOSE,AIR MIL-H-62028 HOSE,AIR DUCT 3 EA https//www.nsnlookup.com
HOSE,AIR HOSE,AIR MIL-H-62028 HOSE,AIR DUCT 3 EA NS Request Quotation MIL-PRF-62028 HOSE,AIR DUCT https
HOSE,AIR MIL-H-62028 HOSE,AIR DUCT 3 EA NS Request Quotation MIL-PRF-62028 HOSE,AIR DUCT https
MIL-PRF-62028 HOSE,AIR DUCT 108 EA NS Request Quotation MIL-H-62028 HOSE,AIR DUCT 3 EA NS Request Quotation
3 EA NS Request Quotation MIL-PRF-62028 HOSE,AIR DUCT 108 EA HOSE,AIR MIL-H-62028 HOSE,AIR DUCT 3 EA
/fsc-9999/uk 9999-99-146-9443 Air Duct Hose 9999991469443991469443 497-9934 4720-01-087-2121 4720-00-535-7615
200-8697 4720-00-289-8904 4720-00-535-1994 4720-00-808-7904 4720-01-432-1384 4720-01-087-2121 4720-00-535-7615
Restrictions 4720-00-535-7615
4720-00-535-7615 is a Air Duct Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4720-00-535-7615
- US Army (A920)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- BD
- US Air Force (FXGC)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- FXAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- NICD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Finland (WF01)
- Effective Date:
- 1 Jun 2009
- Spain (YB01)
- Effective Date:
- 1 Oct 1998
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Aug 1997
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4720-00-535-7615
- Part Number
- Manufacturer
- Status
- M62028236466132
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-62028
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 8724787
- 19207 - U S Army Tank Automotive Command (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MIL-H-62028
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 10113392
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
- 4720005357615
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 4720-00-535-7615
- Characteristic
- Specifications
- FIIG
- Specifications
- A229A0
- Connection Type [AWLS]
- Plain Both Ends
- Cross-Sectional Shape Style [AAGR]
- Round
- Features Provided [CBBL]
- Ozone Resistant
- Material [MATT]
- Fiberglass 1St Ply And Rubber Silicone Class Q 1St Ply
- Material [MATT]
- Fiberglass 2Nd Ply And Rubber Silicone Class Q 2Nd Ply
- Material [MATT]
- Fiberglass Reinforcing Cord And Rubber Silicone Class Q Reinforcing Cord
- Material [MATT]
- Steel Reinforcing Wire
- Measuring Method And Length [CRXX]
- 132.000 Inches Nominal Overall
- Minimum Inside Bending Radius [ACKH]
- 4.000 Inches
- Nondefinitive Spec/Std Data [ZZZT]
- 3 Class And 3 Type
- Inside Diameter [AARX]
- 4.000 Inches Nominal First End
- Wall Thickness [AAGT]
- 0.111 Inches Nominal
- Specification/Standard Data [ZZZK]
- 81349-Mil-H-62028 Government Specification
- Style Designator [STYL]
- Helically Wound Continous Wire Supported
Weapon Systems (WSDC) 4720-00-535-7615
DLA Procurement Analysis 4720-00-535-7615
- Last Stock Position:
- 28 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-00-535-7615
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2021
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 4720-00-535-7615
Freight Information 4720-00-535-7615
4720-00-535-7615 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051035. A Sub NMFC of Z. It has a NMFC Description of DUCTS:AIR SYSTEM. 4720-00-535-7615 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33815 which rates the freight between FCL and LCL. 4720-00-535-7615 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-535-7615 is not classified as a special type of cargo when transported by water. 4720-00-535-7615 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-535-7615
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 18.0" H x 18.0" W x 12.0" L
- --
- --
- Physical Protection
- Any Suitable Process
- 18.0" H x 18.0" W x 12.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- ASTM - D5118, Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 4720-00-535-7615 2 Records
Contracting Technical Data File (CTDF) 4720-00-535-7615 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
