4720-00-420-8657
Nonmetallic Hose Assembly
4720004208657 004208657 S6167-63000 S6167-63000-4 SS45CT1A140000 AE2463827E0140 000AE50-4W0140 66000004-0140J SS45T1A140000
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
May 2023
7
Marketplace 4720-00-420-8657
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-420-8657 5+ Documents (More...)
RQST NE Updated Every Day 4720-00-420-8657 RQST Updated Every Day 4720-00-420-8657 RQST NE Related
Documents 4720-00-420-8657 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720
JavaScript in your web browser . 4720-00-017-2413Hydraulic Hose Assembly4720000172413 000172413 S6167-63000
Nonmetallic Hose Assembly 4720004208657 Upgrade your Account Upgrade 4720-00-420-8657Nonmetallic
Marketplace Restrictions Approved Sources Datasheet https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-420-8657
Nonmetallic Hose Assembly 4720004208657 Subscribe to View Vendor Details... 000AE50-4W0140 HOSE
JavaScript in your web browser . 4720-00-017-2413Hydraulic Hose Assembly4720000172413 000172413 S6167-63000
www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-017-2413 https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-420-8657
Similar Supply Items to 9999-99-617-2611 4720-00-067-4142 4720-00-883-2233 4720-00-404-7073 4720-00-420-8657
Restrictions 4720-00-420-8657
4720-00-420-8657 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4720-00-420-8657
- Italy (ZR01)
- Effective Date:
- 1 Jul 1999
Approved Sources 4720-00-420-8657
- Part Number
- Manufacturer
- Status
- S6167-63000-4
- Manufacturer
- 78286 - Sikorsky Aircraft Corporation (Active)
- Primary Buy
- Primary Buy
- SS45CT1A140000
- 78286 - Sikorsky Aircraft Corporation (Active)
- Primary Buy
- Primary Buy
- S6167-63000
- 78286 - Sikorsky Aircraft Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- AE2463827E0140
- 00624 - Eaton Aeroquip Llc (Active)
- Secondary Buy
- Secondary Buy
- 000AE50-4W0140
- 50599 - Parker-Hannifin Corporation (Active)
- Secondary Buy
- Secondary Buy
- 66000004-0140J
- 78570 - Smiths Tubular Systems-Laconia, Inc. (Active)
- Secondary Buy
- Secondary Buy
- SS45T1A140000
- 78286 - Sikorsky Aircraft Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4720-00-420-8657
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Straight 1St End
- Burst Test Pressure [CQBD]
- 16000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Swivel Nut Flare 1St End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Features Provided [CBBL]
- Electrostatic Discharge Capability
- Maximum Operating Pressure [CQGM]
- 3000.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 14.688 Inches Nominal Overall
- Minimum Inside Bending Radius [ACKH]
- 3.000 Inches
- Nominal Thread Size [CQJX]
- 0.438 Inches 1St End
- Outer Covering Environmental Protection [CRJM]
- Corrosion Resistant
- Outside Diameter [ABKV]
- 0.469 Inches Nominal
- Inside Diameter [AARX]
- 0.219 Inches Nominal
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- Outer Layer Braided Corrosion Resistant Steel Wire And 1St Layer Braided Corrosion Resistant Steel Wire
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit And 400.0 Deg Fahrenheit Single Response
- Thread Class [AAJD]
- 3B 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Series Designator [THSD]
- Unf 1St End
Similar Supply Items to 4720-00-420-8657
Freight Information 4720-00-420-8657
4720-00-420-8657 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-420-8657 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-420-8657 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 772 for ocean manifesting and military sealift. 4720-00-420-8657 is not classified as a special type of cargo when transported by water. 4720-00-420-8657 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-420-8657
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- No Requirement
- --
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
