4720-00-420-4396
Nonmetallic Hose Assembly
4720004204396 004204396 111417-8D-0134 67C44051 MS28741-8-0134 360-8D0134 AN6271-8-13 1-2
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
Managed by United States
NSN Created on 14 Mar 1969
Data Last Changed
July 2025
July 2025
NATO Update Count
37
37
NATO Data Quality
Marketplace 4720-00-420-4396
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-420-4396 2+ Documents (More...)
111417-8D-0134 67C44051 MS28741-8-0134 360-8D0134 AN6271-8-13 1-2 A length of nonmetallic hose with
RQST NE Updated Every Day 4720-00-420-4396 RQST NE Updated Every Day 4720-00-420-4396 RQST Updated Every
Day 4720-00-420-4396 RQST NE Related Documents 4720-00-420-4396 3+ Documents ( More... ) https//www.nsnlookup.com
RQST NE Updated Every Day 4720-00-420-4396 RQST NE Updated Every Day 4720-00-420-4396 RQST Updated Every
Day 4720-00-420-4396 RQST NE Related Documents 4720-00-420-4396 3+ Documents ( More... ) https//www.nsnlookup.com
Documents 4720-00-143-8906 2+ Documents ( More https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-420-4396
Nonmetallic Hose Assembly 4720004204396 Documents ( More... ) https//www.nsnlookup.com https//www.nsnlookup.com
AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NZDiscontinued-Use 4720-00-420-4396
Nonmetallic Hose Assembly 4720004204396 Documents ( More... ) https//www.nsnlookup.com https//www.nsnlookup.com
AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NZDiscontinued-Use 4720-00-420-4396
Restrictions 4720-00-420-4396
4720-00-420-4396 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4720-00-420-4396
- Office of the Secretary of Housing & Urban Development (MM81)
- Effective Date:
- 1 Feb 2014
- Former MOE Rule:
- MF6E
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Sep 1999
Approved Sources 4720-00-420-4396
- Part Number
- Manufacturer
- Status
- MS28741-8-0134
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- 111417-8D-0134
- 98441 - Parker Hannifin Corp (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0134
- 32142 - Hydrasearch Company, Llc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 67C44051
- 98748 - Air Force United States Department (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0134
- 00624 - Eaton Aeroquip Llc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0134
- 50599 - Parker-Hannifin Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0134
- 14798 - Designed Metal Connections Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 360-8D0134
- 00624 - Eaton Aeroquip Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AN6271-8-13 1-2
- 88044 - Aeronautical Standards Group (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4720004204396
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 67C44051
- 98749 - Sacramento Air Logistics Center (Obsolete)
- Informational Drawing
- Informational Drawing
Datasheet 4720-00-420-4396
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Straight 1St End
- Burst Test Pressure [CQBD]
- 8000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Swivel Nut Flare 1St End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Hydrostatic Test Pressure [CRDW]
- 4000.0 Pounds Per Square Inch
- Maximum Operating Pressure [CQGM]
- 2000.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 13.500 Inches Nominal Working
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Minimum Inside Bending Radius [ACKH]
- 4.625 Inches
- Nominal Thread Size [CQJX]
- 0.750 Inches 1St End
- Outer Covering Environmental Protection [CRJM]
- Mildew Resistant And Oil Resistant
- Outside Diameter [ABKV]
- 0.766 Inches Nominal
- Inside Diameter [AARX]
- 0.406 Inches Nominal
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- 2Nd Layer Rubber Impregnated Braided Steel Wire And 1St Layer Rubber Impregnated Braided Cotton Cord And Outer Layer Rubber Impregnated Braided Cotton Cord
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Vacuum In Torr [CRSM]
- 50.8
- Specification/Standard Data [ZZZK]
- 96906-Ms28741 Government Standard
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit And 250.0 Deg Fahrenheit Single Response
- Thread Class [AAJD]
- 3B 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Series Designator [THSD]
- Unf 1St End
DLA Procurement Analysis 4720-00-420-4396
Management Data 4720-00-420-4396
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2014
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- R
- Refer To Mf4720009998994
- MF4720009998994
- R
- Department of the Air Force (DF)
- F
- R
- Refer To Mf4730008422202
- MF4730008422202
- R
- US Marine Corps (DM)
- M
- Q
- Fabricate Or Assemble 4730-00-842-2202
- 1
- EA
- Q
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 8
- 97X4830.FCL4 - Materiel Support DIV (MSD) - Materiel Support Division (MSD), which includes those Air Force Centrally Managed Investment Items (ERRC XD1=C and XD2=T) except for those still managed in budget programs (BP) 15, 25, 82, 83, and 84 as stock fund exempt. MSD also includes items centrally procured and managed as Expense Items (ERRC XB3=N and XF3=P). Reference AFMAN 23–110, Volume 1, Part 3, Chapter 7, Paragraph 7.3.1
- Aggregation Code:
- RK
- AEROSPACE SUPPORT ACCESSORIES
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 39
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 4720-00-420-4396
4930-98-855-1116 4720-99-845-9126 4720-14-311-2847 4720-14-269-0904 4720-21-913-4339 4720-14-277-3699 4720-15-118-9773 4720-14-308-8664 4720-17-114-6295 4720-99-477-5829 4720-12-341-5895 4720-12-330-2083 4720-99-477-5984 4720-17-124-9106 4720-27-053-5411 4720-99-374-7025 4720-12-353-8651 4720-99-580-4201
Freight Information 4720-00-420-4396
4720-00-420-4396 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-420-4396 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-420-4396 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-420-4396 is not classified as a special type of cargo when transported by water. 4720-00-420-4396 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-420-4396
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- No Requirement
- --
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
Contracting Technical Data File (CTDF) 4720-00-420-4396 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
