4720-00-410-1231
Nonmetallic Hose Assembly
4720004101231 004101231 8761502-2
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
Managed by United States
NSN Created on 1 May 1974
Data Last Changed
November 2023
November 2023
NATO Update Count
34
34
NATO Data Quality
Marketplace 4720-00-410-1231
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-410-1231 5+ Documents (More...)
4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7 19207 8761535 5120-00-678-5285 79 12 19207
4720-00-410-1231 21 36 19207 8761507 4720-00-678-3286 21 2 19207 8761510 4720-00-678-3285 37 7 19207
Nonmetallic Hose Assembly 4720004101231 465-6575 42 18 19207 8761491-3 4720-00-410-1184 21 37 19207
4720-00-410-1231 21 36 19207 8761507 4720-00-678-3286 21 2 19207 8761510 4720-00-678-3285 37 7 19207
Nonmetallic Hose Assembly 4720004101231 465-6575 42 18 19207 8761491-3 4720-00-410-1184 21 37 19207
Page 101 of 455. https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-410-1231 Nonmetallic Hose Assembly
4720004101231 4720-00-410-1231 4720004101231 004101231 is a length of nonmetallic hose with fittings
4720004101231 4720-00-410-1231 4720004101231 004101231 is a length of nonmetallic hose with fittings
512-6695 42 40 19207 8761490-2 4720-01-465-6575 42 18 19207 8761491-3 4720-00-410-1184 21 37 19207 8761502-2
4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7 https//www.nsnlookup.com /fsg-30/fsc-3020
8761472 4730-00-194-2481 21 32 19207 8761490-2 40 19 19207 8761491-3 4720-00-410-1184 21 35 19207 8761502-2
4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7 https//www.nsnlookup.com /fsg-30/fsc-3020
8761472 4730-00-194-2481 21 32 19207 8761490-2 40 19 19207 8761491-3 4720-00-410-1184 21 35 19207 8761502-2
512-6695 42 40 19207 8761490-2 4720-01-465-6575 42 18 19207 8761491-3 4720-00-410-1184 21 37 19207 8761502-2
4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7 19207 8761535 5120-00-678-5285 79 12 19207
4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7 19207 8761535 5120-00-678-5285 79 12 19207
8761472 4730-00-194-2481 21 32 19207 8761490-2 40 19 19207 8761491-3 4720-00-410-1184 21 35 19207 8761502-2
4720-00-410-1231 21 36 19207 8761507 4720-00-678-3286 21 2 19207 8761510 4720-00-678-3285 37 7 19207
4720-00-410-1231 21 36 19207 8761507 4720-00-678-3286 21 2 19207 8761510 4720-00-678-3285 37 7 19207
Restrictions 4720-00-410-1231
4720-00-410-1231 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4720-00-410-1231
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4720-00-410-1231
- US Army (A920)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZBD
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- FXAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 Feb 1998
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4720-00-410-1231
- Part Number
- Manufacturer
- Status
- 8761502-2
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 4720004101231
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 4720-00-410-1231
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Straight 1St End
- End Connection Design [AKUU]
- Straight 2Nd End
- End Fitting Component And Material [AKXL]
- Complete Fitting Steel All Ends
- Burst Test Pressure [CQBD]
- 1000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Plain 2Nd End
- Connection Style [AHNC]
- Swivel Nut Flare 1St End
- Connection Type [AWLS]
- Threaded External Pipe 2Nd End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Exterior Color [ADJS]
- Natural
- Fitting Component And Surface Treatment [AKXM]
- Complete Fitting Cadmium 1St End
- Hydrostatic Test Pressure [CRDW]
- 3000.0 Pounds Per Square Inch
- Maximum Operating Pressure [CQGM]
- 1000.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 15.500 Inches Nominal Overall
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Minimum Inside Bending Radius [ACKH]
- 2.000 Inches
- Nominal Thread Size [CQJX]
- 0.125 Inches 2Nd End
- Nominal Thread Size [CQJX]
- 0.438 Inches 1St End
- Outer Covering Environmental Protection [CRJM]
- Fuel Resistant And Ozone Resistant And Salt Water Resistant
- Outside Diameter [ABKV]
- 0.296 Inches Minimum And 0.343 Inches Maximum
- Inside Diameter [AARX]
- 0.173 Inches Minimum And 0.203 Inches Maximum
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- Outer Layer Braided Corrosion Resistant Steel Wire
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Special Features [FEAT]
- Inner Conveying Tube Material-Plastic, Thermoplastic
- Temp Rating [ABJH]
- -67.0 Deg Fahrenheit And 450.0 Deg Fahrenheit Single Response
- Thread Direction [AAJF]
- Right-Hand 2Nd End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Class [AAJD]
- 2B 1St End
- Thread Quantity Per Inch [CMLP]
- 20 1St End
- Thread Quantity Per Inch [CMLP]
- 27 2Nd End
- Thread Series Designator [THSD]
- Nptf 2Nd End
- Thread Series Designator [THSD]
- Unf 1St End
Weapon Systems (WSDC) 4720-00-410-1231
DLA Procurement Analysis 4720-00-410-1231
- Last Stock Position:
- 50 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-00-410-1231
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Air Force (DF)
- PG
- Subscribe
- 1
- PG
- Oct 2021
- Department of the Air Force (DF)
- PG
- Subscribe
- 1
- PG
- Apr 2021
- Department of the Air Force (DF)
- PG
- Subscribe
- 1
- PG
- Feb 2021
- US Marine Corps (DM)
- PG
- Subscribe
- 1
- PG
- Feb 2020
- Department of the Army (DA)
- PG
- Subscribe
- 1
- PG
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- K
- U/I Contains 5 Ea
- 00000000005EA
- K
- Department of the Air Force (DF)
- F
- K
- U/I Contains 5 Ea
- 00000000005EA
- K
- US Marine Corps (DM)
- M
- K
- U/I Contains 5 Ea
- 00000000005EA
- K
- Department of the Navy (DN)
- N
- K
- U/I Contains 5 Ea
- 00000000005EA
- K
- Defense Logistics Agency (DS)
- I
- K
- U/I Contains 5 Ea
- 00000000005EA
- K
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 4720-00-410-1231
4930-98-855-1116 4720-99-845-9126 4720-14-311-2847 4720-14-269-0904 4720-21-913-4339 4720-14-277-3699 4720-15-118-9773 4720-14-308-8664 4720-17-114-6295 4720-99-477-5829 4720-12-341-5895 4720-12-330-2083 4720-99-477-5984 4720-17-124-9106 4720-27-053-5411 4720-99-374-7025 4720-12-353-8651 4720-99-580-4201
Freight Information 4720-00-410-1231
4720-00-410-1231 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-410-1231 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4720-00-410-1231 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-410-1231 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-410-1231 is not classified as a special type of cargo when transported by water. 4720-00-410-1231 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-410-1231
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 10.0" H x 4.0" W x 1.0" L
- --
- --
- --
- Any Suitable Process
- 10.0" H x 4.0" W x 1.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- MIL-DTL-117, Type III, Class C, Style 1, Medium Duty, Waterproof, Greaseproof, Opaque Bag
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 4720-00-410-1231 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- R
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
