4720-00-410-1184
Nonmetallic Hose Assembly
4720004101184 004101184 8761491-3
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
Managed by United States
NSN Created on 1 May 1974
Data Last Changed
July 2023
July 2023
NATO Update Count
25
25
NATO Data Quality
Marketplace 4720-00-410-1184
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-410-1184 5+ Documents (More...)
and calibrated dial or a digital readout display. https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-410-1184
Nonmetallic Hose Assembly 4720004101184 day Upgrade your Account Upgrade 4720-00-410-1184Nonmetallic
Hose Assembly4720004101184 004101184 8761491 -3 HOSE ASSEMBLY,NONMETALLIC 3 EA NS Request Quotation
Nonmetallic Hose Assembly 4720004101184 day Upgrade your Account Upgrade 4720-00-410-1184Nonmetallic
Hose Assembly4720004101184 004101184 8761491 -3 HOSE ASSEMBLY,NONMETALLIC 3 EA NS Request Quotation
-1790-2DA and AVDS-1790-2DR Page 443 512-6695 42 40 19207 8761490-2 4720-01-465-6575 42 18 19207 8761491-3
4720-00-410-1184 21 37 19207 8761502-2 4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7
4720-00-410-1184 21 35 19207 8761502-2 4720-00-410-1231 21 36 19207 8761507 4720-00-678-3286 21 2
4720-00-410-1184 21 37 19207 8761502-2 4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7
4720-00-410-1184 21 35 19207 8761502-2 4720-00-410-1231 21 36 19207 8761507 4720-00-678-3286 21 2
-457-1984 21 3 19207 8761453 5306-01-512-6695 42 40 19207 8761490-2 4720-01-465-6575 42 18 19207 8761491-3
4720-00-410-1184 21 37 19207 8761502-2 4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7
4720-00-410-1184 21 37 19207 8761502-2 4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7
https//www.nsnlookup.com
/fsg-30/fsc-3020/us
/fsg-30/fsc-3020/us
3020-00-811-6835 Sprocket Wheel 3020008116835 008116835
AVDS-1790-2DR Page 443 8761453 5306-01-512-6695 42 40 19207 8761490-2 4720-01-465-6575 42 18 19207 8761491-3
4720-00-410-1184 21 https//www.nsnlookup.com /equipment-intelligence/land/engines/avds1790/360tm-9
AVDS-1790-2DR Page 360 -1984 21 5 19207 8761472 4730-00-194-2481 21 32 19207 8761490-2 40 19 19207 8761491-3
4720-00-410-1184 21 https//www.nsnlookup.com /equipment-intelligence/land/engines/avds1790/360tm-9
AVDS-1790-2DR Page 360 -1984 21 5 19207 8761472 4730-00-194-2481 21 32 19207 8761490-2 40 19 19207 8761491-3
24P Parts Manual for AVDS-1790-2CA AVDS-1790-2DA and AVDS-1790-2DR Page 443 465-6575 42 18 19207 8761491-3
4720-00-410-1184 21 37 19207 8761502-2 4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7
fsg-47/fsc-4720/us 4720-00-410-1231 Nonmetallic Hose Assembly 4720004101231 465-6575 42 18 19207 8761491-3
4720-00-410-1184 21 37 19207 8761502-2 4720-00-410-1231 21 40 19207 8761510 4720-00-678-3285 39 7
fsg-47/fsc-4720/us 4720-00-410-1231 Nonmetallic Hose Assembly 4720004101231 465-6575 42 18 19207 8761491-3
Restrictions 4720-00-410-1184
4720-00-410-1184 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4720-00-410-1184
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4720-00-410-1184
- US Army (A920)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Air Force (FXGC)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- FXAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 Feb 1998
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Oct 1999
Approved Sources 4720-00-410-1184
- Part Number
- Manufacturer
- Status
- 8761491-3
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 4720-00-410-1184
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Straight 1St End
- Burst Test Pressure [CQBD]
- 6000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Swivel Nut Flare 1St End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Exterior Color [ADJS]
- Natural
- Features Provided [CBBL]
- Electrostatic Discharge Capability
- Hydrostatic Test Pressure [CRDW]
- 1600.0 Pounds Per Square Inch
- Maximum Operating Pressure [CQGM]
- 800.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 46.000 Inches Nominal Working
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Minimum Inside Bending Radius [ACKH]
- 5.500 Inches
- Nominal Thread Size [CQJX]
- 0.875 Inches 1St End
- Outer Covering Environmental Protection [CRJM]
- Fuel Resistant And Ozone Resistant And Salt Water Resistant
- Outside Diameter [ABKV]
- 0.633 Inches Minimum And 0.687 Inches Maximum
- Inside Diameter [AARX]
- 0.485 Inches Minimum And 0.515 Inches Maximum
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- Outer Layer Braided Corrosion Resistant Steel Wire
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Vacuum In Torr [CRSM]
- 50.8
- Temp Rating [ABJH]
- -67.0 Deg Fahrenheit Single Response And 450.0 Deg Fahrenheit Single Response
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Class [AAJD]
- 2B 1St End
- Thread Quantity Per Inch [CMLP]
- 14 1St End
- Thread Series Designator [THSD]
- Unf 1St End
Weapon Systems (WSDC) 4720-00-410-1184
DLA Procurement Analysis 4720-00-410-1184
- Last Stock Position:
- 31 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-00-410-1184
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2021
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- JT
- Tanks
Recovery Vehicle, M51/M74/M88
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Material Identification:
- T
- Maintenance Float Secondary Non-depot Reparables
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 4720-00-410-1184
4930-98-855-1116 4720-99-845-9126 4720-14-311-2847 4720-14-269-0904 4720-21-913-4339 4720-14-277-3699 4720-15-118-9773 4720-14-308-8664 4720-17-114-6295 4720-99-477-5829 4720-12-341-5895 4720-12-330-2083 4720-99-477-5984 4720-17-124-9106 4720-27-053-5411 4720-99-374-7025 4720-12-353-8651 4720-99-580-4201
Freight Information 4720-00-410-1184
4720-00-410-1184 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-410-1184 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4720-00-410-1184 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-410-1184 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-410-1184 is not classified as a special type of cargo when transported by water. 4720-00-410-1184 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-410-1184
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 4720-00-410-1184 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
